Summary of Contents for AGPtek V88
-
Page 2: Table Of Contents
CONTENT 1 Remote Control........................1 2 Front and Rear Panel......................2 2.1 Front Panel ........................2 2.1 Rear Panel........................2 3 Installation .......................... 3 4 DTV Mode...........................4 4.1 Initialization ........................ 4 4.2 Channel & Left and Right Channel Switching .............. 5 4.3 EPG (Electric Program Guide)..................6 4.4 Teletext ......................... -
Page 3: Remote Control
1. Remote Control Photograph Function POWER Standby /On SUB-T Subtitle display option Switch on teletext (press EXIT to switch off) MUTE Switch on/off volume Shows the Electronic Program Guide GOTO Go to desired time in multimedia file PAGE+/PAGE- To navigate inside the menu REPEAT Repeat multimedia file playback LANG... -
Page 4: Front And Rear Panel
2. Front and Rear Panel 2.1 Front Panel VOL+ VOL- MENU STANDBY ON/OFF USB 2.0 PORT 2.2 Rear Panel RF IN RF LOOP THROUGH S/PDIF (COAXIAL) HD-OUT TV SCART POWER ON/OFF 240V) 7 POWER INPUT(AC 100-... -
Page 5: Installation
3. Installation... -
Page 6: Dtv Mode
4. DTV Mode 4.1 Initialization Initialization is needed for the first-time entry into the system by setting language, country time zone, active antenna and channel number, etc. After finishing setting, choose [Start Search] and press [ENTER] to scan channels, and all available channels will be reserved automatically. Menu display as follows: Pic 4.1 Initialization... -
Page 7: Channel & Left And Right Channel Switching
Channel & Left and Right Channel Switching 4.2.1. Under full-screen state, press [AUDIO] to match the language of the current program and show left& right Channel list: Pic 4.2 Channel and left & right Channel list 4.2.2. Press [LEFT/RIGHT] to choose left & right channel or stereo; press[UP/DOWN] to choose language；... -
Page 8: Epg (Electric Program Guide)
4.3 EPG (Electric Program Guide) 4.3.1 Press [EPG] to check Program information: Pic 4.3.1 EPG Menu Default EPG menu shows NOW/NEXT Mode, including 7 parts: 1) Mark 1 shows current EPG state; 2) Mark 2 shows current time and program information; 3) Mark 3 shows detailed date;... - Page 9 4.3.2 Press Red Key to entry Daily Mode: Pic 4.3.2 Daily Mode 1) Press Yellow Key Blue Key can change from Monday to Sunday. Green Key 2) Select playing TV shows, press to record...
- Page 10 4.3.3 Press Red Key to entry Weekly Mode: Pic 4.3.3 Weekly Mode 1) Press [LEFT/RIGHT] to switch windows. Yellow Key Blue Key 2) Press to switch TV programs of yesterday or tomorrow.
-
Page 11: Teletext
4.4 Teletext Press [TTX] to entry program menu 4.4.1 Input page number(100 - 899) in Teletext to turn over; 4.4.2 Press [UP/DOWN] and [PAGE+/-] to switch pages; 4.4.3 Long press [UP/DOWN] for fast switch pages; 4.4.4 Press [ENTER] to change the transparency of TTX; 4.4.5 Pres [LEFT/RIGHT] to switch to Subpage of current page, if choose[AUTO],it will switch to Subpages automatically;... -
Page 12: Main Menu
5. Main menu Main menu includes Installation, Channel, Preference, Setting, AV, Multimedia Pic 5 5.1 Installation [Installation] includes Auto Search, Manual Search, Channel Filter, Country, .LCN, Active Antenna. Notice: This menu cannot be chose in Multi-media Mode. Pic 5.1 Installation... -
Page 13: Auto Search
5.1.1 Auto Search Press [UP/DOWN] to choose [Auto Search] and then press [ENTER] or [right], it will show a message to ask you: whether delete previous TV programs. Choose [YES] to enter [Auto search]: Pic 5.1.1 Confirm Auto Search Pic 5.1.1.1 Auto Search System will scan programs and reserve them automatically:... -
Page 14: Manual Search
5.1.2 Manual Search Pic 5.1.2 Manual Search 5.1.2.1 Press [UP/DOWN] to choose [Manual Search] and then press [ENTER] or [RIGHT]: 5.1.2.2 Deploy the parameters before manual scan, including following three parameters: 1) Channel NO.: scanning station ID, every country has some default station ID, you can modify it by using number key (0 - 9), if the station ID was set up, other two parameters are no need to set;... -
Page 15: Channel
5.2 Channel [Channel] has two options, including [Channel Manager] and [Favorite List]. In the [Main Menu], press [UP/DOWN] to choose [Channel] and press [ENTER] or [RIGHT]. As picture 5.2 shows: Pic 5.2 Channel... -
Page 16: Preference
5.3 Preference [Installation] includes OSD Language, OSD Timeout, 1st Preferred Subtitle, 2nd Preferred Subtitle, Hard Hearing, 1st Preferred Audio, 2st Preferred Audio. Pic 5.3 OSD Language Setting [OSD Language] is mainly used to change the language of menu and tips. Press [UP/DOWN] to choose language and then press [ENTER] to confirm. -
Page 17: Setting
5.4 Setting [Setting] is used to set up or upgrade system, including Timers, Child Lock, Date Time, Factory Reset, Upgrade, Version, Auto Standby. Pic 5.4 Setting... -
Page 18: Timers
5.4.1 Timers Timers is used to manage and edit the reserved program. In timers menu, you can edit program name, starting time and type of reserved program. From left to right are: number, program name, date, time, mode, reserved type. Pic 5.4.1 Timer List Press [OK] to enter timer edit interface: Pic 5.4.1.1 Timer Edit... - Page 19 1) [Date] is used to set up appoint date, if you want to change date, after choosing [DATE], press [RIGHT] to edit; 2) [Program Name] is the name of appointed program, if you want to change name, after choosing [Program Name], press [RIGHT] to edit; 3) [Start Time] is used to set up the appointed time, if you want to change time, after choosing [Start Time],press[RIGHT] to edit;...
