USER & INSTALLATION GUIDE

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the PLIXUS and is the answer not in the manual?

Questions and answers

Summary of Contents for Televic PLIXUS

  • Page 1 PLIXUS USER & INSTALLATION GUIDE...
  • Page 2 However, the information in this manual is supplied without warranty, either express or implied. Neither the authors, Televic Conference NV, nor its dealers or distributors will be held liable for any damages caused or alleged to be caused either directly or indirectly by this book.
  • Page 3: Table Of Contents

    Plixus MME Overview Control dial functionality Rear connectivity Dante™ interface Supported Video Formats Factory defaults restore button Plixus AE-R Overview Recording feature Rear end connectivity Power supply Factory defaults restore button Plixus power supply Plixus AE-R power supply Plixus power supply...
  • Page 4 Audio only equipment Multimedia equipment Interpreter equipment Installation design Plixus component properties 100 Mbit powered over Plixus Cable 1 Gbit powered over Plixus cable 1 Gbit externally powered General installation guidelines Units per branch / loop When to use a network extender...
  • Page 5 Microphone connector characteristics Microphone Operation Modes Install delegate units Connect Plixus units Connect to Plixus engine Install Confidea G3 Connect Wireless Conference Access Point (WCAP) to Plixus network Configuration Introduction Plixus Core Plixus Core versus CoCon Configure IP settings Change IP settings in Windows...
  • Page 6 General volume Dynamics processing Auto gain reduction Audio routing Audio routing configuration Auxiliary levels Additional options Interpretation Add new language Add Interpretation configuration from CoCon Operator Regional settings Network settings Network information Camera protocol REST API Users System info Couple with Confidea G3 Couple WCAP with engine Associate units with WCAP Takeover WCAP...
  • Page 7: Introduction

    INTRODUCTION This chapter will give you a short introduction to this manual together with a general description of the Plixus network and its functionalities.
  • Page 8: Getting Started

    GETTING STARTED About This Manual Throughout this guide we use icons to designate different types of information: This is a note. A note gives additional information, such as the meaning of the color of the microphone LEDs. A note also provides information that may only be applicable to some situations. This is a tip.
  • Page 9: Compatibility

    Compatibility This user manual applies to the following products: Product Version Plixus MME ≥ Plixus AE-R ≥ CRP 5.2 Confidea WCAP G3 ≥ 3.1 Confidea G3 delegate units ≥ 3.1 G ETTING STAR TED...
  • Page 10: Safety Instructions

    SAFETY INSTRUCTIONS The safety instructions contain general safety guidelines that integrators, installers, operators, end users, and anyone else who installs or uses Televic material is required to read and follow at all times. Safety All Televic systems are state of the art devices and have been designed to meet all quality standards.
  • Page 11: Conformity And Certification Info For Japan

    2. This device must accept any interference received, including interference that may cause undesired operation. Changes or modifications made to this equipment not expressly approved by Televic Conference NV may void the FCC authorization to operate this equipment. Wireless discussion units and the Wireless Access Point comply with FCC radiation exposure limits set forth for an uncontrolled environment.
  • Page 12: Important Safety Instructions

    Important Safety Instructions 1. Read Instructions. All the safety and operating instructions should be read before the product, device or system is operated. 2. Retain Instructions. The safety and operating instructions should be retained for future reference. The instructions should be kept in the vicinity of the product or system. 3.
  • Page 13 12. Power Sources. This product should be operated only from the type of power source indicated on the marking label. If you are not sure of the type of power supply to your home, consult your product dealer or local power company. For products intended to operate from battery power, or other sources, refer to the operating instructions.
  • Page 14: Power Connections

    a. When the power-supply cord or plug is damaged. b. if liquid has been spilled, or objects have fallen into the product. c. If the product has been exposed to rain or water. d. If the product does not operate normally by following the operating instructions. Adjust only those controls that are covered by the operating instructions as an improper adjustment of other controls may result in damage and will often require extensive work by a qualified technician to restore the product to its normal operation.
  • Page 15 The lightning flash with an arrowhead symbol, with an equilateral triangle, is intended to alert the user to the presence of un-insulated ‘dangerous voltage’ within the products enclosure that may be of sufficient magnitude to constitute a risk of electric shock to persons.
  • Page 16: About Plixus

