Structure and
use guidance
The lifting jack serves for lifting or lowering components and loads with assembly works on building sites.
With the lifting jack e.g. steel girders or wood purlins can be millimeter-exactly aligned.
The weight is turned up or down by means of crank within selflocking spindle transmission.
The lifting jack is equipped with swivel rollers, so that the weight can be brought exactly into the
correct position.
Technical data:
Height of heading fork.......:
with adapter........................:
light mass heading fork .....:
load-bearing capacity ........:
General note:
Only components in perfect status
and original equipment
may be used.
The lifting jack is to be used
only according to the intended
purpose.
The rules for the prevention
of accidents are to be observed.
1,10 m bis 2,75 m
1,36 m bis 3,00 m
36 cm x 21 cm x 11,5 cm
600 kg
height:
1,36 m bis 3,00 m
adapter
Art. Nr.:
12374
4031549
1
1
Lifting jack
Type: KAL 275 hinged
Art. No.
dimensions
(load arm down) .....:
weight completely....:
crank, adjustably......:
1,11 m bis 2,75 m
heading fork
2
stand
underframe
12373
4031549
02054
1,57 m x 0,73 m x 1,64 m
86 kg
Art.-Nr.
12361
4031549
1
height:
load loop
load arm
spindle
spindle transmission
props
3
4
Advertisement
Related Manuals for Müba KAL 275
Summary of Contents for Müba KAL 275
- Page 1 Lifting jack Type: KAL 275 hinged Art. No. 12373 4031549 02054 Structure and use guidance The lifting jack serves for lifting or lowering components and loads with assembly works on building sites. With the lifting jack e.g. steel girders or wood purlins can be millimeter-exactly aligned.
- Page 2 Building up the lifting jack: Lifting jack in the folded up status without plug-on handles. Before building up all swivel rollers must be fixed with brakes. 0,60 m The load arms as well as the stand are folded up. Subsequently, the load arm and the stand are connected with the locating pin.
- Page 3 Use and operation: plan view: The lifting jack may be set up only on horizontal-even, capable of foundation. The weight, e.g. a steel girder or a wood purlin, will be put on the lifting jack. The fixation can be made by drillings in the heading fork.
- Page 4 Lengthening with the adapter: With the plug-on of the adapter, which is otherwise between the two pipes of the stand, it is possible to raise up the work height of the lifting jack by 0,25 m to 3,00 m. adapter 3,00 m 0,25 m 1,475 m...
