SM-1621U
DJ MIXER
WITH USB/SD/MP3 PLAYER
N Instruction manual

Advertisement

Table of Contents
loading

Related Manuals for FONESTAR SM-1621U

Summary of Contents for FONESTAR SM-1621U

  • Page 1 SM-1621U DJ MIXER WITH USB/SD/MP3 PLAYER N Instruction manual...
  • Page 2 We take this opportunity to thank you for buying this product. We recommend you read the instruction manual before switching on the machine and follow the instructions that are given. Keep the manual for future reference. SECURITY AND THE ENVIRONMENT ELECTRICAL SECURITY Check that the current in the mains connection where the machine is to be installed corresponds to the power supply of the machine.

  • Page 3: Exemption Of Liability

    The characteristics of the equipment and the content of the manual can change without forewarning. FONESTAR, S.A. does not assume responsibilities regarding the inappropriate use of the equipment or the information supplied in this instruction manual, and specifically disclaims any implied liability for marketability or fitness for any other use.

  • Page 4: Controls And Functions Front Panel

    DESCRIPTION The SM-1621U model is a professional stereo mixer with 6 inputs, 3 channels and 2 outputs with independent volume controls for DJ use. MP3 player with LCD display that shows ID3 information in MP3 files, with USB port for USB memory connection and SD/MMC card reader.
  • Page 5 source for channel 3. 5.- Sliding volume control for the level of the corresponding channel. 6.- TALKOVER: button for activating/deactivating the talk over function in channel 1. This function weakens the signal in the rest of the channels in the general mix. When activated the LED indicator lights up. 7.- REVERSE: for reversing the variation curve from the crossfader.

  • Page 6: Back Panel

    BACK PANEL 1.- POWER: equipment on/off switch. 2.- AC socket: for connecting the AC power supply cable. 3.- MASTER L/R: balanced output for the corresponding MASTER line level to the final mix, 2 x XLR connectors. 4.- MASTER: unbalanced output for the corresponding MASTER line level to the final mix, 2 x RCA connectors.
  • Page 7 Connect the equipment to the power supply. Switch the equipment on in the correct order: players, SM-1621U mixer and lastly the amplifier. Adjust the input level for each channel with the GAIN control and mix with the volume controls for each channel.

  • Page 8: Block Diagram

    BLOCK DIAGRAM - 8 -...

  • Page 9: Specifications

    SPECIFICATIONS SM-1621U CHARACTERISTICS Professional mixer with 6 inputs, 3 channels and 2 outputs with independent volume controls. USB/SD/MP3 player. USB PLAYER MP3 file player USB port for USB drive connection SD/MMC card reader Accepts drives of up to 8 GB...

  • Page 10: Declaration Of Conformity

    2 months after being conscious of the problem. It is only necessary to contact FONESTAR if it is impossible or imposes an undue burden for them to solve it.
