User Manual
CR1500
Currency Discriminator/Sorter
User Manual
Preface
Thank you for choosing the CR1500 currency counter/sorter. This machine represents the
latest development in Carnation technology. In order to make the best use of this currency counter
and its counting/sorting capabilities, please read the manual carefully, and familiarize yourself
with the operating procedures.
Contents
Safety .................................................................................. 2
Features ................................................................................ 3
Unpacking .............................................................................. 3
Exterior ................................................................................. 4
Operating ............................................................................... 6
Functions ............................................................................... 8
User Menu ............................................................................. 12
Troubleshooting ........................................................................ 14
Key Points ............................................................................. 20
Replacing the fuse ...................................................................... 20
Specifications .......................................................................... 21
Prepared by
Reviewed by
Approved by
1
Advertisement
Table of Contents
Related Manuals for Carnation CR1500
Summary of Contents for Carnation CR1500
-
Page 1: Table Of Contents
Thank you for choosing the CR1500 currency counter/sorter. This machine represents the latest development in Carnation technology. In order to make the best use of this currency counter and its counting/sorting capabilities, please read the manual carefully, and familiarize yourself with the operating procedures. -
Page 2: Safety
User Manual Safety To avoid damage to the machine and/or personal injury, read the following carefully before the first use! Place the unit on a solid flat surface. Before moving the unit, please disconnect the power cord. Damage to power cord may result in fire and/or electric shock. -
Page 3: Features
User Manual Features Detects magnetic ink, infrared ink, UV, CIS image, length, thickness of banknotes. Compact size, user-friendly interface with large and clear LCD display. Up to 4 different currencies (depending on country software), banknotes can be processed in all four orientations. -
Page 4: Exterior
User Manual Exterior 1. Front View ♦Hopper with adjustable guides ♦Banknote pressing wheel ♦Hopper ♦Banknote rollers ♦Control panel ♦LCD display ♦Reject pocket ♦Banknote receiving wheel ♦Banknote receiving sensor ♦Stacker 2. Rear view ♦ Adjusting screw ♦ Handle ♦On/off switch ♦Handle of back drawer ♦RS232 port ♦Banknote ♦USB port for PC connection... - Page 5 User Manual 3. Panel ：Currency selection. ：Batch function on/off and set batch number. ：Increase the batch number by 1 (short press) or 10 (press and hold). ：Send count report to print. ：Counting mode settings: MIX, SINGLE, FACE, ORIENT, COUNT. ：ADD function on/off. Also serves as an upward navigation key. ：View the counting result report.
-
Page 6: Operating
User Manual Operating In order to avoid counting/detection errors, the following must be done before counting: ① Have the banknotes neatly stacked ② Straighten out folded notes/corners ③ Remove wrinkled notes ④ Remove any foreign objects from the notes (staples, coins) Place the machine on a solid flat surface. - Page 7 User Manual messages are displayed on the LCD, please refer to the TROUBLESHOOTING section of the manual. Figure 1 Before counting, please adjust the left and right hopper guides to the size of the banknotes to ensure uninterrupted feeding. Place the well-stacked banknotes on the hopper, and the machine will start counting. The suspicious or unfit banknotes will be moved to the reject pocket.
-
Page 8: Functions
User Manual Functions 1. Currency selection When the machine is turned on, the currency mode is displayed on the LCD. If you need to count/sort another currency, press "CUR" key to change the currency, the symbols of the installed currencies will be displayed in turn: "USD"... - Page 9 User Manual e.g. Example: 美工请把这部分 total 整行头顶加上虚线如下图 If the machine is connected to the printer, you can print the report by pressing the "PRINT" button. 2015-06-26 08:33 Deno Value USD 1 USD 2 USD 5 Total B. Single mode In single mode, "SINGLE" is displayed on the LCD, and the machine will count banknotes of the same denomination.
- Page 10 User Manual In Face mode, "FACE" is displayed on the LCD, and the machine will sort the banknotes according to their front / back orientation. The first banknote detected by the sensor becomes the reference for the rest of the stack. The banknotes facing the other direction are then sorted into the reject pocket, including any suspicious notes (regardless of front/back orientation).
- Page 11 User Manual Note: In "COUNT" mode, the counterfeit detecting function is switched off. 3. Cumulative Counting When you need cumulative counting, press the "ADD" button on the control panel, if "ADD" is displayed on the LCD, the machine will count starting from the original number displayed on the LCD.
-
Page 12: User Menu
User Manual User Menu When the machine is in one of the counting modes, you can enter the user menu by pressing the "MENU" button. You can navigate to any category by pressing the "ADD" button or "DISPLAY" button. 1. Counting Speed Navigate to "1 Speed", press the "BATCH"... - Page 13 User Manual 3. Capacity of the Reject Pocket Navigate to "3 R-P Capacity", press the "BATCH" button or "+1/+10" button to select the capacity of the reject pocket (50, 40, 30 and 20 are available). Press "RESET" button to save the change.
-
Page 14: Troubleshooting
User Manual Date Format Setting Navigate to "1 Date Format" item, press the "BATCH" button or "+1/+10" button to switch the Date Format. Press "RESET" button to save the change. Press "MENU" button to exit. Date and Time Setting Navigate to "2 Date Setup"... - Page 15 User Manual 2. Adjusting feeder’s aperture The adjusting screw of the feeder aperture on the top cover has already been set at the factory. You may need to adjust the feeder aperture if the following problems occur during counting/sorting: ■ Frequent jams, or banknotes pass the feeder with difficulty - turn the adjusting screw clockwise to make the aperture wider.
- Page 16 User Manual...
- Page 17 User Manual Error message displayed Solution Remove the banknotes from the feeder and/or Feeding Failure remove dust from feeding sensor. Remove the banknotes from the stacker and/or Receiving Failure remove dust from receiving sensor. Remove the banknotes from the reject pocket Rejector Failure and/or remove dust from reject pocket sensor.
- Page 18 User Manual Remove the banknote from the back drawer Left Back IR Failure and/or remove dust from Left Back IR sensor. Remove the banknote from the back drawer Right Back IR Failure and/or remove dust from Right Back IR sensor. Remove the banknote from the machine and/or Please Clean Left Counting Sensor! remove dust from IR sensor.
- Page 19 User Manual Slant 1. Tilted banknote. Slant#1 2. Place the banknotes from the banknote stacker back to the banknote hopper and re-count. Double 1. Some banknotes are attached to each other or overlapping. Chained#1 2. Place the banknotes from the banknote stacker back to the Chained#2 banknote hopper and re-count.
-
Page 20: Key Points
User Manual Some foreign objects inside the machine, or banknote jammed. Open the back cover to remove them. Mainloop Broken Turn off the machine and restart it. 5. Sensitivity Parameters Setting You may encounter the following problems during counting/sorting: ■ Machine doesn't sort the notes properly; ■... -
Page 21: Specifications
User Manual Fuse Holder Note: To protect against malfunction, replace only with same type and resistance fuses. Specifications Counterfeit detection: IR, MG, CIS IMAGE, MT, UV Counting speed: 800/1000/1200 notes/min Hopper Capacity: 500 notes Stacker Capacity: 200 notes Reject Pocket Capacity Max, 50 notes Power supply: 100~240V AC, 50/60Hz...
