- Page 1 I N S T A L L A T I O N I N S T R U C T I O N S Instrucciones de instalación Istruzioni di installazione Installationsanleitung Installatie-instructies Instruções de Instalação Instructions d´installation Office Furniture Bracket Spanish Product Description German Product Description Portuguese Product Description...
- Page 2 The information contained in this document is subject to change without notice or obligation of any kind. Milestone WARNING: Failure to provide adequate structural strength makes no representation of warranty, expressed or implied, for this component can result in serious personal injury or regarding the information contained herein.
- Page 3 Installation Instructions OFB211 LEGEND Tighten Fastener Open-Ended Wrench Apretar elemento de fijación Llave de boca Befestigungsteil festziehen Gabelschlüssel Apertar fixador Chave de bocas Serrare il fissaggio Chiave a punte aperte Bevestiging vastdraaien Steeksleutel Serrez les fixations Clé à fourche Loosen Fastener Phillips Screwdriver Aflojar elemento de fijación Destornillador Phillips...
-
Page 4: Assembly And Installation
OFB211 Installation Instructions Assembly And Installation Secure wall plate (not included) to main bracket (A) by installing three #10-24 lock nuts (G) and three #10 washers (H) onto three permanent screws on main bracket. (See Figure 3) WARNING: Exceeding the weight capacity can result in serious personal injury or damage to equipment! It is the installer’s responsibility to make sure the combined weight of all components attached to this accessory does not exceed... - Page 5 Installation Instructions OFB211 Installation onto a Horizontal Bracket Hook main bracket onto horizontal bracket at desired mounting location. Secure horizontal hooks bracket (C) to main bracket (A) by installing #10-24 x 5/8" Phillips head machine screw (E) through holes in both brackets. (See Figure 4) Figure 4 Secure wall plate (not included) to main bracket (A) by installing three #10-24 lock nuts (G) and three #10 washers...
- Page 6 OFB211 Installation Instructions...
- Page 7 Installation Instructions OFB211...
- Page 8 Milestone AV Technologies Asia Pacific A Office No. 1 on 12/F, Shatin Galleria 18-24 Shan Mei Street Fotan, Shatin, Hong Kong 8812-002003 REV 00 P 852 2145 4099 2010 Milestone AV Technologies, a F 852 2145 4477 Duchossios Group Company www.chiefmfg.com 02/10...
