ECA3290 series
Chapter 2 :
•Installation Guide
2.1
How to Remove Both Side Panels
1
Chapter 1 :
•Product Overview
User's Manual
1.1
Product View
Top
Front
2.2
How to Install
A
C
2
UNLOCKED
3
Reset
HDD LED
USB
USB
Microphone
Haedphone
Rear
Left
Right
Optical Drive
B
D
LOCKED !
Notice
To lock ODD, slide it until
hearing click sound.
1.2
Specs
Model Name
ECA3290B
Dimensions (mm)
Material
M/B
Power Supply
Power
5.25"
Drive Bays
3.5"
Power LED
2.5"
2 (converted from 2 x 3.5")
I/O
Front
Rear
Cooling
Side
Top
Bottom
Expansion Slots
*Product specifiations are subject to change without notice.
*Options vary by countries or regions. For detailed information please visit our website at www.enermax.com
How to install device to the 3rd drive bay (ECA3290B)
Remarks:
ECA3290A
D487 x W234 x H488
SECC 0.5~0.6mm
Micro ATX, ATX
ATX 12V (Optional)
3
3
5 x Hidden
7 x Hidden
4 (converted from 4 x 3.5")
USB 3.0 x 2 (w/internal 19-pin &
one USB3.0 to USB2.0 converter
12cm fan x 2
12cm fan x 1
Acrylic window
14/12cm fan x 2 or UCTA18A/UCTVQ18A x 1
12cm fan x 1
7
Backside
