- Page 1 Range hood Range Hood User Manual BCCH60B-BCCH60X Compliant to EEE Directive. Please read this user manual carefully before installing or using your equipment. Please keep this user manual in a safe place for future use.
-
Page 2: Table Of Contents
Scope of the Range Hood User Manual Dear customer, the following sections contain information on safe and efficient use of the equipment. Please read carefully before attempting to install the equipment. Points to consider before use……………………………………2 Section 1 Technical specifications ............3 Section 2 Technical dimensions ............ -
Page 3: Points To Consider Before Use
Points to consider before use Section 1 1..Electrical connections and installation of the product must be done by qualified service personnel. In contrary, the product's efficiency may be reduced and serious risks such as noise, vibration and electricity leakage may occur. In addition, the warranty becomes null. 2..Operating voltage is 200-230 Volt. -
Page 4: Technical Specifications
≈℄₂ Technical specifications ΔΩ Section 2 Figure A1 1- Flue Top 2- Lower Flue Panel 3- 220V Cable 4- Glass 5- Control icons Range hood technical specifications LENGTH 598-898 105 W MOTOR POWER WIDTH 155 W TOTAL POWER Min 530 Max 1010 AIR OUTLET PIPE DIAMETER 120 mm/150 mm HEIGHT... -
Page 5: Technical Dimensions
Technical dimensions Section 3 Figure A2... -
Page 6: Wiring Diagrams
Wiring diagrams Section 4 Push button Wiring diagrams White Blue Black Brown Button card Brown Black Blue 220-230 V AC ~ RIGHT LIGHT LEFT LIGHT MOTOR BUTTON CONTROL CONTROL Figure A3... -
Page 7: Mounting Instructions
Mounting instructions Section 5A Range hood mounting distances CEILING drill with Ø7 drill bit Flue connection apparatus drill with Ø8 drill bit Mounting plate Oven & Stove Figure A4... -
Page 8: Section 5
Mounting instructions Section 5B Range mounting ŞEKİL A5-1 Figure A5 ŞEKİL A5-2 1- Ø8 mm threaded insert 2- 2x50 rysb screw 3- Motor connection plate & wall mounting plate 4- Range Mounting steps; 1- Drill the required holes in accordance with the distances specified in Figure A4. 2- Drive 2x Ø8 mm threaded inserts (5) and 2x Ø7 threaded inserts into the wall. - Page 9 Mounting instructions Section 5C Range hood flue assembly and completion of the mounting works Note : You are required to buy Ø120 mm or Ø150 mm semi-rigid aluminium duct and 2 connecting clamps for the flue assembly. We recommend you to use Ø150 mm semi-rigid duct. 1- Flue mounting apparatus 2- Ø7 Threaded insert 3- 3,9x9,5 pan head screw...
-
Page 10: Operating Instructions
Operating instructions Section 6 1-Push button operating instructions (0 button): Stops the motor. (1 button): Motor starts-up at Speed 1. (2 button): Motor starts-up at Speed 2. (3 button): Motor starts-up at Speed 3. (Lamp button: ): It is used to turn the lamp on and off. -
Page 11: Maintenance Instructions
Maintenance instructions Section 7A Unplug the product or turn off the switch before commencing maintenance works on the product. Aluminium filter cleaning: Aluminium filter is used to trap the oil particles in the air, therefore it is blocked based on the frequency of use and leads to performance loss with the product. - Page 12 Maintenance instructions Section 7B Carbon filter replacement: Carbon filter is an optional component produced with the purpose of using the range hood without flue connection. If you want to use the product without flue connection, a carbon filter must be purchased from the authorized technical services.
-
Page 13: Fault Descriptions
Fault Descriptions Section 8 Please read the following information carefully before calling an authorized technical service. Range hood does not function! - Make sure that the power cable of the equipment is connected to the power socket. - Check the fuse switches. Range hood functions but the light is off! - Unplug the product and check whether the lamps are intact and they are loose. - Page 14 Guarantee Argos Product Support 01759 487838 Product Guarantee This product is guaranteed against manufacturing defects for a period of Year This product is guaranteed for 12 months from the date of original purchase. Any defect that arises during this period due to faulty materials or workmanship will either be repaired free of charge or replaced.
