Installation and Configuration Guide
P/N: 709C001208
REV: A0
Date: 08-FEB-09

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 2000 and is the answer not in the manual?

Questions and answers

Related Manuals for MobileAccess 2000

Summary of Contents for MobileAccess 2000

  • Page 1 Installation and Configuration Guide P/N: 709C001208 REV: A0 Date: 08-FEB-09...
  • Page 2 Preface MobileAccess 8391 Old Courthouse Road, Suite 300, Vienna, VA 22182 Tel: +1(866)436-9266, +1(703)848-0200 TAC: +1(800)787-1266, Fax: +1(703)848-0280 http://www.MobileAccess.com © C 2009, M OPYRIGHT OBILE CCESS ETWORKS IGHTS ESERVED ™ OBILE CCESS IS A REGISTERED TRADEMARK OF OBILE CCESS HIS DOCUMENT CONTAINS OTHER TRADEMARKS...
  • Page 3 RESPECT TO ANY GOODS, PARTS AND SERVICES PROVIDED IN CONNECTION WITH THIS AGREEMENT INCLUDING, BUT NOT LIMITED TO, THE IMPLIED WARRANTIES OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE. MOBILEACCESS SHALL NOT BE LIABLE FOR ANY OTHER DAMAGE INCLUDING, BUT NOT LIMITED TO, INDIRECT, SPECIAL OR CONSEQUENTIAL DAMAGES ARISING OUT OF OR IN CONNECTION WITH FURNISHING OF GOODS, PARTS AND SERVICE HEREUNDER, OR THE PERFORMANCE, USE OF, OR INABILITY TO USE THE GOODS, PARTS AND SERVICE.
  • Page 4 CONNECTORS UNCOVERED WHEN NOT CONNECTED HE TIP OF THE FIBER OPTIC CONNECTOR SHOULD NOT COME INTO CONTACT WITH ANY OBJECT OR DUST EFER TO THE CLEANING PROCEDURE FOR INFORMATION ON THE CLEANING OF THE FIBER TIP MA 2000 Installation and Configuration Guide...
  • Page 5 Compliance with RF safety requirements: • MobileAccess™ products have no inherent significant RF radiation. • The RF level on the downlink is very low at the downlink ports. Therefore, there is no dangerous RF radiation when the antenna is not connected.
  • Page 6 Preface Standards and Certification MobileAccess products have met the approvals of the following certifying organizations: Product Certifications FCC 47 CFR part 15B, 22, 24, 90 UL 60950-1 21CFR 1040.10 & 1040.11. Europe EN 301502, EN 300609, EN 301489, EN 60950-1, IEC 60825-1, IEC 60825-2...
  • Page 7 RIU Installation and Configuration Guide NMS MA 410/430 Installation and Configuration Guide MA1000 MA2000 Commissioning Guide List of Acronyms Bi-Directional Amplifier Base Transceiver Station BTSC Base Transceiver Station Conditioner Base Unit Downlink Remote (Hub )Unit Radio Interface Unit MA 2000 Installation and Configuration Guide...
  • Page 8 Preface Uplink VIII MA 2000 Installation and Configuration Guide...

