Heisei Electronics ZPOS Series User Manual

Touch pos terminal
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the ZPOS Series and is the answer not in the manual?

Questions and answers

Related Manuals for Heisei Electronics ZPOS Series

Summary of Contents for Heisei Electronics ZPOS Series

  • Page 2 FCC Statement This device complies with part 15 FCC rules. Operation is subject to the following two conditions： This device may not cause harmful interference. This device must accept any interference received including interference that may cause undesired operation. This equipment has been tested and found to comply with the limits for a class "a" digital device, pursuant to part 15 of the FCC rules.
  • Page 3 Heisei Electronics Co., Ltd. reserves the right to revise this publication and to make changes from time to time in the contents hereof without obligation to notify any person of such revision or changes.
  • Page 4 Unpacking the ZPOS After unpacking the ZPOS carton, check to make sure all the following items are included and in good condition. ZPOS main system Accessories: AC Power Cable User guide CD & driver Make sure that all of the items listed above are present. If any of the above items is missing, contact your supplier immediately.
  • Page 5 Important Safety Precautions Before getting started, read these instructions and save them for later reference. Please disconnect this equipment from any AC outlet before cleaning. Clean with a damp or dry cloth only. Do not spray any liquid cleaner directly on the screen. The power outlet socket used to plug in the computer power cord must be located near the system and easily accessible.

  • Page 6: Table Of Contents

    Contents ............1-8 HAPTER NTRODUCTION General Information..............1-8 Specifications ................1-9 Dimensions................1-12 ..........2-13 HAPTER SING THE YSTEM Identifying the System ............2-13 2.1.1 Front view ..................2-13 2.1.2 Rear view ................... 2-14 First Time System Setup ............2-15 2.2.1 Hardware Installation Procedure ............2-15 2.2.2 System BIOS Setup ................
  • Page 7 5.11 I/O Board Disassembly............5-50 5.12 VFD Module Disassembly .............5-51 5.13 Power Disassembly ...............5-52 5.14 Main Board Disassembly............5-54 .........6-57 HAPTER YSTEM OARD Main Board Dimensions ............6-57 Main Board Layout ..............6-58 Main Board Jumpers and Connectors ........6-59 6.3.1 JBAT1: Clear CMOS Contents............6-60 6.3.2 JC1: Chassis intrusion connector ............
  • Page 8 Ethernet Driver Installation ............8-94 8.2.1 Windows XP/WEPOS/POSReady ............. 8-94 8.2.2 Windows VISTA ................. 8-95 VGA Driver Installation ............8-96 8.3.1 Windows XP/ WEPOS/POSReady ............ 8-96 8.3.2 Windows VISTA ................. 8-97 Audio Driver Installation............8-100 8.4.1 Windows XP..................8-100 8.4.2 Windows VISTA ................8-101 8.4.3 Windows WEPOS/POSReady............

  • Page 9: Chapter 1 Introduction

    Dimensions General Information The ZPOS series is an all-in-one touch POS terminal designed for operation in quiet and dusty environments. The ZPOS series also can benefit from low voltage consumption and heat dissipation. Featuring a 15-inch or 17-inch analog resistive high brightness touch screen, it can perfectly meet any requirement.

  • Page 10: Specifications

    HEISEI Electronics Co., Ltd. Specifications SYSTEM • Support Intel Core 2 Duo/Pentium 4/Celeron LGA 775 Processors (Up to FSB 800MHz) • Intel G31/ICH7 chipset System Memory • 2 x 240 pin DIMM socket up to DDR2 4GB 667/800 Graphics •...
  • Page 11 HEISEI Electronics Co., Ltd. Touch Type • 5-wire Analog resistive (HIGGSTEC) Brightness • 15” LCD: 250 cd/m² • 17” LCD: 300 cd/m² I/O PORTS • 8 x USB 2.0 ports (4 x rear; 2 x front; 2 x onboard pin header) Serial Ports •...
  • Page 12 HEISEI Electronics Co., Ltd. ENVIRONMENT EMC & Safety • CE, FCC Temperature & Humidity • Operating: 0~40°C/Storage: -20~60°C • Humidity: 10%~90% OPTIONAL ITEMS Processor • Pentium 4 651: 3.4GHz/2MB L2/FSB 800 • Core 2 Duo E4300: 1.8GHz/2MB L2/FSB 800 •...

  • Page 13: Dimensions

    HEISEI Electronics Co., Ltd. Dimensions ZPOS USER MANUAL 1-12...

  • Page 14: Chapter 2 Using The System

    HEISEI Electronics Co., Ltd. Chapter 2 U SING THE YSTEM Identifying the System 2.1.1 Front view LED Indicators Descriptions Power Status LED Red: it will light up when power on. HDD Status LED Orange: it will flash when data transmit.

