OWNER'S MANUAL
620 Monster Moto Trail
support@megamotousa.com
IF YOU HAVE PROBLEMS, DO NOT RETURN TO STORE!
CONTACT MEGA MOTO AT 855-833-6483
OR SUPPORT@MEGAMOTOUSA.COM
Failure to follow the instructions in this manual could result in
serious injury or death. Failure to follow the instructions in this
manual could also prevent the mini bike from operating properly.
This owner's manual contains important information. Each rider
of the mini bike must read this owner's manual thoroughly before
riding the mini bike for the first time and must always follow all of the
instructions outlined in this manual. This manual must remain with
the vehicle if the vehicle is transferred to a new owner. Do not discard
this owner's manual as it must be reviewed by each rider prior to his
or her operation of the vehicle. If a minor is operating the vehicle, it
is the responsibility of the minor's guardian to ensure that the minor
understands the information contained in this manual.
This manual contains the latest product information available before
printing. You may view the most recent version of this owner's manual
online at www.megamotousa.com. Due to product improvements
or production changes, there could be discrepancies between the
information contained in this owner's manual and actual product
specifications. Mega Moto reserves the right to make changes to its
products at any time without notice and without obligation to make
the same or similar changes to any vehicle previously built or sold.
© Mega Moto
No part of this publication may be reproduced or copied without written permission from Mega Moto.
1
MINI BIKE
MM-B212 & MEGA MAX 212
MEGA MOTO
Ruston, LA 71270
855-833-6483
www.megamotousa.com

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the MEGA MAX 212 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Megamoto MEGA MAX 212

Summary of Contents for Megamoto MEGA MAX 212

  • Page 1 MINI BIKE MM-B212 & MEGA MAX 212 OWNER’S MANUAL MEGA MOTO 620 Monster Moto Trail Ruston, LA 71270 855-833-6483 support@megamotousa.com www.megamotousa.com IF YOU HAVE PROBLEMS, DO NOT RETURN TO STORE! CONTACT MEGA MOTO AT 855-833-6483 OR SUPPORT@MEGAMOTOUSA.COM Failure to follow the instructions in this manual could result in serious injury or death.

  • Page 2: Table Of Contents

    PROBLEMS? DO NOT RETURN TO STORE! CALL US AT TABLE OF CONTENTS Introduction ......................3 Laws & Regulations ....................4 Maintenance Requirements ................4 Safety .......................... 5 Basic Operation: Starting, Riding, Stopping & Storing The Mini Bike ..8 Maintenance Procedures ................... 12 Fuel ..........................11 Clutch Bushing ....................13 Engine Oil......................

  • Page 3: Introduction

    855-833-6483 OR EMAIL US AT SUPPORT@MEGAMOTOUSA.COM! INTRODUCTION Congratulations on the purchase of your new Mega Moto MM-B212! We hope that your new mini bike provides years of fun experiences and epic moments. Mega Moto is dedicated to providing you with an exceptional experience. If you are not happy with your mini bike, don’t return it! Instead, contact Mega Moto at 855-833-6483 or info@megamotousa.com, and we will do our best to provide you with outstanding customer support.

  • Page 4: Laws & Regulations

    PROBLEMS? DO NOT RETURN TO STORE! CALL US AT LAWS & REGULATIONS It is the responsibility of any rider of this vehicle to be familiar with and fully comply with all laws, rules, and regulations governing the operation of this vehicle. Laws vary by jurisdiction.

  • Page 5: Safety

    855-833-6483 OR EMAIL US AT SUPPORT@MEGAMOTOUSA.COM! SAFETY The MM-B212 mini bike has the potential to cause serious injury or death. Although the risks associated with riding a mini bike can never be eliminated completely, following all of the instructions contained in this manual will reduce the risk of harm to the operator and others.
  • Page 6 PROBLEMS? DO NOT RETURN TO STORE! CALL US AT WARNING: Never ride the mini bike if it is not in proper riding condition. Always inspect your mini bike before you ride to ensure that it is in proper riding condition. If you have any indication that your mini bike is not running correctly, stop riding immediately.
  • Page 7 855-833-6483 OR EMAIL US AT SUPPORT@MEGAMOTOUSA.COM! BREAKING IN YOUR MINI BIKE To protect your new engine, enjoy optimum performance, and extend the life of the vehicle, break in your mini bike properly. To do this, avoid full throttle starts and rapid acceleration for the first fifteen miles.

