6. Attach a Handrail (84) to the Right Upright (90)
with a 5/16" x 2 1/2" Screw (28) and a 5/16" Star
Washer (11) in the location shown. Make sure
not to pinch the Upright Wire (81). Do not

fully tighten the Screw yet.

Attach the other Handrail (not shown) to the
Left Upright (89) in the same way. Note: There
are no wires on the left side.
Then, remove the two indicated screws (E) from
each Handrail (84) (only one Handrail is shown).
Discard the Screws.
7. IMPORTANT: To avoid damaging the Pulse
Crossbar (93), do not use power tools and do
not overtighten the #10 x 3/4" Screws (9).
Orient the Pulse Crossbar (93) as shown. Attach
the Pulse Crossbar to the Handrails (84) with
four #10 x 3/4" Screws (9) and four #10 Star
Washers (5); start all four Screws, and then
tighten them. Make sure not to pinch the
Upright Wire (81).
Next, tighten two 5/16" x 2 1/2" Screws (28)
with two 5/16" Star Washers (11) into the Pulse
Crossbar (93) as shown.
Firmly tighten the four 5/16" x 2 1/2" Screws
(28).
Then, remove the wire tie (A) from the Upright
Wire (81).
6
84
89
81
7
28
11
9
5
28
84
12
28
11
E
90
93
81
84
A
28
11
9
5
28
