DROPSA Flow master User And Maintenance Manual

Volumetric flow meter for controlling the flow of liquids. manual or motorized adjustment
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
http://www.dropsa.com
FLOW MASTER
VOLUMETRIC FLOW METER
FOR CONTROLLING THE FLOW OF LIQUIDS.
MANUAL OR MOTORIZED ADJUSTMENT
User and
Maintenance Manual
Warranty information

TABLE OF CONTENTS

1.
2.
3.
4.
5.
6.
7.
MACHINE OPERATIONS
8.
9.
10.
11.
12.
13.
14.
15.
16.
17.
18.
Manual drafted in compliance with
EC Directive 98/37
C2057IE - WK 20/11

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Flow master and is the answer not in the manual?

Questions and answers

Related Manuals for DROPSA Flow master

Summary of Contents for DROPSA Flow master

  • Page 1: Table Of Contents

    FLOW MASTER VOLUMETRIC FLOW METER FOR CONTROLLING THE FLOW OF LIQUIDS. MANUAL OR MOTORIZED ADJUSTMENT User and Maintenance Manual Warranty information TABLE OF CONTENTS INTRODUCTION GENERAL DESCRIPTION PRODUCT-MACHINE IDENTIFICATION TECHNICAL CHARACTERISTICS MACHINE COMPONENTS UNPACKING AND INSTALLING THE MACHINE MACHINE OPERATIONS...

  • Page 2: Introduction

    1. INTRODUCTION This manual refers to FLOW MASTER volumetric flow device. You can find additional copies and newer revisions of this document from our website http://www.dropsa.com. Alternatively contact one of our Sales Offices. This User and Maintenance Manual contains important information on health and safety issues for the personnel.

  • Page 3: Technical Characteristics

    4. TECHNICAL CHARACTERISTICS Base and metering module Fluid maximum viscosity 1000 cSt (4628 SUS) (at lubricant operating temperature) Operating temperature -20 C ÷ +60 C (-4 °F ÷ +140 °F) Minimum pressure 6 bar (88.2 psi) (continuous working) Maximum pressure 20 bar (294 psi) (intermittent working;...

  • Page 4: Machine Components

    WARNING: All the electric, electronic components, reservoirs and base structure must be grounded. The stainless steel option makes the FLOW MASTER suitable for applications in harsh, damp or corrosive environments. Connect inlet (par. 11.3, fig.1, pos. J) and outlet (par. 11.3, fig.1, pos. K) piping.

  • Page 5: Troubleshooting

    (see machine parts drawing, par. 11.3) 9. MAINTENANCE PROCEDURE FLOW MASTER has been designed and constructed to require a minimum of maintenance. For an easy maintenance, it is advised to assemble the machine in an adequate location. To facilitate maintenance tasks without interrupting the operation of the machine, it is recommended to provide the flow meter with an input ball valve to disconnect parts of the system.

  • Page 6: Disposal

    The machine does not require any special tool for check or maintenance tasks. However, it is recommended the use only of appropriate and in good conditions tooling, protective devices (gloves) and clothing (626/94 and DPR 547/55) to avoid injury to persons or damage to machine parts.
  • Page 7 11.3 Spare parts Connector for pipe, Connector for pipe, Connector with check valve, complete with nut and ring complete with nut and ring complete with nut and ring Part N° Part N° Part N° Ø Ø Pipe Ø Pipe Pipe stainless steel aluminium stainless...

  • Page 8: Dimensions

    12. DIMENSIONS Depth “X” Module metering “A” 2.36 “B“ 67.5 2.65 “C“ 3.22 12.1 Manual FLOW MASTER 12.2 Motorized FLOW MASTER...

  • Page 9: Handling And Transportation

    FLOW MASTER does not produce excessive noise, less than 70 dB(A). 15. PRECAUTIONS No particular operating hazards characterize the FLOW MASTER, except for the following precautions: Operator’s contact with lubricant during maintenance tasks: The operator must be provided with suitable personal protective clothing and devices...

  • Page 10: Warranty Information

    16. WARRANTY INFORMATION All products manufactured and marketed by Dropsa are warranted to be free of defects in material or workmanship for a period of at least 12 months from date of delivery. Extended warranty coverage applies as follows: Complete system installation by Dropsa: 24 Months All other components: 12 months from date of installation;...

  • Page 11: Declaration Of Compliance With Standards

    Via Besana,5 / Dropsa S.p.A. au Siège Social à Milan, Via Besana,5/ Dropsa S.p.A., Sitz in Milano, Via Besana 5/ La sociedad Dropsa S.p.a., con sede legal en Milán, Via Besana,5/ A Dropsa S.p.A, com sede em Milão, via Besana, nº 5 DICHIARA /CERTIFIES / CERTIFIE/ ZERTIFIZIERT, DASS/ DECLARA/ CERTIFICA: che la macchina denominate/that the machine named / que la machine dénommée/ Die Maschine mit...

  • Page 12: Dropsa Locations

    E-mail: sales@dropsa.it (Export) Fax: (+33) 01 39 86 26 36 E-mail: vendite@dropsa.it (National) E-mail: salesfr@dropsa.com Dropsa (UK) Ltd Dropsa do Brazil Ind. E Com. Ltda Unit 6, Egham Business Village, Rua Sobralia 175, Egham,Surrey,TW20 8RB Sao Paulo, Brazil Tel: (+44) 01784 - 431177...
