Hubbard Systems Scotsman AF 124 Installation Manual

Self-contained flakers electronic

Scotsman Self-Contained Flakers (Electronic)

Installation Guide for Scotsman Flaker

Table of Contents

Need help?

Do you have a question about the Scotsman AF 124 and is the answer not in the manual?

Page 1 Installation Guide for: Scotsman Self-Contained Flakers (Electronic) Installation Guide for Scotsman Flaker...
Page 2 Unpacking • Remove the two banding strips securing equipment to pallet. • Remove cardboard carton and packaging material. • Inspect exterior of machine for any potential damage. Open bin door and remove: • 1 x water inlet tube • 1 x drain tube complete with clip •...
Page 3 Check the following: • Ambient temperature - minimum 10°C, maximum 40°C • Adequate space at rear of machine for water and drain connections. • Minimum airflow clearance requirement of 15cm to both sides of machine. Note: If clearance is less, ice production rate will decrease by as much as 25% due to potential overheating.
Page 4 Hubbard Ice Technical Department in the first instance. NOTE - The above procedures are designed to supplement guidance given in the user handbook, not replace it. HTG Trading Ltd (Hubbard Systems) Unit 106 Claydon Business Park Great Blakenham Ipswich...
