M7220
Wireless Terminal
Quick-Start Guide
800.648.4452
www.amltd.com
05012013
Getting Started
1
Load the main battery
1.
2.
Turn the access latch
counter-clockwise
door by hinging it upward
3.
4.
Turn the access
Insert battery in rear and slide
latch clockwise
towards the front to engage
1
2
Front and Bottom View
Scan Key
Power Key
RS-232
2
Charge the M7220 for
at least 4 hours
Remove the battery
LCD
Backlight Key
USB Port
Bottom
Getting Started
5V DC
Power Jack
Battery Charge Times
Before Initial Use =
4 hours
For Full Charge =
6 hours
Back and Top View
Laser Safety
Label
Battery
Latch
Battery
Door
Scan Engine
Top p
Window
Getting Started
3
Learn More about
the AML M7220
Download the M7220 data sheet, User
Manual, Firmware and Utility Software
online at
www.amltd.com/support.asp
or
Give us a call at
800.648.4452
Get Updates from AML
Don't forget to register your product(s)
online at
www.amltd.com/register
receive updates about AML products
and software.
to