  • Page 15: Rear View

    HEISEI Electronics Co., Ltd. 2.1.2 Rear view ZPOS USER MANUAL 2-14...

  • Page 16: First Time System Setup

    HEISEI Electronics Co., Ltd. First Time System Setup To set up ZPOS series for the first-time, you should have the following items ready. These items are either included in the accessory box or available from your local computer parts store.

  • Page 17: Operating System And Driver

    HEISEI Electronics Co., Ltd. system setup information is stored in a battery-backed CMOS RAM. The battery is to ensure the settings will not be erased when the computer is turned off or reset. When the computer is powered on again, the system will read the settings stored in the CMOS RAM and compare them to the equipment check conducted during the power on self-test (POST).

  • Page 18: Installation Memory Module

    HEISEI Electronics Co., Ltd. Installation Memory Module The ZPOS main board provides two 240-pin DIMM slot. The socket supports up to 2GB DDR2 677/800 MHz. When installing the Memory device, please follow the steps below： 1. Locate the DIMM slot in the motherboard.

  • Page 19: Versatile Stand With Options

    HEISEI Electronics Co., Ltd. Versatile Stand with Options The ZPOS series include a sleek and stable pedestal assembled with the base that enables the ZPOS to endure intense operation in any public setting. The two side hinges swivel the base up and down, from 30° to 180°.

  • Page 20: Chapter 3 Touch Screen

    CREEN Introduction The ZPOS series are installed with a 5-wire analog resistive touch screen. The touch screen panel turns the flat-panel display into a dynamic graphical user interface (GUI) and data entry device. The touch screen represents a replacement to needing a keyboard and mouse to interface with the computer.

  • Page 21: Touch Screen Care And Clean

    HEISEI Electronics Co., Ltd. Touch Screen Care and Clean Only use soft non-abrasive lint free wipes with Isopropyl 99% to clean dirt or stains found on the touch panel. Always dampen the wipes and then clean the touch panel. Chemical liquids with strong acidic base will damage the touch screen and void the warranty.

  • Page 22: Hardware Troubleshooting

    HEISEI Electronics Co., Ltd. 3.5.4 Hardware Troubleshooting The touch screen system hardware troubleshooting may require analysis of the touch screen, controller, cables, power supply, and the integration process. To start with the controller would be the best. Use the controller power-on diagnostics that are displayed when the touch panel utility driver software is loaded to check for specific faults.

  • Page 23: Chapter 4 Input /Output Connectors

    HEISEI Electronics Co., Ltd. Chapter 4 I NPUT UTPUT ONNECTORS This chapter describes the I/O connections of ZPOS system. Mouse and Keyboard The standard PS/2 mouse/keyboard DIN connector is for a PS/2 mouse/keyboard. Parallel Port A parallel port is a standard printer port that supports enhanced Parallel Port (EEP) and Extended Capabilities Parallel Port (ECP) mode.

  • Page 24: Chapter 5 System Disassembly

    HEISEI Electronics Co., Ltd. Chapter 5 S YSTEM ISASSEMBLY Warning: Power cord and I/O cables must be disconnected and unplugged before system assembling!! LCD Disassembly A. Adjust the panel as the picture. B. Disconnect the VGA cable, speaker cable, power cable and USB cables.
  • Page 25 HEISEI Electronics Co., Ltd. G. Remove screws (6) to take off the panel H. Remove screws (2) from the top. cover. I. Remove screws (2) from the left side. J. Remove screws (2) from the right side. K. Disconnect the left speaker cable.
  • Page 26 HEISEI Electronics Co., Ltd. M. Disconnect LVDS cable for AD board. N. Remove screws (4) from two sides. O. Remove the touch screen as direction. After replacing, please install as the step inversely. ZPOS USER MANUAL 5-25...

  • Page 27: Inverter Board Disassembly

    HEISEI Electronics Co., Ltd. Inverter Board Disassembly A. Adjust the panel as the picture. B. Disconnect the VGA cable, speaker cable, power cable and USB cables. C. Remove screws (2). D. Move the panel as the direction. E. Pull the panel up.
  • Page 28 HEISEI Electronics Co., Ltd. G. Remove screws (6) to take off the panel H. Remove screws (2) from the top. cover. I. Remove screws (2) from the left side. J. Remove screws (2) from the right side. K. Disconnect the left speaker cable.
  • Page 29 HEISEI Electronics Co., Ltd. M. Disconnect inverter cables (3). N. Remove screws (2). After replacing, please install as the step inversely. ZPOS USER MANUAL 5-28...