    Moreover, Plixus is conceived with a self-healing topology: data will always travel the shortest route and in the case of an error, Plixus will self-correct and reroute data via the fastest available pathway. Ultimately, it offers all parties peace of mind with Plixus’ rock-solid reliability.
  • Page 17: Plixus Components

    PLIXUS COMPONENTS The Plixus architecture allows for a mix & match of components: from flushmount devices to multimedia units and interpreter desk to PTZ cameras and third-party Dante™-enabled applications. This chapter will describe all available hardware components together with how...
  • Page 18: Components

    Figure 1-2 Plixus architecture diagram with example setup The Plixus architecture allows for a mix & match of components: from flushmount devices over multimedia units and interpreter desk to PTZ cameras and third-party Dante™-enabled applications. A typical setup consists of the following components:...
  • Page 19 Confidea F units: flushmount units (discussion/voting/interpretation) Confidea G3 units: the wireless solution Lingua Interpreter Desks Video IN-OUT boxes A combination of peripherals PTZ cameras External displays Dante™-enabled devices CO MPO NENTS...
  • Page 20: Component Range

    COMPONENT RANGE As discussed earlier, you can include different components in your Plixus network. These components can be divided into four different categories: Central equipment: the heart of the Plixus network, with these devices you can set up, configure and maintain the Plixus network.
  • Page 21: Plixus Mme

    (camera control, Dante, central software, API). The central unit can drive a maximum of 80 Plixus units directly from the engine. In case a large number of units are required, the system can be extended with multiple Plixus Network Extenders.
  • Page 22 0 to max Plixus MME headphone volume Additional icons are displayed to indicate different states: indicates that CoCon server is connected to the Plixus Multimedia Engine indicates an error state. indicates a Master/Slave setup. Control button key lock activation/deactivation. Press and hold control dial for 5 sec. You can still browse through the settings when locked.
  • Page 23: Rear Connectivity

    Rear Connectivity Figure 1-4 Plixus MME rear view The rear of the Plixus MME/AE-R has the following connectivity options: 1. AC power inlet & fuse holder 2. Balanced (XLR) and two unbalanced (RCA) audio outputs 3. Balanced and (XLR) two unbalanced (RCA) audio inputs 4.
  • Page 24: Dante™ Interface

    1. Make sure the Dante card connectors face the top and put the card in under a 45° angle. 2. Press the card down and secure it with two screws, one at each corner of the card. Please switch off power before inserting the DANTE™ card into the Plixus MME/AE-R. PL IX US MME...
  • Page 25: Supported Video Formats

    3G SDI Factory Defaults Restore Button Figure 1-5 Reset button on Plixus MME To restore factory default settings , push the button inside the small hole , next to the headphone connector for at least 10 sec and release. PL IX US MME...
  • Page 26: Plixus Ae-R

    Figure 1-7 How to use the recording feature With the Plixus AE-R you can record the floor and up to three different languages. You can use the button on the engine or the Plixus Core web server to control recording.
  • Page 27: Rear End Connectivity

    8. LAN port Power Supply The Plixus AE-R does not have an internal power supply. By default one external power supply of 220 W is delivered together with the engine. You can use a second power supply for redundancy. However for larger setups you need the additional power to power the units, preventing you to use the second power supply for redundancy.
  • Page 28: Plixus Power Supply

    The Plixus MME has an internal power supply of 48 V/10 A (480 W). However the Plixus AE-R does not. By default you receive one Plixus power supply with the AE-R. When the internal power supply of the MME or the external power supply of the AE-R is insufficient, a separate power supply is necessary.
  • Page 29: Plixus Next

    PLIXUS NEXT Plixus NEXT is the next generation of Plixus network extenders which have the same functionality and connectivity, but additionally offer the option to configure (via DIP switches) a delayed power up of the conference extension ports (see DIP switch table below).
  • Page 30: Dip Switch Table

    *planned for future releases General Network Extender Guidelines The maximum distance between the central unit and the first Plixus network extender or delegate unit in the branch is 100 m. The maximum distance between two Plixus network extenders is 100 m.
  • Page 31: Redundancy

