AC-SERIES ULTRASONIC CLEANER USER MANUAL FEATURES Normal and soft power control to resolve the cleaning blind spot. Blinking LED light bar display for timer and temperature. Stainless steel housing, tank and lid, nice looking. Stamp tank without welding gap for better waterproof. Cooling fan.
Page 2
INTRODUCTION Ultrasonic cleaning is based on the cavitation effect caused by high frequency ultrasonic wave vibration signal in the fluid. Microscopic bubbles are formed, and they implode violently causing the cavitation which create an intense scrubbing action on the surface of the item being cleaned. The bubbles are small enough to penetrate microscopic crevices,cleaning them thoroughly and consistently.Ultrasonic cleaning is extremely effective at removing dirt and grime which...
Attention While the machine is working normally, ultrasonic and tank syntony gives a well-proportioned sound, and no shudder on the surface of the water, yet there is spray made by the tiny bubbles. If there are discontinuous surges, please add or release a little of washing solution in the tank, stopping the surges is better for the objects cleaning.
Page 4
6) Never immerse the machine or power cord in water or other liquid. 7) DO NOT touch the power plug with wet hands, especially when inserting or removing the plug. 8)DO NOT touch the unit if the machine has fallen into water during operation. Remove the power plug from the socket first.
Page 5
Beauty and Chiropody Institutes: scissors, scalpels, comedo removers, pincers, nippers, forceps and razors with the removal of organic tissue before sterilization treatments. Tattoo Studios: grips, tips and needles. Dental Practices and Dental Technician Laboratories: dental instruments, removing organic and blood residues, Hospital cleaning hand pieces, drills, heads for ultrasonic ablators, glass objects and mirrors;...
Page 6
MECHANICAL ULTRASONIC CLEANER STRUCTURE Unit front view/side view A: Stainless steel housing B: Lid C: SUS304 tank D: Max line E: Plastic carrying handles F: Drain tap G:Rubber feet...
Page 7
Unit back view A:Louver B:Socket C:Power switch D:QC PASSED sticker E:Rating label Front panel A: Heating knob:Turn rightwards to set the temperature from 20-80℃,turn leftwards to reduce the temperature. (Note:1:It’s useless to turn rightwards when temperature reach to 80℃ and turn leftwards when temperature reach to 20℃) B:Timer knob : Turn rightwards to set the timer from 0-30mins,turn leftwards to reduce the timer.
C:Heating indicator:When turn on power switch and setting temperature reached ,the heating indicator will light up. D:Timer indicator:When turn on power switch and setting timer reached , the timer indicator will light up. E:Heating LED light bar:Temperature display F:Timer LED light bar:Timer display G:Normal power :100% power to the tank for normal applications .
Page 9
b:Turn the knob leftwards to reduce the temperature . c:To stop heating immediately, turn knob leftwards to off until heating indicator light up again. Note: 1.Temperature with 13 gear ranges ,from 20,25,30,35, 40,45,50,55,60,65,70,75,80℃ 2.Heating will auto start again when actual temperature ℃...