  • Page 30: Touch Control Board Disassembly

    HEISEI Electronics Co., Ltd. Touch Control Board Disassembly A. Adjust the panel as the picture. B. Disconnect the VGA cable, speaker cable, power cable and USB cables. C. Remove screws (2). D. Move the panel as the direction. E. Pull the panel up.
  • Page 31 HEISEI Electronics Co., Ltd. G. Remove screws (6) to take off the panel H. Remove screws (2) from the top. cover. I. Remove screws (2) from the left side. J. Remove screws (2) from the right side. K. Disconnect the left speaker cable.
  • Page 32 HEISEI Electronics Co., Ltd. M. disconnect touch screen cable and N. Remove screws (2). USB cable. After replacing, please install as the step inversely. ZPOS USER MANUAL 5-31...

  • Page 33: Touch Screen Disassembly

    HEISEI Electronics Co., Ltd. Touch Screen Disassembly A. Adjust the panel as the picture. B. Disconnect the VGA cable, speaker cable, power cable and USB cables. C. Remove screws (2). D. Move the panel as the direction. E. Pull the panel up.
  • Page 34 HEISEI Electronics Co., Ltd. G. Remove screws (6) to take off the panel H. Remove screws (2) from the top. cover. I. Remove screws (2) from the left side. J. Remove screws (2) from the right side. K. Disconnect the left speaker cable.
  • Page 35 HEISEI Electronics Co., Ltd. M. Disconnect touch screen cable. N. Remove the touch screen as direction. After replacing, please install as the step inversely. ZPOS USER MANUAL 5-34...

  • Page 36: Wifi Module Disassembly

    HEISEI Electronics Co., Ltd. WIFI Module Disassembly A. Adjust the panel as the picture. B. Disconnect the VGA cable, speaker cable, power cable and USB cables. C. Remove screws (2). D. Move the panel as the direction. E. Pull the panel up.
  • Page 37 HEISEI Electronics Co., Ltd. G. Remove screws (6) to take off the panel H. Remove screws (2) from the top. cover. I. Remove screws (2) from the left side. J. Remove screws (2) from the right side. K. Disconnect the left speaker cable.
  • Page 38 HEISEI Electronics Co., Ltd. M. disconnect WIFI cable and antenna. N. Remove screws (2). After replacing, please install as the step inversely. ZPOS USER MANUAL 5-37...

  • Page 39: Ad Board Disassembly

    HEISEI Electronics Co., Ltd. AD Board Disassembly A. Adjust the panel as the picture. B. Disconnect the VGA cable, speaker cable, power cable and USB cables. C. Remove screws (2). D. Move the panel as the direction. E. Pull the panel up.
  • Page 40 HEISEI Electronics Co., Ltd. G. Remove screws (6) to take off the panel H. Remove screws (2) from the top. cover. I. Remove screws (2) from the left side. J. Remove screws (2) from the right side. K. Disconnect the left speaker cable.
  • Page 41 HEISEI Electronics Co., Ltd. M. Disconnect inverter cable, speaker N. Remove screws (4). cable and LVDS cable. After replacing, please install as the step inversely. ZPOS USER MANUAL 5-40...

  • Page 42: Usb Board Disassembly

    HEISEI Electronics Co., Ltd. USB Board Disassembly A. Adjust the panel as the picture. B. Disconnect the VGA cable, speaker cable, power cable and USB cables. C. Remove screws (2). D. Move the panel as the direction. E. Pull the panel up.
  • Page 43 HEISEI Electronics Co., Ltd. G. Remove screws (6) to take off the panel H. Remove screws (2) from the top. cover. I. Remove screws (2) from the left side. J. Remove screws (2) from the right side. K. Disconnect the left speaker cable.
  • Page 44 HEISEI Electronics Co., Ltd. M. Disconnect USB cable. N. Remove screws (2). After replacing, please install as the step inversely. ZPOS USER MANUAL 5-43...

  • Page 45: Speaker Module Disassembly

    HEISEI Electronics Co., Ltd. Speaker Module Disassembly A. Adjust the panel as the picture. B. Disconnect the VGA cable, speaker cable, power cable and USB cables. C. Remove screws (2). D. Move the panel as the direction. E. Pull the panel up.
  • Page 46 HEISEI Electronics Co., Ltd. G. Remove screws (6) to take off the panel H. Remove screws (2) from the top. cover. I. Disconnect the right speaker cable. J. Remove screws (2) form left speaker. K. Remove screws (2) form right speaker.

  • Page 47: Msr Module Disassembly

    HEISEI Electronics Co., Ltd. MSR Module Disassembly A. Adjust the panel as the picture. B. Disconnect the VGA cable, speaker cable, power cable and USB cables. C. Remove screws (2). D. Move the panel as the direction. E. Pull the panel up.
  • Page 48 HEISEI Electronics Co., Ltd. G. Remove screws (2). H. Take off the MSR board. After replacing, please install as the step inversely. ZPOS USER MANUAL 5-47...