  • Page 9: Table Of Contents

    2.1.2.1 Enclosure Internal Elements................10 2.1.2.2 Digital Card Unit ....................11 2.1.2.3 Filters and Combiners..................12 2.2 MA 2000 Remote Location Units ....................12 2.2.1 RU 2000 ........................12 2.2.2 MA 1200 Add-on......................14 2.2.3 8 x 4 Combiner......................16 2.2.3.1 MA 8x4 Combiner Front Panel ................
  • Page 10 5.2.1 Typical Asian Configuration: Cell/DCS+ UMTS ..............47 5.2.2 Typical European & Middle East Configuration: EGSM/DCS + UMTS Configuration ....47 5.2.3 iDEN..........................48 5.3 2000 Lite Cell/DCS and GSM/DCS Config for Telstra ..............49 Appendix : System Specifications ...................50 RF Parameters ..........................50 System Specs ..........................
  • Page 11 Preface Specifications of Units ........................55 MA 2000 MRC Remote Hub ...................... 55 MA 2000 Lite .......................... 55 MA 2000 Remote Unit ......................55 MA 1200 Add-On Specifications ....................55 Base unit Specifications ......................56 Ordering Information ........................56 MA 2000 Installation and Configuration Guide...
  • Page 12 MobileAccess™-2000 series provides enterprise level indoor coverage, of a wide range of multi-operator wireless services over a single broadband infrastructure. Front-end wireless RF services are routed, over optic fibers, to MA 2000 series hubs that are securely located in remote telecommunication closets at each remote location. These modular service aggregation platforms precisely combine multiple wireless service signals for simultaneous distribution over a common broadband infrastructure.

  • Page 13: Introduction To The Ma 2000 System

    Conditioning and monitoring of input RF signals at the head-end through interface to MA-RIU NOTE: MobileAccess is in the process of transition to 2000M products that will support both singlemode fiber and multimode fiber. The new Base Unit is designated by WBM (Wide Band M), and the new RHUs will where the suffix “M”...
  • Page 14 Introduction to the MA 2000 System System Architecture For end-to-end control, controllers installed at the head-end provide direct interface to the MA elements and through them, control over the remote end elements. Figure 1-2. System Architecture Figure 1-2 shows a basic block diagram of the system operation. On the downlink, services from the BTS/BDA are transferred via interface to the Base Units (BUs).

  • Page 15: Application Examples

    Introduction to the MA 2000 System Application Examples Application Examples Figure 1-3 shows an example of an MA 2000 Cabinet based solution. Five services from two different operators are distributed, where services from Operator A conflict with those from Operator B.
  • Page 16 The converted optical signal is routed from the BUs directly to the corresponding RUs over optic fiber. Services 1 and 2 are distributed through one of the RUs supported by MA 2000 Lite. Services 3 and 4 are distributed through the second RU. The combiner and filter provides interface to the antennas.

  • Page 17: Ma 2000 System Elements

    MA 2000 Cabinet supports the following functions: • Compactly houses up to five RU 2000 and MA 1200 modules and the required filters NOTE: The number of modules that can be housed depends on the models, required filtering, etc. •...
  • Page 18 Supplied in two models with differing power supply: • Integrated power supply – fed from an external AC power source. The RU 2000 an MA 1200 Add-on modules are internally connected to the power supply. This model includes a battery connection as well.
  • Page 19 MA 2000 System Elements Enclosure Types The following image shows the MA 2000 RC with the cabling. The antenna ports of the individual modules are connected to the relevant filters and to the 8x4 Combiner. The PS connections of each module are also connected to cables that are internally routed to the integrated PS (a full detailed description of the connections is provided in chapter 5 ).

  • Page 20: Ma 2000 Lite

    MA 2000 System Elements Enclosure Types 2.1.2 MA 2000 Lite The 2000 Lite is designed to support up to 8 voice services, in addition to 802.11 data services. MA 2000 Lite To RU 2000 front panel Connections to RU Control...

  • Page 21: Enclosure Internal Elements

    8x4 Combiner (see section 2.2.3 for description) • Digital Card unit (see 2.1.2.2). • Filters and Combiners (see 2.1.2.3). Rear tab Filters and combiners Digital module 8x4 Combiner Front tabs Figure 2-5. MA 2000 Lite Internal Units MA 2000 Installation and Configuration Guide...

  • Page 22: Digital Card Unit

    Enclosure Types 2.1.2.2 Digital Card Unit NOTE: This unit is internal to the MA 2000 Lite system. The Digital unit enables antenna monitoring. It is connected to the 8x4 Combiner and to each of Remote Units. Digital Unit Front Panel The front panel of the unit contains the power connector.

