Vega DC Handbook
ENGLISH
General Safety Instructions:
READ SAFETY INSTRUCTIONS
Servicing:
These products are not customer serviceable. TDK-Lambda UK LTD. and their authorised agents only are
permitted to carry out repairs.
Critical Components:
These products are not authorised for use as critical components in nuclear control systems, life support
systems or equipment for use in hazardous environments without the express written approval of the
Managing Director of TDK-Lambda EMEA.
Product Usage:
These products are designed for use within a host equipment which restricts access to authorised competent
personnel.
This product is a component power supply and is only to be installed by qualified persons within other
equipment and must not be operated as a stand alone product.
This product is for sale to business to business customers and can be obtained via distribution channels.
It is not intended for sale to end users.
This product is a component power supply and does not fall within the scope of the EMC directive.
Compliance with the EMC directive must be considered in the final installation. Please contact your local
TDK-Lambda office.
Environmental:
These products are IPX0, and therefore chemicals/solvents, cleaning agents and other liquids must not be
used.
Environment:
This power supply is a switch mode power supply for use in applications within a Pollution Degree 2,
overvoltage category II environment. Material Group IIIb PCB's are used within it.
Output Loading:
The output power taken from the power supply must not exceed the rating stated on the power supply label,
except as stated in the product limitations in this handbook.
Input Parameters:
This product must be operated within the input parameters stated in the product limitations in this handbook.
End of Life Disposal:
The unit contains components that require special disposal. Make sure that the unit is properly disposed of at
the end of its service life and in accordance with local regulations.
This product is a component power supply and is only to be installed by qualified persons within other
equipment and must not be operated as a stand alone product.
This product is for sale to business to business customers and can be obtained via distribution channels.
It is not intended for sale to end users.
This product is a component power supply and does not fall within the scope of the EMC directive.
Compliance with the EMC directive must be considered in the final installation. Please contact your local
TDK-Lambda office
RISK OF ELECTRIC SHOCK
Page 1 of 23
17150 issue 17, October 2018

Advertisement

loading
Need help?

Need help?

Do you have a question about the Vega DC and is the answer not in the manual?

Questions and answers

Related Manuals for TDK-Lambda Vega DC

Summary of Contents for TDK-Lambda Vega DC

  • Page 1 General Safety Instructions: READ SAFETY INSTRUCTIONS Servicing: These products are not customer serviceable. TDK-Lambda UK LTD. and their authorised agents only are permitted to carry out repairs. Critical Components: These products are not authorised for use as critical components in nuclear control systems, life support systems or equipment for use in hazardous environments without the express written approval of the Managing Director of TDK-Lambda EMEA.
  • Page 2 An internal fuse protects the unit and must not be replaced by the user. In case of internal defect, the unit must be returned to TDK-Lambda UK LTD or one of their authorised agents. A suitable mechanical, electrical and fire enclosure must be provided by the end use equipment for mechanical, electric shock and fire hazard protection.

  • Page 3: Wartung

    Allgemeine Sicherheitsvorschriften: LESEN SIE DIE SICHERHEITSVORSCHRIFTEN Wartung: Diese Produkte können nicht durch den Kunden gewartet werden. Nur TDK-Lambda UK LTD. und deren zugelassene Vertriebshändler sind zur Durchführung von Reparaturen berechtigt. Kritische Komponenten: Diese Produkte sind nicht für die Verwendung als kritische Komponenten in nuklearen Kontrollsystemen, Lebenserhaltungssystemen oder Geräten in gefährlichen Umgebungen geeignet, sofern dies nicht...
  • Page 4 Produkt auf Erdschluss geprüft werden. Eine interne Sicherung schützt das Gerät und darf durch den Benutzer nicht ausgetauscht werden. Im Fall von internen Defekten muss das Gerät an TDK-Lambda UK LTD oder einen der autorisierten Vertriebshändler zurückgeschickt werden.

  • Page 5: Entretien

    Consignes générales de sécurité: LIRE LES CONSIGNES DE SECURITE Entretien: Ces produits ne peuvent pas être réparés par l’utilisateur. Seuls, TDK-Lambda UK LTD et ses agents agréés sont autorisés à effectuer des réparations. Composants critiques: Ces produits ne doivent pas être utilisés en tant que composants critiques dans des systèmes de commande nucléaire, dans des systèmes de sauvetage ou dans des équipements utilisés dans des environnements...
  • Page 6 Un fusible interne protège le module et ne doit pas être remplacé par l'utilisateur. En cas de défaut interne, le module doit être renvoyé à TDK-Lambda UK LTD ou l'un de ses agents agréés. Une enceinte appropriée doit être prévue par l'utilisateur final pour assurer la protection contre les chocs mécaniques, les chocs électriques et l'incendie.

