Summary of Contents for extraspace expandakabin
- Page 1 ™ expandakabin instruction manual www.expandarange.com...
- Page 2 1 x door panel 8 x panel insertion pieces (wood and plastic) 1. For the best results, assemble the Expandakabin on level ground so as to avoid bending of the chassis and complications with the aligning of the panels. 1 x roof cap Fixings: 2.
- Page 3 1. Unpacking: a. Exandakabin arrives flat-packed. d. Unpack the contents, retain packaging Position the flat pack unit in the place that for future use (if you want to demount the you wish to assemble it, or un pack the Kabin). contents and then position the chasis in your preferred site.
- Page 4 2. Corner Post and Wall Assembly a. Attach the corner post inners and d. Line up the wall panels into the groove tighten using 19mm bolts. and slide into position, repeat this with the remaining wall panels. b. Align and fit the 4 corner outerposts, using the self tapping bolts, 4 for each corner.
- Page 5 3. Walls, door and window panels a. Continue this procedure for the remaining panels, including the door and window panels.
- Page 6 4. Roof fitting - retention bars 5. Roof fitting - ceiling panels a. Now that all of the wall, door and a. Lift the panels into position, onto the window panels are in place, it is time to ceiling retention bars retainging lip fit the ceiling retention bars.
- Page 7 6. Roof capping and finishing 7. The Expandashelta is now ready for use Your Expandakabin is now ready for use. We trust it will give you many years of service. a. The roof is now ready to have the roof cap fitted.
- Page 8 8. Accessories The Expandakabin has various accessories, these include: Linking kits. Units can be linked at any time, end to end or side by side to create large areas of accommodation. Electric packs, including: heater, light, cabling, fusebox, switches, trunking and sockets...
- Page 9 ™ andaspace expandarange www.expandarange.com To see more products in the Expandarange, visit: ™ ™ ™ ™ expandashelta expandachem expandakabin expandastore expandashelta...
