Technical manual
Butterfly valves Sylax FM - CNPP
CNPP Version (National Center for Prevention and Protection) : DN32/40 - DN300 mm
FM Version (Factory Mutual approval) : DN32/40 - DN300 mm
Summary
Applications and main
characteristics
Sprinkler systems
Applications :
• Sprinkler systems
• For special applications such as lug type
body, alu-bronze or stainless steel disc ...,
contact our technical back office team.
An instruction notice specifying the installation characteristics and the commission of the Sylax FM-CNPP is available on our web
site www.socla.com or on request by our sales department.
uksylaxfm_cnpp - Updated 12/01/2018
• Pressure/Temperature
• Torque value
• Bolts and nuts
Main characteristics :
• Butterfly valves with gear box, dedicated to
sprinkler systems, equipped with chain and
padlocks (CNPP version only).
• CNPP approval n° YO/AL/12/037 dated
02/12/2003
• Factory Mutual approval n° 3029234
(Sylax FM)
• Competitive quality and price ratio
• Reliability
p.2
p.4
p.6
p.8
p.9
p.10
p.11
p.12
p.12
p.13
p.14
p.15
p.15
p.16
p.18
