OWNER'S MANUAL
L A W N S W E E P E R
MODEL:
S T S - 4 2 B H D K
US PATENT 6,640,532
• Assembly
• Installation
• Operation
• Repair Parts
For use with Riders and
Lawn/Garden Tractors
Visit us on the web!
www.brinly.com
Important: This manual contains information for the safety of persons
and property. Read it carefully before assembly and operation
of the equipment!
1018189 Rev. C
Advertisement
Related Manuals for Brinly STS-42BHDK
Summary of Contents for Brinly STS-42BHDK
- Page 1 • Operation • Repair Parts For use with Riders and Lawn/Garden Tractors Important: This manual contains information for the safety of persons Visit us on the web! and property. Read it carefully before assembly and operation www.brinly.com of the equipment! 1018189 Rev. C...
-
Page 2: Table Of Contents
Sweeper. CUSTOMER RESPONSIBILITIES - Please read & retain this manual. The instructions will enable to assemble and maintain your Sweeper properly. - Please carefully read and observe the SAFETY SECTION of this manual. - Follow a regular schedule in maintaining and caring for your Brinly-Hardy Sweeper. TABLE OF CONTENTS SAFETY LABELS AND NOTATION ================================ ================================================================= Safety .... 2 - 3... - Page 3 CAUTION SHOULD BE TAKEN WHEN TOWING AND/OR USING ANY ATTACHMENT. ================================================================================================ This attachment combined with the weight distribution, turning radius, and speed of towing vehicle can result in severe injury or death to operator, damage to towing vehicle, and/or attachment if not used properly. Follow all towing safety precautions noted in the GENERAL NOTES towing vehicle owner’s manual, including the following precautions: (Operation)
-
Page 4: Safety
COMPONENT VIEW AND REFERENCE LIST COMPONENT VIEW AND REFERENCE LIST ================================================================================================ =============================================================================================== = REF. PART NO. DESCRIPTION QTY. REF. PART NO. DESCRIPTION QTY. R-2251-10 Hitch Clevis Assembly 30M1200P Hex Nut, 3/8" R-2254-10 Tow Tube B-1675P Lock Nut, 3/8" R-2270-10 Lift Handle B-983 Hairpin Cotter, Small 1018198... -
Page 5: Reference List
RTS REFERENCE COMPONENT VIEW AND REFERENCE LIST ================================================================================================ 1018189 Rev. C... -
Page 6: Assembly
ASSEMBLY ================================================================================================ 1018189 Rev. C... -
Page 7: Assembly
ASSEMBLY ================================================================================================ STEP 1 - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - a. Attach upper frame assembly (35) to brush housing assembly (31). - Page 8 5/16" ASSEMBLY a) Assemble Lift Handle (3) to Lift Link (14). b) Install H ================================================================================================ Washe Note orientation of Lift Handle (3) to hole. N Lift Link (14) in picture below. downw Assem STEP 2-A - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - c) Comple Spring a) Assemble Lift Handle (3) to Lift Link (14).
-
Page 9: Rev. C
Step 4. ATTACHING CLEVIS ASSEMBLY ================================================================================================ Attach the Hitch Clevis Assembly (1) to the Tow Tubes (2), as shown. STEP 4 - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - a) Install Hex Bolts (63) through Tow Tubes (2) and ATTACHING CLEVIS... - Page 10 11” ASSEMBLY (top of page) 11” ================================================================== 10” STEP 5 - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 10”...
- Page 11 ASSEMBLY ================================================================================================ STEP 6 - - - - - - - - - - - - - - - - - - - - - - - - - a) Assemble Rear Tube (53) with a. Assemble Rear Tube (53) with holes holes up to Lower Tube (52). Step 6.
- Page 12 ASSEMBLY ================================================================================================ STEP 8 - - - - - - - - - - - - - - - - - - - - - - - - - - - - Step 8. a. Locate and align the holes in the upper Rear Tube (53) with the side tubes (56).
- Page 13 ASSEMBLY ================================================================================================ STEP 10 - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - Step 10. a. Pull up on bottom of Hamper (55) from “J” Channel and hook ”J” Channel onto Hamper Stop Rod (54).
- Page 14 Step 12.2 ASSEMBLY ================================================================================================ Step 12.3 Step 12. Step 12.2 STEP 12 Step 12.1 - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - To Sweeper To Towing Step 12.3...
-
Page 15: Operation
that will be easi Pull Rope to sla and tied point o pull the knots in Hairpin Cotter, .08 x 1-3/16" Clevis Pin, 5/16" x 1-3/8" needed. Qty. 2 Qty. 2 OPERATION C) Clean the area located and affix A) With the sweeper attached to the towing vehicle, attach the hamper ================================================================================================ assembly to back of sweeper by placing Clevis Pins (49) through holes in Hamper Mount Tubes (57) and upper frame assembly (35). -
Page 16: Dethatcher Attachment
Normal lawn sweeping is accomplished when the brushes sweep at the Total towed weight must not exceed Pull to same height as the mower cutting height. combined weight of towing vehicle, ballast STS-42BHDK 102 lbs. dry disengage and operator. NOTE: Setting brush height too low for sweeping conditions causes 222 lbs. with wet grass... - Page 17 OPERATION ================================================================================================ CAUTION: AVOID INJURY! Make sure area is clear of EMPTYING HAMPER bystanders, especially children, before backing up. - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - BEFORE DUMPING MATERIAL FROM THE HAMPER: Park towing vehicle and set parking brake (see owners manual).
- Page 18 pivot sweeper to vertical position and resting on the tubes (B) at rear of sweeper (bottom of sweeper should face wall). 7. Lift the collapsed hamper assembly by the rear tubes, OPERATION positioning the middle of the upper rear tube (C) at the center hamper cut-out over the opening in the hitch clevis (the inside ================================================================================================ of the hamper faces the lift handle and tow tubes, and the...
- Page 19 SERVICE SERVICE ================================================================================================ SERVICE - Do not allow material to remain in the hamper for extended - Check the drive pinions for wear. These are considered normal Do not allow material to remain in the hamper for extended SPECIFICATIONS periods of time. Clean the hamper using a water hose and wear parts. Contact our Customer Service Department to periods of time. Clean the hamper using a water hose and Do not allow material to remain in the hamper for extended allow to dry prior to storage.
- Page 20 MANUFACTURER’S LIMITED WARRANTY FOR BRINLY PULL-BEHIND ACCESSORIES The limited warranty set forth below is given by Brinly-Hardy or retailer, with respect to any product, shall bind Brinly- Company with respect to new merchandise purchased and Hardy Co. During the period of the warranty, the exclusive remedy is repair or replacement of the product as set forth used in the United States, its possessions and territories.
