- Page 1 Embeddable Digital Video Recorders 4000 Series Models 4011, 4012, 4013 Hardware Manual Ver. 2.1.0 | July 2018 SENSORAY | p. 503.684.8005 | email:info@SENSORAY.com | www.SENSORAY.com 7313 SW Tech Center Drive | Portland, OR 97203...
-
Page 2: Table Of Contents
Table of Contents Limited warranty ......................... 4 Introduction ..........................5 Connectors ............................ 7 USB Connectors ........................7 Model 4011 ..........................7 Power ............................. 7 Video ............................7 Audio out ..........................7 Keypad ........................... 8 RS-232 ............................ 8 Model 4012 ..........................9 Power ............................. - Page 3 Menu system ..........................17 Firmware updates ........................26 Customizations ........................... 28 Keypad functions ........................28 Splash screen ........................... 28 Maintaining custom settings ....................28 Wireless ............................30 WiFi adapters .......................... 30 Streaming video from a DVR ....................30 Specifications ..........................32 Revision history ..........................
-
Page 4: Limited Warranty
Sensoray specifications for two years from the date of shipment to purchaser. Sensoray will, at its option, repair or replace equipment that proves to be defective during the warranty period. This warranty includes parts and labor. -
Page 5: Introduction
3 available USB ports and used to control the DVR. All members of the 4000 series use the same firmware. Some features are available on particular models only. Connector pinouts are listed for each model in respective... - Page 6 Table 1. Summary of differences between the members of 4000 series. Features 4011 4012 4013 External USB ports vertical vertical right-angle Incremental encoder in- terfaces Built-in microphone Line audio input optional RS-232 (Note 1) optional Note 1: Firmware implementation of RS-232 communications requires knowledge of application specific protocols and is provided on a custom basis.
-
Page 7: Connectors
Connectors USB Connectors There is a total of three USB 2.0 connectors on all models: two on the top side and a single connector on the bottom side. All connectors are functionally interchangeable. The only difference is that a storage device plugged into the connector on the top side is considered “external”, on the bottom side –... -
Page 8: Keypad
Signal left channel ground ground right channel Keypad J4, Molex 90500-4007 or TE Connectivity 5-520314-7, 7 pin. Accepts a ZIF-style flex tail, 0.1” pitch. Recommended mapping for keypad pins and functions: Function Signal Record/Pause DIO33V0 Stop/Back DIO33V1 Snapshot DIO33V2 Down DIO33V3 Menu/OK DIO33V4... -
Page 9: Model 4012
Model 4012 Power J11, Molex 0705530001. Mating part: Molex 0050579402. Signal ground +12 V DC Video In (J10), out (J2) Molex 0705530002. Mating part: Molex 0050579403. Signal video ground not connected Audio out J13, Molex 0705530003. Mating part: Molex 0050579404. Signal left ground... -
Page 10: Incremental Encoders
Mating connectors: Amphenol/FCI 65801-007LF, 65801-008LF, 65801-009LF, 65801- 010LF. Standard pinout: Function Signal Record/Pause DIO33V0 Stop/Back DIO33V1 Snapshot DIO33V2 Down DIO33V3 Menu/OK DIO33V4 common (ground) DIO33V6 Keypad functions could be remapped, as discussed in Customizations chapter using signal names from the table above. Each key is expected to be a normally open tactile switch to a common line. - Page 11 Signal ground...
-
Page 12: Model 4013
Model 4013 Video J2, Samtec IPL1-106-02-L-SH-K. Mating part: Samtec IPD1-06-S-K, crimp terminals CC79L-2630-01-L. Signal ground video in ground video out Power J11, Samtec IPL1-102-02-L-SH-K. Mating part: Samtec IPD-02-S-K, crimp terminals CC79L-2630-01-L. Signal ground +12 V DC Incremental encoders JP1, JP2, Samtec T1M-06-GF-SH-L-K. Mating part: Samtec ISS1-06-L, crimp terminals CC09M-01-GF. -
Page 13: Keypad
Keypad J1, Samtec IPL1-110-02-L-SH-K. Mating part: Samtec IPD1-10-S-K, crimp terminals CC79L-2630-01-L. Recommended mapping for keypad pins and functions: Function Signal unused Encoder #2 reset DIO33V8 Encoder #1 reset DIO33V7 DIO33V6 Common (ground) Menu/OK DIO33V4 Down DIO33V3 Snapshot DIO33V2 Stop/Back DIO33V1 Record/Pause DIO33V0 Keypad functions could be remapped, as discussed in Customizations chapter... -
Page 14: Audio Out
Audio out J13, Samtec IPL1-104-02-L-SH-K. Mating part: Samtec IPD1-04-S-K, crimp terminals CC79L-2630-01-L. Signal Right ground ground Left RS-232 J18, Samtec IPL1-103-02-L-SH-K. Mating part: Samtec IPD1-03-S-K, crimp terminals CC79L-2630-01-L. Signal ground... -
Page 15: Overlays
Overlays DVRs support a wide choice of text overlay information displayed on the preview, recorded video, and screen shots. Overlay's position on the screen, font size and background transparency can be adjusted. The overlays are divided into primary and secondary overlay groups. One selection from each group can be displayed on the screen at any time. - Page 16 Extra overlay is similar to Title overlay. It is an arbitrary text (32x14 characters) that could be entered and saved to/loaded from a file on the internal or external storage device (extra.txt). Additional overlay is similar to Extra overlay and is loaded from addl.txt.
