- Page 1 Model 8159-0011A 1 CHANNEL STRAIN GAGE SENSOR SIGNAL CONDITIONER Installation and Operating Manual For assistance with the operation of this product, contact PCB Piezotronics, Inc. Toll-free: 800-828-8840 24-hour SensorLine: 716-684-0001 Fax: 716-684-0987 E-mail: info@pcb.com Web: www.pcb.com...
- Page 2 Returning Equipment – Following the equipment to PCB Piezotronics for these procedures will insure that your repair. User servicing or repair is not returned materials are handled in the recommended and, if attempted, may most expedient manner.
- Page 3 PCB Piezotronics, Inc. Warranty – All equipment and repair 3425 Walden Ave. services provided by PCB Piezotronics, Depew, NY 14043 USA Inc. are covered by a limited warranty Toll-free: (800) 828-8840 against defective...
- Page 4 Model 8159 Model 8159 Model 8159 Model 8159- - - - 0012A 0012A 0012A 0012A DC Excitation Strain Gage Signal Conditioner DC Excitation Strain Gage Signal Conditioner DC Excitation Strain Gage Signal Conditioner DC Excitation Strain Gage Signal Conditioner Installation and Operating Manual Installation and Operating Manual Installation and Operating Manual Installation and Operating Manual...
-
Page 5: Table Of Contents
SERIES 8159 SIGNAL CONDITIONER MANUAL TABLE OF CONTENTS Section Page DESCRIPTION INSTALLATION WIRING SWITCH DEFINITION FUNCTION DEFINITIONS OPERATING INSTRUCTIONS CALIBRATION INSTRUCTIONS OPTIONS Figure Page Series 8159 Front Panel View Series 8159 Rear Panel View Panel Mounting Cut-Out Dimensions Transducer Wiring Input/Output (I/O) Wiring Location of Jumpers and Potentiometers (Top View) SW1 Switch Settings... -
Page 6: Description
SERIES 8159 SIGNAL CONDITIONER MANUAL DESCRIPTION The Series 8159 is a microprocessor-based digital indicator capable of interfacing directly to low level strain gage transducers. An internal, high gain, fully differential amplifier and a 4-½ digit analog-to-digital converter combine to accurately digitize the input signal. A 5V @ 60mA or 10V @ 120mA, short circuit protected, transducer excitation supply is also provided. -
Page 7: Installation
SERIES 8159 SIGNAL CONDITIONER MANUAL Figure 2 - Series 8159 Rear Panel View INSTALLATION The Series 8159 enclosure is designated for panel mounting in a 1/8 DIN cutout. The cutout dimensions are shown below. Figure 3 - Panel Mounting Cutout Dimensions To panel mount the 8159, perform the following steps: 1. -
Page 8: Wiring
SERIES 8159 SIGNAL CONDITIONER MANUAL WIRING Reference Figures 4 and 5 for TRANSDUCER and INPUT/OUTPUT (I/O) wiring information. Power is applied with a 3-prong AC power cord. The instrument is protected by a 250V, 250mA fast acting 5mm fuse. The fuse holder is an integral part of the input power connector. A spare fuse is provided in the fuse holder. - Page 9 SERIES 8159 SIGNAL CONDITIONER MANUAL Figure 5 - Input/Output (I/O) Wiring...
- Page 10 SERIES 8159 SIGNAL CONDITIONER MANUAL Figure 6 - Location of Jumpers and Potentiometers (Top View) Warning: Remove AC power to the 8159 meter before removing any enclosure panels or making any internal adjustments or changes. Switch 1 Switch 2 Switch 3 Switch Switch Bridge...
- Page 11 SERIES 8159 SIGNAL CONDITIONER MANUAL Housing RCAL Resistor Rear Panel Figure 9 - Location of RCAL Resistor (Top View) Warning: Remove AC power to the 8159 meter before removing any enclosure panels or making any internal adjustments or changes. Figure 10 - Front Panel Switches...