    In Plixus it is possible to insert a type of fail-safe mechanism by creating redundancy. You can get redundancy by inserting loops in your network. When there is a loop, Plixus can still access the device using a different route when a cable or a device in one side of the loop breaks.
  • Page 32 AUX OUT AUX IN Central Dante 48 V IN CONFERENCE NETWORK (CN) 48 V / 2A OUT (4x) MAX 420W PORT 1 PORT 2 PORT 3 PORT 4 Unit ON WE 2 3 4 Network Extender Delegate Unit Redundancy for cables and Redundancy for cables, network extenders delegate units and delegate units...
  • Page 33: Video In

    Push to show You can use multiple V-IN boxes in a Plixus network. Group V-IN boxes in order to create a presentation stream based on a push to show principle (using the Video-Request button or dry contacts). A total of six streams can be active in the Plixus network at any given time.
  • Page 34: Video Request

    Interlace is not supported Video Request The video stream input request can be done via dry contacts or by using the Plixus V-REQ (video input request button), see image below. Connection of V-REQ to the Video In Box is done through the included micro USB cable.
  • Page 35: Video-Out

    VIDEO-OUT Video-Out Box You can use the Plixus Video-OUT Box to extract any HDMI video stream from the Plixus network to an external device using HDMI. Two modes are available: fixed stream routing selection of available streams (using Video-Selection (V-SEL) or dry contacts) You can assign multiple V-OUT boxes to a group, routing a specific stream to these boxes.
  • Page 36: Video Selection

    Interlace is not supported Video Selection Video stream selection can be done via dry contacts or by using the Plixus V-SEL accessory. Connect the V- SEL to the Video-OUT Box is done through the included micro USB cable. Figure 1-16...
  • Page 37: Video Stream Routing

    VIDEO STREAM ROUTING You can configure video stream routing using the CoCon Video application (CoCon & Plixus CRP version ≥ 5.0). Figure 1-17 Configure video stream routing in CoCon In the application you can define the video input and create input groups ( shown on the left side of the figure).
  • Page 38: Delegate Equipment

    DELEGATE EQUIPMENT You can add different types of units and other peripherals to your Plixus architecture depending on your requirements. Below you can find a list of all delegate equipment that you can combine with Plixus together with a short description.
  • Page 39: Interpreter Equipment

    INTERPRETER EQUIPMENT Within the Plixus network it is possible to configure interpretation. Different units are availble for interpreters. Below you can find a list of all these units, together with a short description. Product Description Lingua interpreter desk Unit specifically designed to support interpretation. In the video enabled version you (video enabled) can extract video from the units HDMI output.
  • Page 40: Installation Design

    INSTALLATION DESIGN This chapter describes how to set up the installation of the Plixus network before you can physically install it. You will find more information on the technical details of the different components and how to combine and configure them.
  • Page 41: Plixus Component Properties

    PLIXUS COMPONENT PROPERTIES It is not possible to combine all Plixus components on the same branch because some units are powered over the Plixus cable, while others require external power. In addition there is a difference in network speed for audio-only devices versus multimedia devices. As a consequence, three different categories of devices are possible that you cannot mix on the same branch.
  • Page 42: 1 Gbit Externally Powered

    1 Gbit Externally Powered Max Power Component type Plixus Network Speed Power over Plixus cable Consumption uniCOS 7" F/ MM 1 Gbit 15 W uniCOS 10" F/MM 1 Gbit 15 W Plixus NEXT 100 Mbit / 1 Gbit A branch cannot mix products with different network speeds. A single branch is restricted to components from one and the same category.
  • Page 43 It is strongly recommended to only place Plixus Network Extenders in one branch, and not to mix them with uniCOS Multimedia units (although they belong to the same category). PL IX US CO MPO NENT PR O PER TIES...
  • Page 44: General Installation Guidelines

    GENERAL INSTALLATION GUIDELINES The following installation design rule apply for one branch / loop powered only by the Plixus engine (internal 48 Vdc power supply) or an external Plixus Power Supply: A maximum of 100 W A specific maximum of devices per product family per branch / loop...
  • Page 45 When you daisy-chain network extenders you can use a maximum of 32 extenders (eight per branch and this for the four Plixus conference ports). In a tree structure there are no limitations. See "Installation diagram" on the next page for a schematic representation of these cases.
  • Page 46: Installation Diagram