  • Page 49: Hdd Module Disassembly

    HEISEI Electronics Co., Ltd. 5.10 HDD Module Disassembly A. Disconnect VGA cable and USB B. Remove screws (2). cables (2). C. Open the bottom cover. D. Pull the bottom. E. Raise the bottom to take off. F. Loosen the knob.
  • Page 50 HEISEI Electronics Co., Ltd. G. Push the HDD as direction. H. Disconnect SATA and power cable. I. Remove screws (4) from two sides. After replacing, please install as the step inversely. ZPOS USER MANUAL 5-49...

  • Page 51: I/O Board Disassembly

    HEISEI Electronics Co., Ltd. 5.11 I/O Board Disassembly B. Disconnect VGA cable and USB B. Remove screws (2). cables (2). C. Open the bottom cover. D. Pull the bottom. E. Raise the bottom to take off. F. Disconnect LED cable and I/O board cable and remove screws (2).

  • Page 52: Vfd Module Disassembly

    HEISEI Electronics Co., Ltd. 5.12 VFD Module Disassembly A. Remove the screw from left side. B. Remove screw from right side. C. Remove the covers from to sides. D. Remove back cover. E. Remove screws (2). After replacing, please install as the step inversely.

  • Page 53: Power Disassembly

    HEISEI Electronics Co., Ltd. 5.13 Power Disassembly A. Disconnect VGA cable and USB B. Remove screws (2). cables (2). C. Open the bottom cover. D. Pull the bottom. E. Raise the bottom to take off. F. Remove the screw. ZPOS USER MANUAL...
  • Page 54 HEISEI Electronics Co., Ltd. G. Disconnect power cable. H. Remove the power as direction. I. Remove the front screw. J. Remove the back screw. After replacing, please install as the step inversely. ZPOS USER MANUAL 5-53...

  • Page 55: Main Board Disassembly

    HEISEI Electronics Co., Ltd. 5.14 Main Board Disassembly A. Disconnect VGA cable and USB B. Remove screws (2). cables (2). C. Open the bottom cover. D. Pull the bottom. E. Raise the bottom to take off. F. Disconnect USB cables (2).
  • Page 56 HEISEI Electronics Co., Ltd. G. Disconnect LED cable and SATA cable. H. Disconnect power cable. I. Disconnect power cable. J. Disconnect audio cable. K. Remove screws (2). L. Remove screws (2). ZPOS USER MANUAL 5-55...
  • Page 57 HEISEI Electronics Co., Ltd. M. Remove screws (2). After replacing, please install as the step inversely. ZPOS USER MANUAL 5-56...

  • Page 58: Main Board

    HEISEI Electronics Co., Ltd. Chapter 6 S YSTEM OARD This chapter describes the mainboard detail. Main Board Dimensions ： ： Width 218mm Length 244mm ： Height 40mm ZPOS USER MANUAL 6-57...

  • Page 59: Main Board Layout

    HEISEI Electronics Co., Ltd. Main Board Layout Locating Jumpers and Connectors (front side) ZPOS USER MANUAL 6-58...

  • Page 60: Main Board Jumpers And Connectors

    HEISEI Electronics Co., Ltd. Main Board Jumpers and Connectors Label Function JBAT1 Clear CMOS Jumper JCI1 Chassis Intrusion Connector CD_IN1 CD-In Connector JUSB1 Front USB Connectors JUSB2 SYSFAN1 SYSFAN2 Fan Power, CPU Connector CPUFAN1 JPW1 ATX 12V Power Connector ATX1...

  • Page 61: Jbat1: Clear Cmos Contents

    HEISEI Electronics Co., Ltd. 6.3.1 JBAT1: Clear CMOS Contents Setting Function Pin 1-2 Normal Short/Closed Pin 2-3 Clear CMOS Short/Closed Note: The ATX-power connector should be disconnected from the board before clearing CMOS. 6.3.2 JC1: Chassis intrusion connector This connector connects to the chassis intrusion switch cable. If the chassis is opened, the chassis intrusion mechanism will be activated.

  • Page 62: Jusb1/Jusb2: Front Usb Connectors

    HEISEI Electronics Co., Ltd. 6.3.4 JUSB1/JUSB2: Front USB Connectors These connectors, compliant with Intel I/O Connectivity Design guide, is ideal for connecting high-speed USB interface peripherals such as USB HDD, digital cameras, MP3 players, printers, modems and the like. Signal Name...