  • Page 8: Basic Operation: Starting, Riding, Stopping & Storing The Mini Bike

    PROBLEMS? DO NOT RETURN TO STORE! CALL US AT BASIC OPERATION: STARTING, RIDING, STOPPING & STORING THE MINI BIKE VEHICLE IDENTIFICATION NUMBER (ETCHED INTO METAL PLATE ON SIDE OF MINI BIKE FRAME BELOW HANDLEBARS) CHOKE LEVER (LEFT IS START/RIGHT IS RUN) FUEL VALVE LEVER (LEFT IS OFF/RIGHT IS ON) ENGINE NUMBER...
  • Page 9 855-833-6483 OR EMAIL US AT SUPPORT@MEGAMOTOUSA.COM! INSPECTING YOUR MINI BIKE Before turning on and riding your mini bike, inspect the vehicle to ensure it is in proper operating condition: Examine the tires for proper inflation and to detect excessive wear. »...
  • Page 10 PROBLEMS? DO NOT RETURN TO STORE! CALL US AT RIDING YOUR MINI BIKE » To Go: The speed of the mini bike is controlled by the throttle. Twisting the throttle towards the rider increases the speed of the mini bike and releasing pressure from the throttle causes the mini bike to gradually slow down until it comes to a stop.

  • Page 11: Maintenance Procedures

    855-833-6483 OR EMAIL US AT SUPPORT@MEGAMOTOUSA.COM! MAINTENANCE PROCEDURES FUEL FUEL TANK FUEL CAP FUEL FILLER NECK ADDING FUEL Before each ride, check the mini bike’s fuel level and add fuel if necessary. The 212 cc engine is equipped with a low oil level sensor. If the oil level is the low the engine will not start.
  • Page 12 PROBLEMS? DO NOT RETURN TO STORE! CALL US AT 4. Screw the fuel cap back onto the fuel tank and tighten it securely. 5. Using a cloth, wipe away any spilled fuel. CLEARING A FLOODED ENGINE If the engine fails to start after repeated attempts, it may be flooded with excess fuel.

  • Page 13: Clutch Bushing

    855-833-6483 OR EMAIL US AT SUPPORT@MEGAMOTOUSA.COM! CLUTCH OIL PROCEDURE CLUTCH COVER LUBRICATING THE CLUTCH BUSHING 1. Remove the rubber plug from the clutch cover. Cover shown with plug removed.
  • Page 14 PROBLEMS? DO NOT RETURN TO STORE! CALL US AT 2) Drip several drops of 10W30 motor oil on the clutch hub behind the silver washer. Make sure the oil drips on top of and behind the circlip. 3) Let the oil seep into the clutch bush- ing for several minutes before starting the bike.

  • Page 15: Engine Oil

    855-833-6483 OR EMAIL US AT SUPPORT@MEGAMOTOUSA.COM! ENGINE OIL Oil Filler Cap Dipstick Upper Mark OIL FILLER CAP & OIL DRAIN BOLT Lower Mark OIL FILLER HOLE & OIL TANK CHECKING & ADDING ENGINE OIL Before each ride, check the mini bike’s engine oil level and add oil if necessary. The 212cc engine is equipped with a low oil level sensor.
  • Page 16 PROBLEMS? DO NOT RETURN TO STORE! CALL US AT screw it in. 7. Remove the oil filler cap and check for dark-colored oil on the dipstick. If the oil level is at or near the upper mark, you do not need to add oil. If the oil level is at or near the lower mark, continue to step 8.

  • Page 17: Air Filter

    855-833-6483 OR EMAIL US AT SUPPORT@MEGAMOTOUSA.COM! AIR FILTER AIR FILTER AIR FILTER AIR FILTER COVER WING NUT (AIR FILTER COVER HAS BEEN REMOVED) CLEANING THE AIR FILTER The mini bike’s air filter must be clean in order for the mini bike to operate properly. Inspect the air filter in your mini bike as part of your regular maintenance routine and clean it whenever it appears dirty.

  • Page 18: Brakes

    PROBLEMS? DO NOT RETURN TO STORE! CALL US AT BRAKES BRAKE FLUID LEVEL INDICATOR BRAKES Your MM-B212 mini bike is equipped with front and rear disc brakes. Your Mega Max 212 is equipped with a rear disc brake. If you cannot stop your mini bike properly, you need to check for proper fluid level.

