12. Slide the Right and Left Handrail Grips (74, 79)
over the Right and Left Handrail Covers (not
shown) and against the console assembly (F).
Attach the Handrail Grips (74, 79) with two
#8 x 1/2" Screws (1); do not overtighten the
Screws.
13. Hold the Pulse Bar (85) near the console assem-
bly (F). Connect the two console wires (G).
See the inset drawing. Connect the two pulse
wires (H, I) on the left side of the Pulse Bar (85).
Use the included tie (J) to attach the pulse wires
to the post on the underside of the Pulse Bar.
Attach the Pulse Bar (85) to the Pulse Crossbar
(93) with eleven #8 x 1/2" Screws (1); start all
eleven Screws, and then tighten them. Make
sure that no wires are pinched.
12
F
79
1
13
85
I
H
93
1
1
J
I
85
H
15
1
74
F
G
1