    Example of Plixus network with engine only For a setup where you only need an engine, connect the units directly to the conference ports of the Plixus engine. Daisy chain the different units in the branch. If your system contains uniCOS units, you need an external power supply.
  • Page 47 2 3 4 Max. 8 Max. 32 Figure 1-20 How to put network extenders in daisy-chain configuration To create redundancy in your system you can insert loops (see "Plixus NEXT" on page 29 AUX OUT AUX IN Dante 48 V IN...
  • Page 48 AUX OUT AUX IN Dante 48 V IN CONFERENCE NETWORK (CN) MAX 420W 48 V / 2A OUT (4x) PORT 1 PORT 2 PORT 3 PORT 4 ON WE 2 3 4 Figure 1-22 How to use network extenders in a tree structure You can also create redundancy in a tree structure, the figure below shows you how to achieve this.
  • Page 49 For installation with a network connector, use the conference port on top of the network extender to connect with the Plixus engine. Use the second top conference port to form a daisy chain with another network extender. Use the conference ports on the bottom of the extender to connect the units inside the room.
  • Page 50: Examples

    Examples EXAMPLE WITH 50 CONFIDEA F UNITS INSTAL L ATIO N DIAG R AM...
  • Page 51: Power Supply Design

    Plixus AE-R Power Supply The Plixus AE-R does not have an internal power supply, however it does have two power connectors. By default you get one power supply together with the engine. You can extend this power supply with another as redundancy or when the system requires more power.
  • Page 52: Calculator Tool

    How to decide to need an additional Plixus AE-R power supply Calculator Tool The Plixus Power Calculator Tool allows to you to validate a configuration in more detail. It takes into account the network cable lengths, power cable lengths and the different types of equipment.
  • Page 53 Avoid placing copper cables near equipment that can generate high levels of electromagnetic interference. Generally avoid locations near power cords, fluorescent lights, building electrical cables and fire-prevention components. Use the Plixus Power Calculator to ensure sufficient power for all units in the network. PO WER SUPPL Y DESIG N...
  • Page 54: Combine Plixus With Confidea G3

    Combine Wired And Wireless Units With Plixus it is possible to combine wired and wireless units this can be the case when disabled people require a wireless microphone. You can also use the wireless units to extend the amount of people that can join the meeting.
  • Page 55: Combine Interpretation With Wireless Units

    Combine Interpretation With Wireless Units In the Confidea G3 unit product range, multiple units that can support that support channel selection are available. Couple such units with the Plixus engine to receive the channels from the Lingua Interpreter Desks in your Plixus network.
  • Page 56: Range Extension With Multiple Access Points

    For more information on how to position the WCAPs for optimal transmission see the Confidea G3 dedicated user guide. televic WCAP 1 RF range WCAP 2 RF range...
  • Page 57: Split And Combine Rooms

    WCAPs with the Plixus engine. In this way you can manage all units centrally using the Plixus engine and web server. When you need to split the room again, simply uncouple the WCAP from Plixus. The WCAP will go back to standalone mode where it remembers all its previous settings.
  • Page 58 Create redundancy by having a backup WCAP in your Plixus system with no associated units. Transfer units in case of problems to this backup WCAP by using the Plixus Core web server. CO MB INE PL IX US WITH CO NF IDEA G 3...
  • Page 59: Installation Process

    INSTALLATION PROCESS This chapter describes how to physically set up and install the Plixus network. Here you can find all technical details needed to correctly install all Plixus components.
  • Page 60: Introduction

    Before you start, make sure to take all necessary precautions. Refer to the tables above and ensure all components are installed and sufficiently powered. Before you install the Plixus system, make installation design as described in "Installation design" on page 40 to ensure correct installation. In this design you will calculate the following elements:...
  • Page 61: Power Supply

    PLIXUS AE-R To supply power to the Plixus AE-R using the power outlets on the engine. You can add two 220 V power supplies. Use a second one when 220 V is insufficient or as a redundant power supply.
  • Page 62 Figure 1-32 Power connection of Plixus MME You can supply power the units over Ethernet. Each conference ports can supply a maximum of 100 W. PO WER SUPPL Y...
  • Page 63: Install Cables