  • Page 63: Jpw1: Atx 12V Power Connector

    HEISEI Electronics Co., Ltd. 6.3.6 JPW1: ATX 12V Power Connector Signal Name Ground Ground +12V +12V 6.3.7 ATX1: ATX 24-Pin power connector To connect the ATX 24-pin power supply, make sure the plug of power supply is inserted in the proper orientation and the pins are aligned. Then push down the power supply firmly into the connector.

  • Page 64: Jcom1: Com Port Connector

    HEISEI Electronics Co., Ltd. 6.3.9 JCOM1: COM Port Connector The connector is a 16550A high speed communication port that sends/receives 16 bytes FIFOs. You can attach a serial device. Signal Name Signal Name DCD, Data carrier detect SIN, Serial in or receive data...

  • Page 65: Pci_E1/Pci_E2: Pci Express Slot

    HEISEI Electronics Co., Ltd. 6.3.11 PCI_E1/PCI_E2: PCI Express Slot The PCI Express slot supports the PCI Express interface expansion card. The PCI Express x 16 slot support up to 4.0GB/s transfer rate. The PCI Express x 1 slot supports up to 250MB/s transfer rate.
  • Page 66 HEISEI Electronics Co., Ltd. Signal Name Signal Name HSIP-7 PRSNT2#2 HSIN-7 HSOP-8 RSVD HSON-8 HSIP-8 HSIN-8 HSOP-9 HSON-9 HSIP-9 HSIN-9 HSOP-10 HSON-10 HSIP-10 HSIN-10 HSOP-11 HSON-11 HSIP-11 HSIN-11 HSOP-12 HSON-12 HSIP-12 HSIN-12 HSOP-13 HSON-13 HSIP-13 HSIN-13 HSOP-14 HSON-14 HSIP-14 HSIN-14...
  • Page 67 HEISEI Electronics Co., Ltd. Signal Name Signal Name +12V +12V +12V +12V +12V SMCLK SMDAT +3.3V +3.3V 3.3VAUX +3.3V WAKE# RESET# PCIE_CLK+ PEG TXP0 PCIE_CLK- PEG TXN0 PEG RXP0 PEG RXN0 PEG TXP1 PEG TXN1 PEG RXP1 PEG RXN1 PEG TXP2...

  • Page 68: Pci1/Pci2: Pci Bus Slot

    HEISEI Electronics Co., Ltd. 6.3.12 PCI1/PCI2: PCI Bus Slot Signal Name Signal Name -12V TRST +12V INTA INTB INTC INTD PRSNT1 RESV01 RESERVED1 PRSNT2 RESV03 GND03 GND05 RESERVED2 RESV05 RESET GND08 RESV06 AD31 AD30 AD29 +3.3V01 AD28 AD27 AD26 AD25 GND10 +3.3V...
  • Page 69 HEISEI Electronics Co., Ltd. Signal Name Signal Name GND13 FRAME IRDY GND14 +3.3V TRDY DEVSEL GND15 GND16 STOP LOCK +3.3V07 PERR SDONE +3.3V SERR GND17 +3.3V C/BE1 AD15 AD14 +3.3V10 GND18 AD13 AD12 AD11 AD10 GND19 GND20 C/BE0 +3.3V11 +3.3V...

  • Page 70: Ide1: Ide Connector

    HEISEI Electronics Co., Ltd. 6.3.13 IDE1: IDE Connector Signal Name Signal Name Reset IDE Ground Host data 7 Host data 8 Host data 6 Host data 9 Host data 5 Host data 10 Host data 4 Host data 11 Host data 3...

  • Page 71: Chapter 7 Award Bios Setup

    HEISEI Electronics Co., Ltd. Chapter 7 A BIOS S WARD ETUP Starting Setup Award BIOS™ has a built-in setup program that allows users to modify the basic system configuration. The information is stored in battery-backed Flash so that it retains the setup information even if the system power is turned off.

  • Page 72: The Main Menu

    HEISEI Electronics Co., Ltd. The Main Menu The Main Menu allows you to select from several setup functions and two exit choices. Use the arrow keys to move among the items and press <Enter> to enter the sub-menu. Standard CMOS Setup This page includes all the items in standard compatible BIOS.

  • Page 73: Standard Cmos Features

    HEISEI Electronics Co., Ltd. Standard CMOS Features The standard CMOS features menu includes some basic items. Use arrow keys to highlight the item and then use the <PgUp> or <PgDn> keys to select the value you want in each item.
  • Page 74 HEISEI Electronics Co., Ltd. ► LBA/Large Mode This allows you to enable or disable the LBA mode. Setting to Auto enable LBA mode of the device supports it and the device id not already formatted with LBA mode disable. ►...