  • Page 23: Filters And Combiners

    NOTE: The MA 850/860 is described in detail in the MA 850/860 Configuration and Installation guide. 2.2.1 RU 2000 RU 2000 is a service specific module that is either housed in the MA 2000 Cabinet or connected externally to the MA 2000 Lite module. It provides the following functions: •...
  • Page 24 MA 2000 Remote Location Units RU 2000 Front Panel The RU 2000 front panel contains the fiber optic connections to the BU, four coax connections to the antennas, power connections and status indicators. The RU 2000 front panel contains the fiber optic connections to the BU, four coax connections to the antennas, power connections and status indicators.

  • Page 25: Ma 1200 Add-On

    The MobileAccess 1200 Add-on module is used to provide support for an additional service to an MA 2000 RU. The host MA RU and the MA 1200 add-on are interconnected and either housed in a MA 2000 Cabinet or connected externally to a MA 2000 Lite ‘enclosure’.
  • Page 26 MA service personnel). The figure below shows the MA 1200 front view. It is followed by a description of the connections and LEDs. Maintenance Power Figure 2-11. RU 1200 Front panels Table 2-3. MobileAccess 1200 Front Panel Connectors Description RS232 Servicing connector to be used by MA service personnel for maintenance.

  • Page 27: X 4 Combiner

    MA 2000 System Elements MA 2000 Remote Location Units MA 1200 Rear Panel The RU 1200 rear panel contains the control connectors and the RF connections to the RU 2000 and MA 850/860. High Band Figure 2-12. RU 1200 Rear Panel Table 2-5.

  • Page 28: Ma 8X4 Combiner Front Panel

    The rear panel of the unit contains four low-band and four high-band ports as well as the control port. Control Ports 1-4: Low Band connectors Ports 5-8: High Band connectors Figure 2-14. 8x4 Combiner Rear Panel Continued on the following page MA 2000 Installation and Configuration Guide...

  • Page 29: Ma Base Unit

    The BU (Base Unit) is a wideband device that performs the conversion between the BTS/BDA (passive or active) interface RF signal and the remote units optic signal. Base Unit capabilities • Supports all services distributed by MobileAccess systems • Fiber connection to up to 8 RUs •...

  • Page 30: Bu Panels

    ON - laser circuitry for the corresponding element (group of four ports) is functioning correctly. Link 1-4, 5-8 ON - the optical link to/from the connected remote functions within the specifications in both directions. Blinking - optical power from remote is lower than required MA 2000 Installation and Configuration Guide...

  • Page 31: Bu Rear Panel

    Alarms dry-contact connections for interface to BTS Power connector Figure 2-17. MA BU Rear Panel (RF Connections) Table 2-7. MobileAccess 1000 Rear Panel Connections Connector Description Uplink output Uplink connectors to be connected on BTS/BDA side. For an 8-port BU, both UL connectors must be connected.

  • Page 32: Site Preparation

    B. Telecom Closet Planning: Planning the layout of the devices and cables in the telecom closet or shaft. This includes the MA 850/860, 802.11 Access Points, cabling and other voice service distribution systems that are relevant to the specific installation. MA 2000 Installation and Configuration Guide...

  • Page 33: Coaxial Cable Connections

    3.3.2 Fiber Optic Rules • Either single mode or multimode fiber can be used with MobileAccess 1000M products, while MobileAccess 1000 products can only be used with single mode fiber. • Only Multimode fiber, 50/125 or 62.5/125um complying with ANSI/TIA/EIA-568-B series, EN50173-1 or ISO/IEC 11801 can be used.

  • Page 34: Rf Rules

    Use coax RG223, 50ohm, male-to-male N-type for RF connections from the BUs to the BTS/RBS and to the RIU. • When using the MobileAccess™ system in an environment in which other indoor coverage systems are installed, it is recommended (where possible) that the antennas are placed at least two meters apart •...