    INSTALL CABLES Use CAT 5e cables to connect Plixus AE-R or MME to the delegate and chairmen units, and to connect the different units in a branch / loop. For more information on cable details, see "Cable requirements" on page 52.
  • Page 64: Install Microphones

    INSTALL MICROPHONES General Microphone Characteristics All Plixus compatible units have a screw-lock connector to insert pluggable microphones. The recommended speaking distance from the mouth to the top of the microphone is between 20 to 40 cm. In order to accommodate the variety of speakers and speaking distances, microphones are available in three different lengths: 30 cm (D-MIC30SL), 40 cm (D-MIC30SL) and 50 cm (D-MIC50SL).
  • Page 65: Microphone Connector Characteristics

    Microphone Connector Characteristics Confidea D-MIC microphones have a 5-pin connector to plug into the different Plixus compatible units. Each pin has a distinct function: Figure 1-33 Microphone connection 1. Pin 1: Microphone GND 2. Pin 2: Microphone signal 3. Pin 3: not used 4.
  • Page 66 Color Status Red (continuous) Microphone is active Red (blinking) Last minute of speech time (if set via software) Speech Request (if set via software) Green (continuous) Microphone is initialized Green (blinking) Microphone request INSTAL L MICR O PHO NES...
  • Page 67: Install Delegate Units

    This means that it doesn’t matter which port is used, the units automatically detect whether it is an input or output. Each unit has two conference ports, below you can find a list with all Plixus compatible units and the location of their conference ports.
  • Page 68: Install Confidea G3

    Connect Wireless Conference Access Point (WCAP) To Plixus Network Use the conference ports on the WCAP to connect to the Plixus engine or a network extender. In some cases you want to have multiple WCAPs available ( see "Combine Plixus with Confidea G3" on page 54 for more information).
  • Page 69: Configuration

    CONFIGURATION This chapter describes how to configure the Plixus network using the Plixus Core web server. It includes a description of how to connect to the built-in web server together with how to initialize units and configure audio settings to guarantee a...
  • Page 70: Introduction

    CoCon: is the complete software suite for conference management. Plixus Core From CRP 5.1 onwards, the Plixus system provides the possibility to use Plixus Core. Below you can find a list containing all functionality that is available in Plixus Core. This guide will discuss all these features together with how to configure and use them.
  • Page 71 Plixus Core CoCon 5.2 Start/Stop initialization Retrieve initialization Creation of synoptics Support for multiple synoptics Configuration of interpreter booths Changing seat priority (delegate – chairman) Default microphone mode No default, the last configured...
  • Page 72 Standalone Advanced interpretation (with all ISO 90107 features) Three basic audio configuration Yes, configurable from web Yes, included in Plixus Core (normal, distance conferencing, server web server external equalizer) Advanced audio configuration No, but once created with...
  • Page 73: Configure Ip Settings

    CONFIGURE IP SETTINGS Before you start using the Plixus web server you need to configure your local IP settings to be able to access the web server. Follow the procedure below to configure this. To be able to access the web server your computer needs an IP address and subnet mask that can access the IP address of the engine.
  • Page 74 4. Right-click the Local Area Connection and select Properties. 5. Select Internet Protocol Version 4 (TCP/IPv4) and click Properties. 6. To assign a fixed IP address to your computer, click Advanced. CO NF IG UR E IP SETTING S...
  • Page 75: Change Ip Settings In Macos

    7. Click Add in the IP address pane. 8. Enter an IP address in the range of the engine, for example 192.168.0.26. Fill in 255.255.255.0 as subnet mask. 9. Click OK. You are now ready to access the WCAP. Change IP Settings In MacOS 1.
  • Page 76 3. Click the Advanced button. 4. Select TCP/IP in the menu on top. 5. Change Configure IPv4 to Manually. CO NF IG UR E IP SETTING S...
  • Page 77 6. Enter an IP address in the range of the engine, for example 192.168.0.25. Fill in 255.255.255.0 as subnet mask. 7. Click OK. CO NF IG UR E IP SETTING S...
  • Page 78: Getting Started With Plixus Core

