Summary of Contents for Polaroid Cube+
- Page 1 USER GUIDE GUIDE DE L’UTILISATEUR | MANUALE UTENTE | BEDIENUNGSANLEITUNG | GUÍA DE USUARIO | GUIA DO UTILIZADOR Wi-Fi HD Action Camera Caméra d’Action HD Wi-Fi | Action Camera HD Wi-Fi | WLAN HD Action-Kamera | Cámara de Acción HD Wi-Fi | Câmara de Ação HD Wi-Fi...
- Page 2 Hello and welcome to the Polaroid Cube ™ camera. Let’s get started. Bonjour et bienvenue dans l’univers de la caméra Polaroid Cube . Démarrons. ™ Ciao, e benvenuto nella fotocamera Polaroid Cube . Cominciamo. ™ Herzlich willkommen bei der Polaroid Cube Kamera.
- Page 3 [only EN chapter has been updated] Overview What’s in the Box Was ist in der Box Get to Know Your Polaroid Cube Camera Deine Polaroid Cube Kamera Using Your Polaroid Cube Camera Bedienung Deiner Polaroid Cube Kamera Que trouve-t-on dans la boîte Qué...
- Page 4 What’s in the Box Get to Know Your Polaroid Cube Camera ™ Polaroid Cube Wi-Fi Micro USB Cable 1. Lens ™ HD Action Camera 2. Microphone 3. Magnet 6 | EN EN | 7...
- Page 5 Top View Back View 4. Wi-Fi Button 7 . MicroSD Slot 5. Multifunction Button 8. Micro USB Port 6. LED 9. Rear Cover Latch 8 | EN EN | 9...
-
Page 6: Table Of Contents
Table of Contents On and Off Capturing Stills from Video SD Card Adjusting Other Settings Installing the Cube Saving, Sharing and Printing Connecting to Wi-Fi Connecting to a Different Cube Photos and Videos Changing Your Passcode Using the App Battery and Charging Video (App section to Still Photo... -
Page 7: Sd Card
Using Your contacts facing up, insert the card and gently push in until you hear a click. To remove a card, Polaroid Cube Camera ™ gently push the card in, release and the card will slide back out. Hold the multifunction button until the LED If no microSD card is present, your camera turns green and you hear 3 beeps. -
Page 8: App
– When prompted, input the Polaroid Cube+ your smartphone as a viewfinder. Download standard Wi-Fi password “1234567890” . the Polaroid Cube+ app from the App Store and It may take up to 5 seconds for the Wi-Fi follow the onscreen instructions to set up your connection to be established. -
Page 9: Photos And Videos
Wi-Fi button until you hear a long beep and the Using the App to Take Photos and Videos LED stops blinking blue. Open the Polaroid Cube+ app. After setting up Let’s Take Photos and Videos your account/signing in, you’ll be taken to the Still Photos Viewfinder screen. - Page 10 For more details, see page 189. 720p at 30 or 60fps. 00:00:00 Video Time: Displays video length. Video Tap once to begin recording video. [slow motion icon] Slow Motion Tap once to stop recording video. [Icon 3.2A.2 Still & Photoburst] Tap once to begin slow-motion capture.
-
Page 11: Still Photo
[time-lapse icon] Time-Lapse Still Photo [icon 3.2A.2 Still & Photoburst] Tap once to Tap once to take photo. begin time-lapse capture. Megapixel Settings: Tap this icon at the [icon 3.2B.5 Video] Tap once to end time-lapse top of the screen to choose between capture. -
Page 12: Editing Video, Time-Lapse And
[photo burst icon] Photo Burst Editing Video, Time-Lapse and Slow Motion For any of these functions, first select the video [Icon 3.2A.2 Still & Photoburst] Tapping and you’d like to edit and view it on playback mode. holding the still photo capture button will Then follow the directions below. -
Page 13: Adjusting Other Settings
Capture Stills from Video, Time-Lapse and Slow Motion Tap any section of the video timeline to zoom [need HiRes] into that section. Tap the image below the timeline to save it as a still image. Tap icon [1] to edit camera name and icon. [image 3.7b] Tap icon [2] to turn off camera from app. -
Page 14: Battery And Charging
Camera is on, with sufficient battery power and SD memory to capture imagery. Battery and Charging To charge your Polaroid Cube+, plug one end of the included microUSB cable into the micro Single Red Flash with Short Beep USB port and the other into either a computer Photo captured. - Page 15 Rapid Blue Flash with One Long Beep Static Orange Camera is pairing to Wi-Fi. Battery power is under 10% (around 3.62V). Camera will turn off when power dips to 3.55V. Intermittent Slow Blue Flashing Camera is paired to Wi-Fi. Rapid Orange Flash with Continuous Short Beeps No SD card present.
-
Page 16: Warnings
Magnet Safety Warnings: indicate any product defect or reason to slow The magnet mount on your Polaroid Cube+ is a down the fun. low-powered magnet. As with any magnet, it is best to follow these safety precautions. - Page 17 Polaroid Cube+ and/or any related Have questions? Need technical support? accessories until consulting a physician. Want to know more? Get in touch at: cspolaroid@camarketing.com www.polaroidcube.com Pregnant Women: Pregnant Women should consult a physician before using any magnetic device.
- Page 18 Federal Communication Commission Interference Statement This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications.
- Page 19 This device complies with Industry Canada’s licence-exempt RSSs. Operation is subject to the following two conditions: (1) This device may not cause interference; and (2) This device must accept any interference, including interference that may cause undesired operation of the device. Le présent appareil est conforme aux CNR d'Industrie Canada applicables aux appareils radio exempts de licence.
