Connect the PoE to Wi-Fi Bridge
to the Wireless Network
(AP Mode)
Complete these steps to connect the W100 to the
wireless network using AP Mode.
1 Plug the W100 into an electrical outlet that is within range of
the customer's Wi-Fi network. Wait for the Power LED to turn
solid green.
2 On an Internet enabled device, connect to the wireless
network "ADC_Bridge_XXX" where XXX is the last three digits
of the W100's MAC address, which is located on the back
of the W100.
3 On the same device, open a web browser and enter
"http://w100install" in the URL field. Follow the on-screen
instructions to add the W100 to the wireless network.
The WLAN LED will flash green when the connection
is complete.
4 Connect the PoE camera to the Camera port at the bottom
of the W100 using an Ethernet cable.
5 Follow the installation instructions included with the camera
to add it to an account.
2 PoE to Wi-Fi Bridge Installation Guide
Connect the PoE to Wi-Fi Bridge
to the Wireless Network
(WPS Mode)
Complete these steps to connect the W100 to the
wireless network using WPS Mode.
1 Plug the W100 into an electrical outlet that is within range of
the customer's Wi-Fi network. Wait for the Power LED to turn
solid green.
2 Hold down the WPS button for about 3 seconds or until the
WLAN LED begins to flash red.
3 Activate the WPS Mode on the router. The W100 will begin
to connect to the wireless network. The WLAN LED will flash
green when the connection is complete.
4 Connect the PoE camera to the Camera port at the bottom
of the W100 using an Ethernet cable.
5 Follow the installation instructions included with the camera
to add it to an account.