    CORE Activate Plixus Core To access the web server of the Plixus system, enter the IP address of the Plixus engine in your browser. The default IP address of the Plixus engine is 192.168.0.100 with subnet mask 255.255.255.0. The first time you will need to activate Plixus Core. Go to Settings, select Info and click Start Plixus Core.
  • Page 79 Return to the home screen where you see the most important features and their configuration. Initialization Define and configure units present in the Plixus network. Discussion options Configure discussion options such as microphone to define how to activate a microphone.
  • Page 80 Users Change user name and password. System info Contains system information such as license information, system logging, (de)activation of Plixus Core and configuration management. Update versions Overview of all firmware and software version together with the option to update to another version.
  • Page 81: The Home Page

    Connection status with CoCon Room Server Connection Status with Plixus Core By default it is not possible to disconnect from Plixus Core, however when Plixus Core crashes home page will show Plixus Core Not connected. Click Restart to restart Plixus Core.
  • Page 82: Initialization

    Introduction The Plixus system always works with seats. A seat is a conceptual name for a unit or a group of units which are combined on that seat. By default this is a one-to-one mapping, so every unit has one seat. However, there can be more advanced cases where units are manually combined on a seat.
  • Page 83: How To Initialize Units

    This means that seat one is assigned to the first unit at port one of the Plixus engine. For network extenders connected to the Plixus port, seats will also start with port one of the network extender. The system automatically discovers the redundant loops.
  • Page 84 : click to swap unit. When a unit is faulty, it will be greyed out in the web server. Click the icon and enter the serial number of the new unit. Click the checkmark icon to confirm. Note that you can only replace units with units of the same type. : click to modify the unit number.
  • Page 85: Discussion Options

    DISCUSSION OPTIONS In this chapter you will find all information to configure the most important settings of your meeting. These settings are the number of open microphones, the microphone mode and the color of the microphone LED. Number Of Open Microphones You can set the number of open microphones be between 1 and 25.
  • Page 86 Parameter Description > Not-selected: microphone will not become active when the maximum Override number of open microphones is reached and you press the microphone button. Another active microphone must switch off first. Deactivation is possible by the delegate, via the operator page, through the chairman using the API or CoCon.
  • Page 87: Microphone Led

    Voice activation (VoX) is a mode where the microphone button is not used. The microphone becomes active when it detects sound above a certain threshold. You can configure Voice activation in the Group discussion mode. The following settings can be configured: Parameter Description Threshold...
  • Page 88: Recording

    With the Plixus AE-R you have the option to record meetings. You can start recording by pressing the button on the engine or by using Plixus Core. Save the recording on the integrated hard drive or to an external USB device.
  • Page 89 1. Select where to store the recording. Select Internal storage to store the recording on the engine locally or select External storage to store the files to an external USB device connected to the engine. For the internal storage you can see the remaining disk space, this depends on the audio quality you selected.
  • Page 90: Manage Recorded Files

    Manage Recorded Files Figure 1-39 How do download and remove your recorded files 1. Go to the location where your files were recorded: on the engine itself or on an external USB device. 2. You can search for specific files using the Search bar. 3.
  • Page 91: Audio Settings

    AUDIO SETTINGS On the Audio page you can configure all general audio settings for the Plixus system. General Volume This sets the volume for the loudspeakers in the room. The value can range from - 96dB to + 6dB. You can also change the volume by turning the control dial of the MME or volume dial of the AE-R.
  • Page 92: Auto Gain Reduction

    Preset Description External speakers (without Same settings as external speakers, but without the noise gate. noise gate) Figure 1-40 Figure 3 13 - Audio - Advanced dynamics settings Auto Gain Reduction Auto gain reduction reduces the amount of gain in signal in function of the amount of open microphones. As the number of open microphones causes the noise to go up, a gain reduction can increase the intelligibility.
  • Page 93: Audio Routing

