- Page 1 ECO-SERIES REAR BUMPER 2015-2016 FORD F150 (accommodated factory hitch receiver) PART # FD-2962 Body Armor 4x4 272 Corporate Terrace St. Corona, CA 92879 951-808-0750 Customer Service hours: M-TH: 7:30am to 4:30 PM Pacific Time Friday: 8 AM – Noon Pacific Time...
- Page 2 ECO-SERIES REAR BUMPER 2015-2016 FORD F150 PARTS LIST: LD1 Rear Bumper Assembly 10mm x 35mm Double Bolt Plates 10mm x 30mm x 2.5mm Flat Washers Driver/left Mounting Bracket 10mm Nylon Lock Nuts Passenger/right Mounting Bracket 4mm x 10mm Button Head Bolts Plastic Plugs for license plate mount Sensor Hole Plugs 2.5mm Wrench...
- Page 3 ECO-SERIES REAR BUMPER 2015-2016 FORD F150 c. Repeat the above steps for remaining light installation. d. Follow light manufacturer’s instructions for adjustment and to properly wire the light to the vehicle electrical system after Bumper installation. 5. Reinstall the license plate lights and trailer plug, (Figure 6). NOTE: Use a flat blade screwdriver to carefully pry the metal clips on the plug out to grab the edge of the opening.
- Page 4 ECO-SERIES REAR BUMPER 2015-2016 FORD F150 the vehicle, do not proceed until the bumper is fully and safely supported. Snug but do not fully tighten hardware at this time. Skip to Step 9. 9. Level and adjust the bumper and fully tighten all hardware including the Mounting Bracket to Bumper hardware.
- Page 5 ECO-SERIES REAR BUMPER 2015-2016 FORD F150 Passenger Side Installation Pictured WARNING! Do not remove bumper bolts unless the bumper is properly supported on Rear blocks or stands or the bumper may fall. (Fig 3B) Remove the factory hex nuts attaching bumper assembly to frame. STD tow Rear package model pictured (no receiver hitch) (Fig 4) Passenger side of frame...
- Page 6 ECO-SERIES REAR BUMPER 2015-2016 FORD F150 Passenger Side Installation Pictured (2) 4mm Screws IMPORTANT: Sensors fit snug in sockets. The 4mm Screws are only used to apply slight pressure to lock the sensors in place. Tighten both screws evenly until they touch the sensor body only.
- Page 7 ECO-SERIES REAR BUMPER 2015-2016 FORD F150 Passenger Side Installation Pictured (2) 10mm Flat Washers (2) 10mm Nylon Lock Nuts 10mm Plastic Retainer WARNING! Do not crawl under bumper unless the bumper is properly supported on Rear blocks or stands or the bumper may fall. (2) 10mm Flat Washers (2) 10mm Nylon Lock Nuts 10mm Plastic...
- Page 8 ECO-SERIES REAR BUMPER 2015-2016 FORD F150 Passenger Side Installation Pictured WARNING! Do not crawl under bumper unless the bumper is properly supported on blocks or stands or the bumper may fall. (2) 10mm Flat Washers (2) 10mm Nylon Lock Nuts Rear (Fig 15) Reinstall integrated receiver hitch/bracket assembly on models with “HD Towing”...