  • Page 19: Tires

    855-833-6483 OR EMAIL US AT SUPPORT@MEGAMOTOUSA.COM! TIRES INSPECTING YOUR TIRES Regularly perform an in-depth inspection of your tires as part of your mainte- nance routine. Park the mini bike on a firm, level surface and turn the engine stop switch to the “off” position. Look for bumps or bulges in the sidewall of the tire and inside of the treads.

  • Page 20: Drive Chain

    TENSIONER ADJUSTMENT ADJUSTING THE DRIVE CHAIN For the Mega Max 212: The drive chain has an automatic adjuster that will maintain the proper chain adjustment. Once the Chain has worn to the point that the chain becomes too loose it is time to change the chain and sprockets.

  • Page 21: Maintenance Chart

    855-833-6483 OR EMAIL US AT SUPPORT@MEGAMOTOUSA.COM! LUBRICATING THE DRIVE CHAIN The drive chain needs to be properly lubricated in order for the mini bike to oper- ate properly. Normal use of the mini bike will cause the chain to dry and rust over time, therefore it is necessary to lubricate the chain as part of routine mainte- nance.

  • Page 22: Troubleshooting

    PROBLEMS? DO NOT RETURN TO STORE! CALL US AT TROUBLESHOOTING If you are having problems with your mini bike, please reference the troubleshoot- ing steps below. If you have completed all of the troubleshooting steps and your mini bike is still not running properly, contact Mega Moto at 855-833-6483 or support@megamotousa.com or take your mini bike to an Authorized Mega Moto Service Center.
  • Page 23 855-833-6483 OR EMAIL US AT SUPPORT@MEGAMOTOUSA.COM! IF THE MINI BIKE IS NOT PERFORMING WELL POTENTIAL PROBLEM SOLUTION Improper choke operation Ensure that the choke lever is in the correct position. See Starting Your Mini Bike on page 9 to ensure you are operating the choke correctly.

  • Page 24: Warranties

    PROBLEMS? DO NOT RETURN TO STORE! CALL US AT WARRANTIES LIMITED WARRANTY WHAT IS COVERED Mega Moto warrants only to the original retail purchaser of this product that this product is free from defects in material and/or workmanship for a period of ninety (90) days from the date of purchase.

  • Page 25: Emissions Control Warranty

    855-833-6483 OR EMAIL US AT SUPPORT@MEGAMOTOUSA.COM! by the Environmental Protection Agency, Mega Moto makes no other warranty of any kind, express or implied. All implied warranties of merchantability and fitness for a particular purpose which exceed the obligations and time limits stated in this warranty are disclaimed and excluded from this warranty.

  • Page 26: Specifications

    PROBLEMS? DO NOT RETURN TO STORE! CALL US AT MM-B212 SPECIFICATIONS RECOMMENDATIONS Recommended Age 16 + Recommended Max Weight 200lb Recommended Fuel Type Unleaded 87 Octane Gasoline Recommended Engine Oil Type SAE 10W-30 SPECIFICATIONS Engine Displacement 212 cc Strokes per Cycle Four Stroke Cylinder Head Configuration Overhead Valve (OHV)
  • Page 27 PROBLEMS? DO NOT RETURN TO STORE! CALL US AT 855-833-6483 OR EMAIL US AT SUPPORT@MEGAMOTOUSA.COM! Mega Max 212 SPECIFICATIONS RECOMMENDATIONS Recommended Age 16 + Recommended Max Weight 200lb Recommended Fuel Type Unleaded 87 Octane Gasoline Recommended Engine Oil Type SAE 10W-30...

  • Page 28: Registration

    PROBLEMS? DO NOT RETURN TO STORE! CALL US AT MINI BIKE MM-B212 & MEGA MAX 212 PRODUCT REGISTRATION Mega Moto 620 Monster Moto Trail Ruston, LA 71270 855-833-6483 support@megamotousa.com www.megamotousa.com Please help us serve you better by registering your new mini bike. You may register your product by calling us at 855-833-6483, by emailing us at support@megamotousa.com, or by mailing the registration form below to us at...
  • Page 29 855-833-6483 OR EMAIL US AT SUPPORT@MEGAMOTOUSA.COM! Thanks for choosing Mega Moto!