    AUDIO ROUTING With audio routing you can control all routing configurations and the auxiliary levels. You can configure the following settings: Audio routing configuration Auxiliary input levels Auxiliary output levels and selection of the output channel Automatically route interpretation channels to Dante Figure 1-41 Audio routing page Audio Routing Configuration...
  • Page 94 DISTANCE CONFERENCING This adds an external signal, using AUX IN, to the local floor signal and sends the local floor signal, using AUX OUT, to a remote party, for example sitting in a different room. EXTERNAL EQUALIZER This option allows you to add an external signal processing equipment or a mixing board. AUDIO R O UTING...
  • Page 95: Auxiliary Levels

    You can use the CoCon Audio application to create additional audio routing configurations. After creation these are sent to and saved on the Plixus engine. These are then accessible from the web server, even when CoCon is not running. In contrast to the predefined configurations you can still edit these configurations.
  • Page 96: Interpretation

    INTERPRETATION On the Interpretation page you configure the languages needed for the meeting. You can add up to eleven channels. Figure 1-42 Interpretation page Add New Language To add a language configuration, click the bottom empty field in the table in the Column Name. You can define the following parameters: Parameter Description...
  • Page 97: Add Interpretation Configuration From Cocon

    Add Interpretation Configuration From CoCon Figure 1-43 How to add language configurations created in CoCon You can also configure languages in the CoCon Interpretation application. You can find these configurations in the drop down list on top of the page. Select the configuration and click Apply configuration to use it.
  • Page 98: Operator

    OPERATOR On the Operator page you can control the microphones in the meeting and see how is speaking or requesting to speak. The Operator page consists out of two parts: Figure 1-44 The Operator page List Description Shows all active microphones , all requests (only possible with Request Speakers &...
  • Page 99: Regional Settings

    Go to the Regional settings page to change the date and time format. Figure 1-45 The Regional settings page Click Push date and time of computer to Plixus to synchronize to time of your Plixus system with that of your computer. R EG IO NAL SETTING S...
  • Page 100: Network Settings

    NETWORK SETTINGS On this page you can adjust the network settings of the Plixus engine and configure the camera protocol which to sent from the Plixus engine to the camera tracking system. Here you are also able to enable the API.
  • Page 101: Rest Api

    (third-party). REST API The Plixus Core API provides a subset of commands that are available on the CoCon API. The Plixus Core API has the same communication protocol and command structure as the CoCon API which allows third- party programmers to simply change the IP address from the CoCon Room Server PC to the Plixus Engine.
  • Page 102: Users

    USERS On the Users page you can enable login. When you enable this you will have to define the user name and password. the next time you use the system you will have to give in these credentials. USER S 1 0 2...
  • Page 103: System Info

    Plixus Core Click the button to activate or deactivate Plixus Core. Use this for functions that are not possible in Plixus Core and require CoCon. The web server will switch back to the old web server and you need CoCon Room Server for all functionality.
  • Page 104 Parameter Description Import configuration When you install a new engine you can import configurations. This can be interesting in case your previous system is defective or you have multiple comparable rooms. Export your current configuration containing the following settings: Export configuration >...
  • Page 105: Couple With Confidea G3

    COUPLE WITH CONFIDEA G3 With Plixus it is possible to combine wired units with wireless ones. You can add one or more Confidea G3 WCAPs to your Plixus network simply by connecting them to one of the conference ports. For more information on the installation of the WCAPs in the Plixus network see "Install Confidea G3"...
  • Page 106: Associate Units With Wcap

    Figure 1-49 View coupled Confidea G3 WCAPs and their details Associate Units With WCAP 1. Select Initialization from the main menu. 2. Click Open initialization to associate wireless units with the WCAPs. 3. Select the radio button of the WCAP you want associate the units with. 4.
  • Page 107: Takeover Wcap

    Takeover WCAP To be able to transfer units from one WCAP to another, the WCAP you want to transfer units to can have no units already associated in Plixus. However, they can have units associated in standalone mode. Figure 1-50...
  • Page 108 1. Select Confidea G3 coupling in the main menu. 2. When there is a WCAP available to transfer units to (i.e. with no units associated in the Plixus network) you will see the button Takeover under the WCAP that can transfer units. Click the button.
  • Page 109 TE LE VIC CONFE RE NCE Leo Bekaertlaan 1 8870 Izegem Belgium +32 51 30 30 45 GET IN TOUCH...