  • Page 75: Advanced Bios Features

    HEISEI Electronics Co., Ltd. Advanced BIOS Features This section allows you to configure your system for basic operation. You can select the system’s default speed, boot-up sequence, keyboard operation, shadowing and security. Full screen Logo Display This item enables you to show the company logo on the bootup screen. Settings are: Enable: show a still image (logo0 on the full screen at boot.
  • Page 76 HEISEI Electronics Co., Ltd. MPS Table version This field allows you to select which MPS (Multi-Processor Specification) version to be used for the operating system. You need to select the MPS version supported by your operating system. To find out which version to use, consult the vendor of your operating system.
  • Page 77 HEISEI Electronics Co., Ltd. DVMT mode: The driver of the graphics core uses the system memory like any other OS component or application does. ► DVMT/FIXED Memory Specify the size of DVMT memory to allocate for video memory. Boot Sequence Press <Enter>...

  • Page 78: Integrated Peripherals

    HEISEI Electronics Co., Ltd. Integrated Peripherals USB Controller This setting allows you to enable or/disable the onboard USB controller. USB Device Legacy Support Select [Enable] if you need to use a USB-interfaced device in the operating system. Onboard LAN Controller This item is used to enable/disable the onboard LAN controller.
  • Page 79 HEISEI Electronics Co., Ltd. ► On-Chip SATA channel1 These items allow users to enable or disable the SATA controller. ► RAID Mode This item is used to enable/disable the RAID function for SATA devices. IO Device Configuration Press <Enter> to enter the sub-menu: ►...

  • Page 80: Power Management Setup

    HEISEI Electronics Co., Ltd. Power Management Setup ACPI Function This item is to activate the ACPI (Advanced Configuration and Power Management Interface) function. If your operating system is APCI-aware, such as Windows 2000/XP, select Enabled. ACPI Standby State This item specifies the power saving mode for ACPI function. If your operating system supports ACPI, such as Windows 2000/XP, you can choose to enter the standby mode in S1 (POS) or S3 (STR) fashion through the setting of this field.
  • Page 81 HEISEI Electronics Co., Ltd. Wakeup Event Setup Press <Enter> to enter the sub-menu: ► Resume From S3 by USB Device The item allows the activity of the USB device to wake up the system from S3 (Suspend to RAM) sleep state.

  • Page 82: H/W Monitor

    HEISEI Electronics Co., Ltd. H/W Monitor Chipset Intrusion The field enables or disables the feature of recording the chassis intrusion status and issuing a warning message if the chassis is once opened. To clear the warning message, set the field to [Reset]. The setting of the field will automatically return to [enable] later.

  • Page 83: Cell Menu

    HEISEI Electronics Co., Ltd. Cell Menu Current CPU/DRAM Frequency These items show the current clocks of CPU and memory speed. Read-only. Intel ELST The Enhance Intel SpeedStep technology allows you to set the performance level of the microprocessor whether the computer is running on battery or AC power.
  • Page 84 HEISEI Electronics Co., Ltd. When DRAM is refreshed, both rows and columns are addressed separately. This setup item allows you to determine the timing of the transition from RAS (row address strobe) to CAS (column address strobe). The less the clock cycles, the faster the DRAM performance.
  • Page 85 HEISEI Electronics Co., Ltd. Power User Mode Press <Enter> to enter the sub-menu: ► ADJUST CHANNEL 0/1 DRIVE These two groups are used to program RCOMP buffer strengths and slew rate table for the various signal groups of MCH. Each channel contains seven groups of signal (GROUP 0~GROUP 6).

  • Page 86: Load Fail-Safe/ Optimized Defaults

    HEISEI Electronics Co., Ltd. Load Fail-Safe/ Optimized Defaults The two options on the main menu allow users to restore all of the BIOS settings to the default Fail-safe or Optimized values. The Optimized Default are the default values set by the mainboard manufacture specifically for optimal performance of the mainboard.

  • Page 87: Bios Setting Password

    HEISEI Electronics Co., Ltd. 7.10 BIOS Setting Password When you select this function, a message as below will appears: Steps to set supervisor/user password are described as follows: New password setting: While pressing <Enter> to set a password, a dialog box appears to ask you enter a password.

  • Page 88: Installation

    HEISEI Electronics Co., Ltd. Chapter 8 D RIVERS NSTALLATION This chapter offers information of software drivers’ installation. Chipset Driver Installation The ZPOS Chipset Drivers should be installed first before the software drivers to enable Plug & Play INF. Follow the instructions below to complete the installation.

  • Page 89: Windows Vista

    HEISEI Electronics Co., Ltd. g. Click “Finish” and restart the computer. 8.1.2 Windows VISTA a. Click “CHIPSET”. b. Click “infinst_autol” to install. c. Click “Next” to continue. d. Click “Yes” to go on. ZPOS USER MANUAL 8-88...

