DET02AFC Operating Manual — Fiber Input Si Photodetector
Description:
The DET02AFC is a ready-to-use, high-speed Si photodetector for use with FC/PC connectorized fiber optic cables
in visible wavelength optical systems. The unit comes with an FC/PC bulkhead connector, detector, and 12V bias
battery enclosed in a compact aluminum housing. The FC/PC connector provides easy coupling to fiber-based light
sources. The output uses an SMA jack to minimize size and maximize frequency response. The bandwidth is
1.2GHz and will operate over the spectral range of 400-1100nm. A NIR version, the DET01CFC, is also available
and operates in the 800-1700nm spectral range.
The DET02AFC includes one #8-32 tapped mounting hole with a 0.25" mounting depth, while the DET02AFC/M has
one M4 tapped mounting hole with a 6.35mm mounting depth. A 12V A23 battery is included.
Specifications*:
Detector:
Active Diameter:
Wavelength Range (λ):
Peak Wavelength (λ
Peak Response [typ, ℜ(λ
Rise Time (t
Fall Time (t
Ball Lens Size:
Diode Capacitance (C
Min Load Resistance:
Damage Threshold:
*All measurements performed with a 50Ω load unless stated otherwise.
Into high impedance. Max voltage is dependent on battery voltage. New batteries typically show 12-13V, while drained
1.
batteries show 9V or less.
Calculated range based on peak responsivity and damage threshold.
2.
Measured with specified bias voltage.
3.
PO Box 366, 435 Route 206N, Newton, NJ 07860
Ph (973) 579-7227, Fax (973) 300-3600, http://www.thorlabs.com
Si PIN
Ø0.25mm
400-1100nm
730nm (typ)
:
p)
)]:
0.46A/W (typ)
p
Input:
FC/PC fiber connector
):
50ps (typ)
R
):
250ps (typ)
f
Ø0.059" (Ø1.5 mm)
):
0.94pF (typ)
J
50Ω
18mW
15829-S01 Rev D 3/18/2008
Output Voltage
Output Voltage
Dark Current
Shunt Resistance (R
Storage Temp:
Operating Temp:
NEP (730nm):
Bias Voltage (V
Figure 1
Page 1 of 5
1
(Hi-Z):
0-10V
2
(50Ω):
0-410mV
Output:
SMA (DC coupled)
3
(I
):
50pA (500pA max)
D
):
20GΩ
sh
Weight:
0.18lbs
0-40°C
0-40°C
Battery:
A23, 12V
, 40mAh
DC
-15
9.5x10
W/√Hz (max)
):
12V
R
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for THORLABS DET02AFC
Summary of Contents for THORLABS DET02AFC
-
Page 1: Specifications
800-1700nm spectral range. The DET02AFC includes one #8-32 tapped mounting hole with a 0.25″ mounting depth, while the DET02AFC/M has one M4 tapped mounting hole with a 6.35mm mounting depth. A 12V A23 battery is included. -
Page 2: Operation
Unpack the optical head and install the battery as described in “Battery Replacement.” • (Optional) Install a Thorlabs TR series ½″ diameter post into one of the #8-32 (M4) tapped holes, located on the bottom and side of the sensor, and mount into a PH series post holder. -
Page 3: Battery Replacement
There are no serviceable parts in the DET02AFC optical sensor. The housing may be cleaned with a soft damp cloth. If you suspect a problem with your DET02AFC, please call Thorlabs and an engineer will be happy to assist you. - Page 4 Waste treatment on your own responsibility If you do not return an end-of-life unit to Thorlabs, you must hand it to a company specialized in waste recovery. Do not dispose of the unit in a litter bin or at a public waste disposal site.
- Page 5 15829-S01 Rev D 3/18/2008 Page 5 of 5...
