- Page 1 LIMITADOR DE VELOCIDAD/ OVERSPEED GOVERNOR/ LIMITEUR DE VITESSE/ GESCHWINDIGKEITSBEGRENZER / QUASAR-SV INSTRUCCIONES DE USO Y MANUTENCIÓN/ INSTRUCTIONS FOR USE AND MAINTENANCE/ INSTRUCTIONS D’USAGE ET ENTRETIEN/ GEBRAUCHS- UND WARTUNGSANLEITUNG...
-
Page 3: Table Of Contents
STORAGE AND SERVICE LIFE ......................8 INSTALLATION DRAWINGS .......................... 8 _________________________________________________________ Note: This manual displays partial information on the instructions for use and maintenance of this product. Please refer to the customer area in Dynatech’s website in order to consult the full manual; http://customers.dynatech-elevation.com/... -
Page 4: General Instructions
(e.g. nominal speed or rope type). c) To adjust any component of the overspeed governor, except for those parts specified in the manual. DYNATECH DYNAMICS & TECHNOLOGY, SL will not be liable for any damage caused by failure to observe any of these general conditions. -
Page 5: Working Principles
A diagram of the unit assembly is displayed below. Note: This manual displays partial information on the instructions for use and maintenance of this product. Please refer to the customer area in Dynatech’s website in order to consult the full manual; http://customers.dynatech-elevation.com/... - Page 6 The following figure displays an example of this connection. These parts are not supplied by the company DYNATECH, DYNAMICS & TECHNOLOGY, S.L. They must be designed in such a way that there are no clearances in the transmission and they do not cause extra movements.
-
Page 7: Quasar Sv's Tripping Settings
INSTRUCTIONS: QUASAR SV Code: DYN 64.1.06 Date: 08/11/2016 Revision: 06 For further information on the Quasar SV’s tensioning devices, please refer to the Quasar-SV’s Tensioners manual. 4.3 REMOTE TRIPPING SYSTEM The governor incorporates a remote jamming system to check for the correct interlocking of the governor and the subsequent jamming of the safety gear. -
Page 8: Ucm Uncontrolled Movement Device
If the D-Box is not used, please observe the following warnings and follow the recommendations below for proper controller design. Note. It is highly recommended that the controller designer contacts Dynatech before designing the circuit to manage the anti-creep system, to clarify any doubts regarding connections and to be recommended a specific solution for their installation ... -
Page 9: Fixing The Governor To The Frame
(the Dynatech D-Box makes 7 attempts before the error message appears that no reading for the control sensor is detected). -
Page 10: Technical Features
It is recommended to use the D-Box when using this device. Diverter pulley: Built in the governor. Note: This manual displays partial information on the instructions for use and maintenance of this product. Please refer to the customer area in Dynatech’s website in order to consult the full manual; http://customers.dynatech-elevation.com/... -
Page 11: Instructions For Use And Maintenance
On the other hand, Dynatech governors have anti-corrosion protection in all the cases; however, it is important that maintenance checks if there is a corrosion process that may affect any mobile part of the component and may prevent its natural movement.
