- Page 1 MINI HD CAMERA USER MANUAL...
- Page 2 Introduction Power Button Light Sensor Camera Lens Invisible Infrared LEDs Force Shutdown Button Indicated Lights System Reset Button SD Card Slot USB Charger Plug QR Code...
- Page 3 Tech Spec. Resolution 1080P@15fps, 720P@30fps, 640P@30fps, 480P@30fps Video format AVI (H.264 Compression) View angle 150° Motion detection distance 6 meters / 20 feet Infrared LED Night vision distance 2 meters / 7 feet Min. illumination 1 Lux Battery capacity 500mA 50 - 120 minutes (Depending on use environment Battery life...
-
Page 4: Button Operation
Button Operation Turn on camera Quick-press the power button, the camera will turn on. Camera will be available to operate after 1 minute. Cam will be automatically turned on when the USB charger is plugged. Turn off camera Unplug your USB charger from the camera, press Power button for 8 seconds at least, the cam is turned off. - Page 5 Button Operation Force shutdown camera Press the button in the pinhole with a pin tool to force shutdown the camera when the Power APP: HdMiniCam Name: Cam Password: 8888 UID: button doesn't work. HLXXXXXXXXXXXXXXXXXXXXX NOTE: This function will not work when the USB charger is plugged, to use this function, please take out the USB charger plug first.
-
Page 6: Indicator Lights Status
Indicator Lights Status The camera contains 3 indicator lights. In order to get the cam working propetly, please read following status carefully. General Status: All lights OFF USB charger is NOT plugged USB charger is plugged All lights OFF: All lights OFF: 1. - Page 7 Indicator Lights Status Recoding Status: When the camera running, operate the Power button will be able to control camera to start or stop recording onto SD card, See what light status you will get when you operate the Power button: When the camera detects an SD card: Blue light is flashing 3 times: The camera stops recording when quick-pressing Power button.
- Page 8 Connect Camera to Phone 1. Download HDMINICAM app The HdMiniCam app is available on Apple app store and Google play store. Directly search “HDMINICAM” to download. 2. Make sure the camera is in Setup Mode In Setup Mode, the camera’s lights will be (Blue OFF, Red constant ON).
- Page 9 Connect Camera to Phone 4. Go to HDMINICAM app In general, the camera will be automatically added to HDMINICAM app. If not, please tap “+” icon -> Add new online Camera. 5. Setup WiFi for camera icon and select Device Settings (Advance Config). NOTE: If you don’t have a need to view feeds on phone, and just want camera only work as video recorder and save video clips onto SD card, just stop here.
- Page 10 Connect Camera to Phone 6. Enter your WiFi password Tap WiFi Config and then select your WiFi SSID from the WiFi lists. NOTE: The camera only supports 2.4GHz WiFi, please do NOT choose 5GHz WiFi SSID to connect. Enter your WiFi password, please note the password is case sensitive.
- Page 11 Connect Camera to Phone 7. Complete setup and view live feed now After save the WiFi setting, the camera status will reboot itself, The status will be changed from Device Reboot to Online within 1 minute. Then you can view camera wherever you are! NOTE: Remotely accessing camera must require your home router is Internet access.
- Page 12 View Camera on Computer 1. Download and install PC software Download the PC tools from Titathink support website: https://support.titathink.com/downloads/software/pctools.zip NOTE: This ZIP file contains Windows version software and Apple OS version software. 2. Login this software After you install it successfully, find the IPCMultiView on desktop and click on it.
- Page 13 View Camera on Computer 3-1. Add camera to software Click on to add the camera. Click the “+” icon to add New IP Camera. Change the video saved path Add a New IP camera NOTE: In order to add camera to PC software successfully, the camera must be in same local area network as the computer.
- Page 14 View Camera on Computer 3-2. Add camera to software Highlight the “New IP camera”, you need to enter the camera’s UID and Password. Next, click OK to save. The camera UID and Password can be found at the rear side of camera body.
- Page 15 FAQ: Before reading FAQ, please note that most of problems can be solved after the camera is fully charged and perform a reset operation. Please learn how to reset the camera by referring to page 3. When the camera is being weird or it is always dropped, please fully charge it and do a reset operation.
- Page 16 FAQ: D. The camera on app says Device Request or Device Offline. Firstly, see what they means: Device Request: The app is trying to communicate with camera, if success, it will switch to Online. Otherwise, it will switch to Device Offline. Device Offline: The app lost communication with the camera.
- Page 17 FAQ: G. How to change the resolution of recordings. Please go to app->Device Settings->SD Card Record Config->Resolution. H. The time stamp on video clips is not correct. Please go to app->Device Settings->Time Setting->Sync With App Time. I. The recordings on SD card has no sound. Please go to app->Device Settings->SD Card Record Config->Turn on the Sound Record option.
- Page 18 R. Can you place the mini camera in area where has moisture? The mini camera is non-waterproof, please don’t place it nearby water or any place has moisture. S. Where can you purchase the magnetic bracket? You can browse our official website: www.titathink.com to buy.
- Page 19 FAQ: T. What is the default password of camera. The default camera password is 8888. It can be found in the label on mini camera. U. What is an eligible camera password for security privacy. An eligible camera password must contain 8 characters at least. It should contain capital, lowercase letter, number and special characters like !@#$%^&*.
- Page 20 Download the newest quick guide on support site: https://support.titathink.com/knowledgebase/download-pdf/ Support mail: support@titathink.com Phone: +86 0775-8602-0195 Skype ID: titathink Chat us: https://app.purechat.com/w/titathink-support Address: 2/f., Co-talent Park Liuxian Road, Ban’an District ShenZhen Ver 2...