-
Page 17: Menu System
Menu system The DVRs are controlled using a keypad or a standard keyboard and the on-screen menu system. Context-dependent keyboard functions mapping: Functions Outside of the menu Inside the menu Enter, Space Menu Menu Up arrow Rewind by set amount Move up Down arrow Fast forward by set amount... - Page 18 Context-dependent keyboard functions mapping (continued): Functions Outside of the menu Inside the menu Resets the first incremental encoder footage to 0 without affecting the calibration factor Enters the free text mode. Escape exits the free text mode Top menu Play video View snapshots Overlays File management...
- Page 19 ==Overlays== Primary Overlay: Toggles the overlay text on or off. Allows selecting one of 2 font sizes. Setup Primary Overlay Allows setup of Primary overlay. The available options are: Text Brings up Select Overlay Text menu. == Select Overlay Text== This menu allows selection of text to be displayed on top of live and recorded video.
- Page 20 Moves the overlay box across the screen in selected direction. Secondary overlay Allows selecting a secondary overlay which is displayed concurrently with primary from the following options: Turns secondary overlay off Title Selects Title overlay as secondary Coded Selects Coded overlay as secondary Extra Selects Extra overlay as secondary Addtl...
- Page 21 Rename files on external Select files: The last item allows switching between individual and group files selection. The latter allows selecting files for a group operation (copy or delete). Setup Selecting “Setup” brings up the next menu level: == Setup == Set Date/Time Allows setting the battery backed-up real-time clock.
- Page 22 When set to ON recording starts automatically once the board is powered on with approximately 20-30 second boot delay. Recording format Presents a choice of MP4 or TS (transport stream). Default is MP4 (for compatibility reasons). TS format, which is now supported by most hardware and software players, may be preferable because of better robustness in case of an accidental recording interruption, for example, due to a power loss.
- Page 23 Allows selecting device(s) that video and snapshots are recorded to: internal, external or both. If "Prompt" option is selected the user is prompted each time a recording is started. Rotary Encoders (models 4012, 4013 only) Brings up Select Encoder menu. ==Select Encoder== Encoder 1 Encoder 2...
- Page 24 Please obtain the firmware file s4011.fw from Sensoray and copy it to a root directory of a USB drive. Update process usually takes about 30 s, after which the board restarts. Please refer to "Firmware updates"...
- Page 25 Turn WiFi ping on (available only when WiFi is turned on) Enabling WiFi pings may help with some wireless clients (receiving devices) that keep dropping the connection. Should be turned off normally.
-
Page 26: Firmware Updates
The process maybe a bit more complicated when updating from a relatively old firmware version to the new, WiFi-enabled firmware. Adding WiFi support to the Sensoray’s family of DVRs resulted in a significantly different layout of the firmware. Therefore the process of firmware update may be different when updating from an older version without WiFi support to the version with WiFi support. - Page 27 System Parameters). Make sure the firmware version now matches that of the firmware obtained from Sensoray. 7. The option “Turn WiFi on” should be now available in Setup menu section (if the WiFi adapter is present).
-
Page 28: Customizations
Customizations Keypad functions The 4000 series DVRs allow creating custom keypad functions and layout. The process is simple and takes 2 steps: assigning custom keypad functions and saving the custom layout to the flash drive. After that the units are customized by loading the custom mapping file. - Page 29 following procedure. 1. System parameters need to be changed, as desired. 2. Parameters need to be saved to config.txt using "Save system parameters". 3. config.txt needs to be placed into custom.zip file. 4. custom.zip must be loaded using "Update custom.zip" from "Setup" menu. After that custom.zip no longer needs to be present on the flash drive, all the settings are stored in the onboard non-volatile memory.
-
Page 30: Wireless
RTSP, or access the browser based interface. WiFi adapters Only devices qualified by Sensoray are guaranteed to work. Currently the following products are recommended: 1. Anewish Mini WiFi adapter, available from https://www.amazon.com/ANEWISH-... - Page 31 (http://www.videolan.org/vlc/index.html) and RTSP Player (http://rtsp- player.soft112.com). Boot the 40xx with an approved WiFi adapter plugged in. Select "Turn WiFi on" in the Settings menu. Wait for the adapter to turn on ("Turn WiFi off" menu selection will re- place "Turn WiFi on"). Connect your mobile device or computer to the 40xx server wireless network ("s4011").
-
Page 32: Specifications
12 V DC (± 4 V), 2.5 W (incremental encoder Power power not included) 3.3 x 2.5 inch; height varies between models (0.8 Mechanical to 1.2 inch). Please contact Sensoray for drawings and STEP models. Operational temperature 0 to +50 °C... -
Page 33: Revision History
Revision history Version Notes 2.1.0, July 2018 Features and menu items updated. 2.0.0, March 2017 Initial release of combined 4011, 4012, 4013 manual.