-
Page 12: Switch Definition
SERIES 8159 SIGNAL CONDITIONER MANUAL SWITCH DEFINITIONS Mode Selection Switch (S1) S1 is used to cycle through the various set points, Hysteresis, and calibration values and decimal point locations. The sequence is as follows. The designators, in parenthesis, identify text that will be displayed, momentarily, followed by the value. -
Page 13: Function Definitions
SERIES 8159 SIGNAL CONDITIONER MANUAL Decrement Switch (S3) This switch serves two functions, depending on the present status of S1. If the instrument is in the Mode Selection sequence, this switch will decrement the flashing digit. If the instrument is in its operating mode, S3 becomes an AUTO CAL switch. CAUTION: Depressing this switch will cause the instrument to recalibrate its full-scale reading. -
Page 14: Operating Instructions
SERIES 8159 SIGNAL CONDITIONER MANUAL Set Point Low 2 (SPL2) SPL2 is independent and functions identically to SPL1. SPL2 has its own relay contact outputs and front panel LED (L2). Hysteresis High (HH) HH is the hysteresis value for SPH1 and SPH2. The hysteresis value determines the number of counts the displayed reading must fall below SPH1 and SPH2 values before deactivating their respective relays and LEDs. - Page 15 SERIES 8159 SIGNAL CONDITIONER MANUAL PROGRAM INSTRUCTIONS Four front panel switches (S1, S2, S3, S4) allow the user to program Set Point, Hysteresis, Calibration Number (CAL) and Decimal Points and monitor minimum, maximum or real time values. 1. Depress MODE (S1) switch once. The text SPH1 followed by the current value of Set Point High 1 (SPH1) will be displayed.
-
Page 16: Calibration Instructions
SERIES 8159 SIGNAL CONDITIONER MANUAL REMOTE TARE (ZERO) Remote zero will tare out any residual value, such as that caused by fixturing a load cell into a test stand. It is activated by momentarily connecting pin 14 to pin 5 on the 15-pin I/O connector REMOTE REBOOT This feature is used to clear the high or low set points if required. - Page 17 SERIES 8159 SIGNAL CONDITIONER MANUAL 8. With no load on the transducer, verify the instrument reading is low. 9. Depress the INCREMENT (S2) switch and hold until the TARE LED illuminates. The readout should be ZERO +/- 1 digit. 10. Apply the FULL SCALE load to the transducer. If a strain gage simulator is used, set it to the desired mV/V setting.
- Page 18 SERIES 8159 SIGNAL CONDITIONER MANUAL 4. Set the CAL NUMBER to the full-scale value provided with the RCAL resistor. This is the shunt calibration valve indicated on the sensor’s calibration certificate. Example: If the RCAL resistor supplied with the instrument creates an output equivalent to 80% of a full-scale 500-pound load, set the CAL NUMBER to 400.00, 0400.0 or 00400.
-
Page 19: Options
SERIES 8159 SIGNAL CONDITIONER MANUAL OPTIONS RS232 SERIAL COMMUNICATION OUTPUT The RS232 transmission is of the displayed reading and is transmitted once every display update, if the DSR line is TRUE (HIGH). The data format is described below. 1. No parity bit 2. -
Page 20: Figure 12
SERIES 8159 SIGNAL CONDITIONER MANUAL Figure 12... - Page 21 Model Number Revision A 1 CHANNEL STRAIN GAGE SENSOR SIGNAL CONDITIONER 8159-0011A ECN #: 37693 Performance ENGLISH Optional Versions (Optional versions have identical specifications and accessories as listed Linearity ±0.015 % FS ±0.015 % FS for standard model except where noted below. More than one option maybe used.)
- Page 22 PCB Load & Torque Inc. claims proprietary rights in REVISIONS the information disclosed hereon. Neither it nor any reproduction thereof will be disclosed to others without DESCRIPTION the written consent of PCB Load and Torque Inc. WAS +/-5VDC, UPDATED TO L&T - 05.14.13, PTE 41416 POWER 3.78...