- Page 20 8) [AD Record], [Subtitle Record], [Teletext Record] can be set up only when the [Type] is Recorder, for selecting whether burn AD,TTX and Subtitle or not.
-
Page 21: Child Lock
5.4.2 Child Lock [Child Lock] is for setting up Child Lock and limit program to avoid that children contact with some unsuitable information. Choose [Child Lock] and then press [ENTER], password input box will be popped up, and then input the correct password (The default password is 0000) to enter the menu, as picture 5.4.2 shows: Pic 5.4.2 Child Lock... -
Page 22: Factory Reset
Pic 5.4.2.1 Change Pin Code Enter the old correct password, and then enter the new password twice to confirm. 5.4.3 Factory Reset [Factory Reset] is for restoring the system to factory settings, press [UP/DOWN] and choose the [Factory Reset], and then press [ENTER], after popping up password input box, input the correct password (the default is 0000), the system will restore to factory settings, after that, it will pop up systematic initial menu and guide the system to reinitialize. -
Page 23: Upgrade
5.4.4 Upgrade [Upgrade] can be choosed in [Main Menu]->[Setting]->[Upgrade] like the picture 5.4.4.1: Pic 5.4.4.1 Upgrade... - Page 24 There are three ways to support upgrade. They are USB/Card Upgrade, OTA Upgrade, IRD Upgrade. Select [USB/Card Upgrade], press [ENTER], if you didn't connect to USB equipment, it will give message; otherwise, it will show as below: Pic 5.4.4.2 USB/Card Upgrade...
- Page 25 Select rom.bin as storage area. Press [ENTER] and then choose rom.bin, pres s [ENTER] again and start using USB to upgrade, as picture shown below: Pic 5.4.4.3 USB Upgrade Flow After finishing USB Upgrade, the system will restart automatically.
-
Page 26: Av Setting
5.5 AV Setting [AV] is for setting up the related options about video output, brightness, resolution, output format, etc. In [Main Menu], press [UP/DOWN] to choose [AV], press [ENTER] to enter [AV], as picture 5.5 shows: Pic 5.5 AV Setting... - Page 27 5.5.1 Video Resolution [Video Resolution] is for setting up output video resolution and refresh rate, it supports up to 1080p_60 (Full HD). After choosing [Video Resolution], press [ENTER], it will pop up the select list, as picture5.5.1 shows: Pic 5.5.1 Video Resolution List includes the following options (P represents line-to-line scan, i represents interlaced scan): 1) 480: P_60,i_30...
-
Page 28: Multimedia Mode
5. 6 Multimedia Mode 5.6.1 [Multimedia Mode] is for viewing and editing media in the USB flash disk inserted. You can switch to [Multimedia Mode] by choosing [Main Menu]->[Media Center]->[Multimedia]. After choosing [Multimedia Mode], press [ENTER], it will check whether there is USB (CARD) equipment automatically. - Page 29 5.6.2 Insert a USB flash disk and the initialization will be processed automatically Pic 5.6.2 USB (CARD) Equipment 5.6.3 And then you can enter the Multimedia List, including Movie/ Music/ Photo/ Record Manager/ Disk Manager/ EBook. The partitions supported includes: FAT FAT32 and NTFS. Pic 5.6.3 Multi-media List...
- Page 30 5.6.4 Press [Menu] to set up the multimedia playback, including: 1) [Movie Repeat]: Select loop mode when playing a video file: Dir (play by list), One, OFF. 2) [Music Repeat]: Select loop mode when playing an audio file: Dir (play by list), One, OFF.
-
Page 31: Record & Timeshift
6. Record & Timeshift 6.1 Record Under full-screen state, if you want to record the television program, please press [REC]. If you haven’t inserted any USB Flash disk (CARD), it will show as pic 7.1: Pic 6.1 Without USB (CARD) DISK... - Page 32 When USB Flash disk (CARD) inserted, it will initialize and start to record, like the pic 6.1.1. If you want to stop recording, please press [STOP]; if you want to suspend record, please press [PAUSE], like pic 6.1.2: Pic 6.1.1 USB (CARD) Initialization Pic 6.1.2 Record Suspension...
- Page 33 While recording, press [INFO] and it can show detailed information, when press [INFO] again, it will show the list of what you are recording, like pic 6.1.3: Pic 6.1.3 Record List...
-
Page 34: Timeshift
6.2 Timeshift Timeshift is for previous TV program playback. You can make the setting in [Main Menu]->[Media Center]->[PVR Config],like the picture 6.2: Pic 6.2 PVR Config [Timeshift] has three options: 1) Auto: when you are in optional channels, it will open Timeshift automatically;...