  • Page 35: Coax Cable Lengths And Losses

    100 ft is required; if there are partitions (loss) between the antennas, a distance of less than 100 ft between them is allowed. Coax Length coax Loss (900Mhz) connector loss Total Loss MA 2000 Installation and Configuration Guide...

  • Page 36: Power Consumption, Connections And Power Supplies

    Be sure to disconnect all power sources before servicing. • MA 410/430 Controller lithium type battery should only be replaced by MobileAccess service personnel. Risk of exploding if battery is replaced by an incorrect type. Dispose of used batteries according to the instructions.

  • Page 37: Circuit Breakers

    2A circuit breaker. 3.4.4 Types of Power Supplies MobileAccess supplies various power supplies that can be installed in a rack or mounted on a wall, depending on your configuration. NOTE: Refer to Appendix II, section 0 for list of power supplies.
  • Page 38 When power cables require distances greater than 1000 feet 14 or 16 gauge wire may be used. • On each floor - the antennas are connected to the Remote Cabinet or 2000 Lite system using coax cables. MA 2000 Installation and Configuration Guide...

  • Page 39: System Installation

    Unpack and inspect the cartons according to the following procedure 1. Open the shipping carton and carefully unpack each unit from the protective packing material. 2. Check for signs of external damage. If there is any damage, call your MobileAccess service representative. MA 2000 Installation and Configuration Guide...

  • Page 40: Communication Room Installation

    If the site is serviced by more than one operator, each operator often installs their equipment in a separate rack. NOTE: Note that the MobileAccess 430 controller is at eye level to provide an easy view of the LED indicators and LCD display and easy access to the local and remote monitoring connections.

  • Page 41: Rack Installation Safety Instructions

    This section describes the installation for the Base Units with the RF signal supplied from an MA RIU Lite. If an RIU system is installed, refer to the RIU Installation and Configuration Guide for detailed instructions on the RIU connections. MA 2000 Installation and Configuration Guide...
  • Page 42 4. Connect the BU rear panel COM to the MA 430 rear panel RS485 connector. 5. Connect the Power connection on the BU rear panel. The following figure shows the BU connections to an RIU Lite and MA 410/430 controller. Figure 4-3. BU Rear Panel Connections MA 2000 Installation and Configuration Guide...

  • Page 43: Remote Cabinet Installation

    General Installation Instructions • The MA 2000 Remote Cabinet units should be installed in a communication room that provides access to authorized personnel only. The units are maintenance free. In the event of failure, only authorized personnel should handle the units.
  • Page 44 System Installation Remote Cabinet Installation The wall installation 2000 Remote Cabinet is supplied with a plate that is to be mounted on the wall and a bracket that is assembled on the rear of the MA 2000 system. Mounting Bracket...
  • Page 45 3. Mount the Plate on the wall. Carefully and thoroughly fasten the anchors to the wall. 4. Assemble the Bracket onto the rear of the Remote Cabinet using the supplied screws. 5. Lift the MA 2000 RC and guide the rear ledge of the assembled bracket onto the plate bracket.

  • Page 46: Rc Grounding - Integrated Ps Wall Mount Model

    NOTE: This procedure is only necessary for wall mount integrated power supply configuration (for other configurations this procedure is optional). The Ground screw is located at the rear of the unit. Figure 4-7: Grounding Located at the Rear of the Unit MA 2000 Installation and Configuration Guide...

  • Page 47: Rc 2000 Rack Mount Installation

    NOTE: The cabinet requires a clearance of 10 cm above the unit. If a heating source is installed beneath the MRC, a buffer must be placed between the cabinet and the surface. The following figure provides the dimensions for the MA 2000 Rack Model. Figure 4-8. MA 2000 Cabinet Rack Mount Assembly...
  • Page 48 The MA 2000 RC Rack Mount model is supplied with the required brackets already assembled to the sides of the cabinet as illustrated in the Figure 4-9 . MA 2000 RC Rack Model. Simply, mount the MA 2000 RC in the rack and secure with the supplied screws.

