DKT Comega WAVE2 IPLoA-MESH-PLC-W Quick Start Manual

IPLoA-MESH-PLC-W

Quick Start Guide

Package Contents

1 pieces
IPLoA-MESH-PLC-W
Installation of first unit
Router,
GateWay or
Modem
PDS Cable
(Ethernet)
Installation of first unit...
If the IPLoA-MESH-PLC-W can NOT access 3rd
party gateway or your Router then you are
not able to access the unit to complete the
installation.
Please see Troubleshooting guide.
IPLoA-MESH-PLC-W_Quick Start Guide_2017-11-20_Draft_2
1
1 pieces
Quick Start Guide
3
All diodes will light up in
green for about 1 minute.
5
7
IPLoA-MESH-PLC-W User Guide
Technical information on DKT
HomeMesh family

Overview

Installation of first unit...
The Power line diode will then shift
to Amber. Thats means that the unit
is ready for pairing with other units.
If the IPLoA-MESH-PLC-W can access
3rd party gateway or your Router
then the LAN LED will be Green slow
blinking (95% on/5% off).
The Wi-Fi LED should be Amber. That
means the Guide SSID is enabled.
Installation of first unit...
You can now scan and connect to the Guide SSID, the default
Guide SSID is printed on the label of each IPLoA-MESH-
PLC-W.
Power Diode
LAN
Wi-Fi
1 x Gigabit Ethernet Ports
Pairing/Reset Button
Power Plugg (100V-240V~, 50/60Hz)
3.8s 0.2s
on off
Amber