  • Page 90: Windows Wepos/Posready

    HEISEI Electronics Co., Ltd. e. Click “Next”. f. Click “Next“. g. Click “Finish” to restart your computer. 8.1.3 Windows WEPOS/POSReady a. Click “CHIPSET” folder. b. Click “infinst_autol” to install. ZPOS USER MANUAL 8-89...
  • Page 91 HEISEI Electronics Co., Ltd. c. Click “Next”. d. Click “Yes”. e. Click “Next” to continue. f. Click “Browse” to find “Windows\system32\drivers” source to copy and click “OK”. g. Click “Browse” to find “Windows\ h. Click “Browse” to find “Windows\ system32\drivers” source to copy system32\drivers”...
  • Page 92 HEISEI Electronics Co., Ltd. i. Click “Browse” to find “Windows\ j. Click “Browse” to find “Windows\ system32\drivers” source to copy system32\drivers” source to copy and and click “OK”. click “OK”. k. Click “Browse” to find “Windows\ l. Click “Browse” to find “Windows\ system32\drivers”...
  • Page 93 HEISEI Electronics Co., Ltd. o. Click “Browse” to find “Windows\ n. Click “Browse” to find “Windows\ system32\drivers” source to copy system32\drivers” source to copy and and click “OK”. click “retry”. q. Click “Browse” to find “Windows\ R. Click “Browse” to find “Windows\ system32\drivers”...
  • Page 94 HEISEI Electronics Co., Ltd. u. Click “Browse” to find “Windows\ v. Click “Browse” to find “Windows\ system32\drivers” source to copy system32\drivers” source to copy and and click “OK”. click “retry”. w. Click “Next”. x. Click “Finish” and restart your computer.

  • Page 95: Ethernet Driver Installation

    HEISEI Electronics Co., Ltd. Ethernet Driver Installation The ZPOS is equipped with the Realtek RTL8111B PCI-E Gigabit Ethernet controller combines a triple-speed IEEE 802.3 compliant Media Access Controller (MAC) with a triple-speed Ethernet transceiver, PCI Express bus controller, and embedded memory.

  • Page 96: Windows Vista

    HEISEI Electronics Co., Ltd. 8.2.2 Windows VISTA a. Click “LAN”. b. Click “VISTA”. c. Click “setup” to install. d. Click “Next”. e. Click “Install”. f. Click “Finish”. ZPOS USER MANUAL 8-95...

  • Page 97: Vga Driver Installation

    HEISEI Electronics Co., Ltd. VGA Driver Installation The ZPOS offers an integrated VGA/LCD Controller, 2D/3D GUI engine, sharing memory architecture. The specifications and features are described as follows: The ZPOS supports CRT and TFT LCD displays. In addition, it also supports CRT and flat panel display mode simultaneously.

  • Page 98: Windows Vista

    HEISEI Electronics Co., Ltd. e. Click “Yes”. f. Click “Next”. g. Click “Next”. h. Select “Yes, I want to restart the computer now” and click “Finish”. 8.3.2 Windows VISTA a. Click “VGA” folder. b. Click “VISTA”. ZPOS USER MANUAL 8-97...
  • Page 99 HEISEI Electronics Co., Ltd. c. Click “VISTA32”. d. Click “Setup” to install the driver. e. Click “Next”. f. Click “Yes”. g. Click “Next”. h. Click “Next”. ZPOS USER MANUAL 8-98...
  • Page 100 HEISEI Electronics Co., Ltd. i. Select “Yes, I want to restart my computer now” and click “Finish”. ZPOS USER MANUAL 8-99...

  • Page 101: Audio Driver Installation

    HEISEI Electronics Co., Ltd. Audio Driver Installation The ZPOS is equipped with the Realtek HD Codec ALC888, which is with high-performance 7.1+2 Channel High Definition Audio Codecs providing ten DAC channels that simultaneously support 7.1 sound playback, plus 2 channels of independent stereo sound output (multiple streaming) through the front panel stereo outputs.

  • Page 102: Windows Vista

    HEISEI Electronics Co., Ltd. g. Select “Yes, I want to restart my h. Click audio icon on working bar. computer now” and click “Finish”. i. Select “Audio I/O” tab and click J. Mark “Disable front panel jack “Connector Settings” icon.
  • Page 103 HEISEI Electronics Co., Ltd. c. Click “Realtek” folder. d. Click “HD”. e. Click “Setup” to install the driver. f. Click “Next” to go on. g. Select “Yes, I want to restart my h. Click “Realtek HD Audio Manager”. computer now” and click “Finish”.