  • Page 49: Fiber Optic Connections

    1. Install splice box near Remote Cabinet. 2. Connect fiber optic cable to splice box and the SC/APC pigtails to each RU 2000 module. 3. For the downlink, connect the fiber optic cable pigtails from splice box coming from the BU port to the corresponding RU port (routing the optic fibers so they will fit through the top opening in the door.)

  • Page 50: Power Connections

    4.3.6 Antenna Connections without • For systems MA 850/860 modules - connect the antenna connections to the RC antenna ports MA 850/860 Installation Manual • For systems with MA 850/860 modules - refer to MA 2000 Installation and Configuration Guide...

  • Page 51: Ma 2000 Lite Installation And Connections

    MA 2000 Lite Installation and Connections MA 2000 Lite Installation and Connections MA 2000 is designed as a wall-mount installation – usually located in the communication shaft of the corresponding floor. The remote units are mounted externally to the 2000 Lite device and their antenna outputs are connected to either side of the 2000 Lite device.
  • Page 52 System Installation MA 2000 Lite Installation and Connections The following figure shows the RIU Lite mechanical drawing Figure 4-13. MA 2000 Lite Mechanical Dimensions MA 2000 Installation and Configuration Guide...

  • Page 53: Mounting Ma 2000 Lite

    4.4.1 Mounting MA 2000 Lite In order to mount MA 2000 Lite on the wall, the cover is first removed, the tray and all installed elements are secured to the wall and the top cover assembled again. 1. Remove the top cover by pulling it towards the rear bracket and lifting it over the front brackets.

  • Page 54: Ma 2000 Lite Connections

    System Installation MA 2000 Lite Installation and Connections 4.4.2 MA 2000 Lite Connections This section describes the MA2000 Lite enclosure and its' external connections. (2) Power (4) To RU 2000 Connections to RU 2000 front front panel RS232 panel RS232 and antenna...

  • Page 55: Upgrading And Configuration Examples

    NOTE: It is required to order an Accessory Kit for each new unit to be added to the installation. The kit includes cables for connecting the RU 2000 or MA 1200 add on units to the required filters. Because of the differences in cable length requirements, the accessory kit differs for units designated to be installed in 2000 Cabinets and for those designated to be installed with MA 2000 Lite systems.

  • Page 56: Common Usa Configurations

    The following figure describes the port connections between the remote units, add-on, and 8x4 Combiner. iDEN DL Add-on RHU 2000 SMR DL and iDEN UL 1200 8x4 P3 iDEN/SMR N.C. iDEN/SMR 8x4 P2 SMR UL Cavity Duplexer 8x4 P6 Figure 5-1. iDEN/SMR and PCS Connections MA 2000 Installation and Configuration Guide...

  • Page 57: Cell/Pcs

    For infrastructures supporting two Cell bands and a PCS band, connect the second Cell/PCS services RU according to the following figure. Cavity Cell DL RHU 2000 Cavity CELL/PCS 8x4 P4 Cell Duplexer N.C. 8x4 P8 Figure 5-3. Additional Cell/PCS Connections MA 2000 Installation and Configuration Guide...

  • Page 58: Typical International Configurations

    Upgrading and Configuration Examples Typical International Configurations Typical International Configurations MA 2000 Lite supports Cell/DCS and DCS. UMTS support can be added through MA 1200 Add-on. 5.2.1 Typical Asian Configuration: Cell/DCS+ UMTS Figure 5-4. Cell/DCS and UMTS Configuration 5.2.2 Typical European & Middle East Configuration: EGSM/DCS + UMTS Configuration Figure 5-5.

  • Page 59: Iden

    Upgrading and Configuration Examples Typical International Configurations 5.2.3 iDEN iDEN support is provided through MA 2000 Cabinet configurations. RHU 2000 Cavity iDEN DL BPF iDEN to 8x4 P6 to 8x4 P2 5-6. iDEN Configuration MA 2000 Installation and Configuration Guide...

