- Page 1 FRONT BUMPER 15-16 FORD F150 ECO-SERIES PART # FD-19336 Body Armor 4x4 272 Corporate Terrace St. Corona, CA 92879 951-808-0750 Customer Service hours: M-TH: 7:30am to 4:30 PM Pacific Time Friday: 8 AM – Noon Pacific Time...
-
Page 2: Parts List
FRONT BUMPER 2015-16 FORD F150 PARTS LIST: Front Bumper Assembly 8mm Lock Washers Driver/left “L” Bracket (center LED light) 8mm Hex Nuts Passenger/right “L” Bracket (center LED light) 6mm x 20mm Button Head Bolts License Plate Bracket 6mm x 18mm x 1.6 Flat Washers Plastic Plugs for license plate mount 6mm Nylon Lock Nuts 8-1.25mm x 25mm Hex Bolts... - Page 3 FRONT BUMPER 2015-16 FORD F150 8. Level and adjust the bumper and fully tighten all hardware. 9. On models with bolt on frame extensions, remove the extensions from outside of frame, (Figure 9). 10. If front license plate is required, attach the License Plate Bracket to the holes in the bumper with the included (2) 6mm x 20mm Button Head Screws, (4) 6mm Flat Washers and (2) 6mm Nylon Lock Nuts.
- Page 4 FRONT BUMPER 2015-16 FORD F150 Driver Side Installation Pictured Front Front (Fig 3) Unplug and move factory wiring harness for fog lights (if equipped) (Fig 4) Remove factory hex nut (arrow) from back of bumper bracket WARNING! Do not remove bumper bolts unless the bumper is properly supported on blocks or stands or the bumper may fall.
- Page 5 FRONT BUMPER 2015-16 FORD F150 Driver Side Installation Pictured Factory Bolt Plate WARNING! Do not crawl under bumper unless the bumper is properly supported on blocks or stands or the bumper may fall. Passenger/right frame mounting flange Front (Fig 7) Insert double bolt plate into mounting plate on back of Bumper Reuse factory bumper bolt and nut...
- Page 6 FRONT BUMPER 2015-16 FORD F150 Driver Side Installation Pictured (2) 8mm x 16mm Hex Bolts (2) 8mm Lock Washers (2) 8mm Flat Washers Front Right “L” Front Bracket Left “L” (Fig 11) Remove block off plates if desired- Bracket highly recommended for ecoboost models (Fig 12) Example of Front center light installation...