  • Page 104: Windows Wepos/Posready

    HEISEI Electronics Co., Ltd. i. Click “Connector Settings” icon. j. Select “Disable front panel jack detection” and click “OK”. 8.4.3 Windows WEPOS/POSReady a. Click “AUDIO” folder. b. Click “XP” folder. c. Click “Realtek” folder. d. Click “HD”. ZPOS USER MANUAL...
  • Page 105 HEISEI Electronics Co., Ltd. e. Click “Setup” to install. f. Click “Next”. g. Click “Browse” to find “Windows\ h. Click “Browse” to find “Windows\ system32\drivers” source to copy and system32\drivers” source to copy and click “OK”. click “Retry”. i. Select “Yes, I want to restart my j.
  • Page 106 HEISEI Electronics Co., Ltd. k. Select “Audio I/O” tab and click l. Mark “Disable front panel jack “Connector Settings” icon. detection” and click “OK”. ZPOS USER MANUAL 8-105...

  • Page 107: Wireless Lan Driver Installation

    HEISEI Electronics Co., Ltd. Wireless LAN Driver Installation The Users must make sure which operating system you are using in the ZPOS before installing the Wireless LAN drivers. Follow the steps below to complete the installation. You will quickly complete the installation. Follow the installation steps for Windows XP/VISTA/WEPOS/POSReady.

  • Page 108: Touch Screen Driver Installation

    HEISEI Electronics Co., Ltd. Touch Screen Driver Installation The ZPOS supports HIGGSTEC Touch. The touchscreen systems consist of a touchscreen and an electronic touchscreen controller. a. Click the file “Touch”. b. Click “All_In_One_2k_XP_Vista”. c. Click “setup” to install driver. d. Click “Next” to continue.
  • Page 109 HEISEI Electronics Co., Ltd. g. Click “OK”. h. Click “Next”. i. Click “Next”. j. Click “Next”. k. Click “Yes”. l. Click “Yes”. ZPOS USER MANUAL 8-108...
  • Page 110 HEISEI Electronics Co., Ltd. m. Press the blinking X Symbol until stop n. Click “OK” to complete the process. blinking. ZPOS USER MANUAL 8-109...

  • Page 111: Vfd Driver Installation

    HEISEI Electronics Co., Ltd. VFD Driver Installation Please install the VFD driver as follow steps. 8.7.1 Windows XP/ WEPOS/POSReady a. Click “VFD” folder. b. Click “PL-2303 Driver Installer” to install. c. Click “Next”. d. Click “Finish”. e. Right click “My Computer” and select f.

  • Page 112: Windows Vista

    HEISEI Electronics Co., Ltd. g. Click “OK”. h. Right click “My Computer” and select “Manage”. i. Right click “USB-Serial Controller D” j. Click “OK” and restart your computer. and select “Uninstall”. 8.7.2 Windows VISTA a. Click “VFD” folder. b. Click “vista_installer” to install.
  • Page 113 HEISEI Electronics Co., Ltd. c. Click “Next”. d. Select “I accept the terms of license agreement” and click “Next”. e. Click “Finish”. ZPOS USER MANUAL 8-112...

  • Page 114: Pci Card Driver Installation

    HEISEI Electronics Co., Ltd. PCI Card Driver Installation Please install PCI card driver as follow steps. 8.8.1 Windows XP/ WEPOS/POSReady a. Right click “My Computer” and select b. Right click “PCI Serial Port” and click “Manage”. “Update Driver…”. c. Select “Yes, this time only” and click d.
  • Page 115 HEISEI Electronics Co., Ltd. e. Click “Browse” to find “PCI\Windows_ f. Click “Finish”. XP-32” as the location to search and click “Next”. g. Select “Yes, this time only” and click h. Select “Install from a list or specific “Next”. location (Advanced)” and click “Next”.

  • Page 116: Windows Vista

    HEISEI Electronics Co., Ltd. 8.8.2 Windows VISTA a. Right click “My Computer” and select b. Right click “PCI Serial Port” and click “Manage”. “Update Driver Software”. c. Click “Browse my computer for driver d. Click “Browse” to find “PCI\Windows_ software”.
  • Page 117 HEISEI Electronics Co., Ltd. g. Click “Cancel”. h. Click “Cancel”. i. Right click “My Computer” and select j. Right click “16C95x Serial Port” and click “Manage”. “Update Driver Software”. k. Click “Browse my computer for driver l. Click “Browse” to find “PCI\Windows_ software”.
  • Page 118 HEISEI Electronics Co., Ltd. m. Click “Close”. n. Right click “My Computer” and select “Manage”. o. Right click “16C95x Serial Port” and p. Click “Browse my computer for driver click “Update Driver Software”. software”. q. Click “Browse” to find “PCI\Windows_ r.