  • Page 60: 2000 Lite Cell/Dcs And Gsm/Dcs Config For Telstra

    Upgrading and Configuration Examples 2000 Lite Cell/DCS and GSM/DCS Config for Telstra 2000 Lite Cell/DCS and GSM/DCS Config for Telstra MA 2000 Installation and Configuration Guide...

  • Page 61: Appendix : System Specifications

    RF Frequency Range Services Frequency Range Uplink Downlink CELL 824-849 869-894 iDEN 806-824 851-869 890-915 935-960 E-GSM 880-915 925-960 Telstra 850M 824-849 869-890 896-902 929-941 1710-1785 1805-1880 1850-1910 1930-1990 G-PCS 1850-1915 1930-1995 UMTS 2100 1920-1980 2110-2170 MA 2000 Installation and Configuration Guide...
  • Page 62 8 carriers 12 carriers Mean Gain(dB)* Pin (dBm)* Input IP3 (dBm) AGC OFF Min Input IP3 (dBm) AGC ON Min SFDR** (dB) Max Intermod Distortion (dBm) Max Nf (dB) Gain Flatn. (dB) ± 2.0 MA 2000 Installation and Configuration Guide...
  • Page 63 8 carriers 12 carriers Mean Gain(dB)* Pin (dBm)* Input IP3 (dBm) AGC OFF Min Input IP3 (dBm) AGC ON Min SFDR** (dB) Max Intermod Distortion (dBm) Max Nf (dB) Gain Flatn. (dB) ± 2.0 MA 2000 Installation and Configuration Guide...
  • Page 64 *Factory set mean gain BU-RHU without RIU. May be field adjusted using system controller. SFDR for CDMA services is calculated in 100Kb/sec *** UMTS Compiles with 3GPP TS 25.106 V5.0.0 (2002-03) Table 9.4 spectrum emission mask MA 2000 Installation and Configuration Guide...

  • Page 65: System Specs

    Total Input RF Power to BU 10dBm 20dBm out-of-band Total Input RF Power to RU -10dBm in-band Power Supply VDC 60VDC Temperature Specifications Operating 0°C to +50°C (32°F to 122°F) Storage -20°C to 85°C (-4°F to 185°F) MA 2000 Installation and Configuration Guide...

  • Page 66: Specifications Of Units

    : Single service corresponding to the model RF Connections: : To RHU - SMA 50 ohm Power: Input power : 25-48VDC Power consumption : 50W Remote management : SNMP, NMS via RHU connection Dimensions 27.9x22.0x6.9cm (10.98”x8.66”x2.71”) Weight 2.8Kg (6.2 lb) MA 2000 Installation and Configuration Guide...

  • Page 67: Base Unit Specifications

    Dual band GSM/DCS 1 port for Lite, enhanced power 2000-GSMO-DCSEL Dual band GSM DCS 1 port for Lite, enhanced power 2000-IDEN-SMR-L Dual band iDEN/SMR for Lite Dual band Cell/DCS 1 port for Lite enhanced power for Telstra MA 2000 Installation and Configuration Guide...
  • Page 68 2000-GSM-DCSLT MobileAccess 1200 Add On 1200-PCS-AO-CB Add-on RHU - PCS service for cabinet 1200-G-PCS-AO-CB Add-on RHU supporting a PCS w/G-block for 2000 cabinet 1200-UMTSE-AO-CB Add-on RHU - UMTS service for cabinet 1200-PCS-AO-LT Add-on RHU - PCS service for Lite 1200-UMTSE-AO-LT...
  • Page 69 LPS-48V-66W Local AC/DC Converter 66W LPS-48V-100W Local AC/DC Converter 100W AK-PWR-CORD-EU AC Power cord for 66W & 100W power supplies, European connector AK-PWR-CORD-UK AC Power cord for 66W & 100W power supplies, UK connector MA 2000 Installation and Configuration Guide...
  • Page 70 This page is intentionally left blank…...
