Note: Herculite Door Bracket (HDB) is to be used with glass doors.
1
INSTALL HDB BRACKET
1a
Select Appropriate Shim
HDB
Bracket
Glass
2
PREPARE FRAME
2a
Tape Template on HDB Bracket and Frame
• Align armature hole on template with armature hole in
HDB bracket
• Prepare frame holes per template
Armature
hole
© 2010 Ingersoll-Rand Company
1-877-671-7011
23737901 Rev. 10/10_a
for M400 Series Electromagnetic Locks
OR
Shim with
Compression
Pad
Single Door
HDB Kit
1b
Install HDB Bracket
• Install appropriate shim (padded side toward glass)
• Tighten set screws (³⁄₃₂" hex wrench included)
Shim with compression pad to be installed on top of glass
opposite the hinge side with the hole for the armature facing
toward the "push" side of the opening.
Armature
holes
Installation
Instructions
Set Screws
Double Door