  • Page 7: Manutenzione

    Questo alimentatore è da considerarsi come un componente e come tale non è assogettato dagli scopi della direttiva EMC. Conformità alla direttiva EMC deve essere considerata nell'installazione finale di utilizzo. Gli uffici di TDK-Lambda Sas Succursale Italiana sono a vostra disposizione per ulteriori ragguagli. Condizioni ambientali: Questi prodotti sono classificati come IPX0, dunque non devono essere utilizzati sostanze chimiche/solventi, prodotti per la pulizia o liquidi di altra natura.
  • Page 8 Un fusibile interno protegge l'unità e non deve essere sostituito dall'utente. Nell'eventualità di un difetto interno, restituire l'unità a TDK-Lambda UK LTD o a uno dei suoi agenti autorizzati. L'apparecchiatura finale deve includere una recinzione meccanica, elettrica e antincendio per proteggere dai pericoli di natura meccanica, dalle scosse elettriche e dai pericoli di incendio.
  • Page 9 Instrucciones generales de seguridad: LEA LAS INSTRUCCIONES DE SEGURIDAD Servicio: Estos productos no pueden ser reparados por los clientes. TDK-Lambda UK LTD. y sus agentes autorizados son los únicos que pueden llevar a cabo las reparaciones. Componentes fundamentales: Estos productos no pueden ser utilizados como componentes fundamentales en sistemas de control nuclear, sistemas de soporte vital o equipos a utilizar en entornos peligrosos sin el consentimiento expreso por escrito del Director General de TDK-Lambda EMEA.
  • Page 10 Un fusible interno protege la unidad y este no debe ser nunca reemplazado por el usuario. En caso de existir algún defecto interno, la unidad debe ser enviada a TDK-Lambda UK LTD o a uno de sus agentes autorizados.
  • Page 11 Instruções gerais de segurança: LEIA AS INSTRUÇÕES DE SEGURANÇA Manutenção: Estes produtos não são podem ser submetidos a manutenção por parte do cliente. Apenas a TDK-Lambda UK LTD e os seus agentes autorizados têm permissão para realizar reparações. Componentes essenciais: Não é...
  • Page 12 Existe um fusível interno que protege a unidade e que não deve ser substituído pelo utilizador. Em caso de defeito interno, a unidade deve ser devolvida à TDK-Lambda UK LTD ou a um dos seus agentes autorizados. O equipamento de utilização final deve fornecer um bastidor com protecção mecânica, eléctrica e contra incêndios adequada.

  • Page 13: Environmental Specifications

    Fast-ons Terminal block If the earth terminal of the Vega DC PSU is connected to the main incoming earth conductor of the end equipment, the installer must cover the earth symbol with a label bearing the earth symbol of IEC60417-5019.
  • Page 14 Vega DC Handbook Products Covered: Unit Configuration Code: V0, K0 or Vega DC (may be prefixed by NS - # / or - where # may be any characters indicating non-safety related model differences. followed by: F, R or C...
  • Page 15 Vega DC Handbook X1, X2, X4 or X8 where the number relates to the maximum voltage capability of the X module in accordance with X1=10V, X2=20V, X4=40V, X8=80V. The X module is connected to the output terminals of D or E modules, which may be connected in series or parallel.
  • Page 16 <40A AT 25°C Adjustment and Derating: The Vega DC series is designed to provide a max power of 450W at nominal output voltages. The following procedurre must be used to ensure the PSU is operated within its ratings: -Calculate user power for each module (volts x amps) -Add all individual module powers together.
  • Page 17 Vega DC Handbook Setting for Rated Occupied Secondary Ampere Module Output Voltage Power Current Hazardous Current Slots Turns Turns Limit Energy H1H/2 3.9-5.5/5-9V 12A/6A 66W/54W 12/12 15A/9A H1L/3 1.8-3.8/9.1-16.2V 12A/6A 46W/98W 12/18 15A/9A H1H/3 3.9-5.5/9.1-16.2V 12A/6A 66W/98W 12/18 15A/7.5A H1L/4 1.8-3.8/16.3-25V 12A/4.5A 46W/113W...
  • Page 18 Vega DC Handbook Setting for Rated Occupied Secondary Ampere Module Output Voltage Power Current Hazardous Current Slots Turns Turns Limit Energy 8 - 16.5V 45.6A 752W 136.8/13 >4V (D3+D3) 4.5 - 5.5V 66.5A 366W 66.5/66. 87.5A >2.7V (L1+L1) Note 1: Actual voltage and current output of an X module is dependent, and limited by, the ratings of the modules from which it is fed.
  • Page 19 Vega DC Handbook Cooling Input Voltage Max AT Module Option Ambient Power (total) Current Rating 100% 100% 44 - 75 100% 100% 100% 44 - 75 100% See Customer Air Cooling section for ratings Power and AT (Ampere Turns) ratings may be interpolated.
  • Page 20 Vega DC Handbook Mechanical Outline Drawings: Primary Options Specified Option Pin 5 Logic 0 Pin 6 Logic 1 Inhibit Outputs OFF Outputs OFF Enable Outputs ON Outputs ON Logic 0 = 0-0.8V Logic 1 = 2-5V with respect to 0V (Pin 3)
  • Page 21 Vega DC Handbook Inhibit Internally is a 390Ω resistor in series with diode of an optocoupler. ≥ 2µΑ Drive to inhibit module (max 13mA) Module Good TWIN Output Module “N” Option Page 21 of 23 17150 issue 17, October 2018...
  • Page 22 Vega DC Handbook TWIN Output Module “R” Option Customer Fixings Customer Air and Fixing Detail Page 22 of 23 17150 issue 17, October 2018...
  • Page 23 Vega DC Handbook Right Angle Screw Terminal Input TDK-Lambda UK Ltd Kingsley Avenue, Ilfracombe Devon, EX34 8ES Telephone - Sales and Service +44 (0)1271 856666 Head Office and Works +44 (0)1271 856600 Facsimile +44 (0)1271 864894 WEBSITE: www.uk.tdk-lambda.com Page 23 of 23...
