- Page 1 Single Trumpet Mini Air Horn 10105 & 10123 Installation Instructions...
-
Page 2: Tools Required For Installation
Tools Required for Installation: • Phillips-Head Screwdriver • 7/16” Drill Bit • Electric Drill • Soldering Gun & Solder (Optional) • Crimping/Cutting Pliers • Silicone Sealant If any hardware components are missing, please contact Marinco Customer Service at 1-800-307-6702. www.marinco.com 800.307.6702... - Page 3 3) Slide the clamp ring forward until it is snug around the trumpet. 4) Finish tightening the machine screw and nut. 5) Place the gasket under the base of the support bracket and attach the bracket to the deck with two #10 size pan-head set screws of appropriate length. www.marinco.com 800.307.6702...
- Page 4 Single Trumpet Mini Air Horn 10105 & 10123 www.marinco.com 800.307.6702...
- Page 5 Do not over lubricate. Let the oil set for a few minutes and then activate the compressor momentarily to distribute the oil. Failure to activate the compressor before re-connecting the air hose may result in oil being blown onto the horn diaphragm and contaminating it. 6) Re-connect the air hose. www.marinco.com 800.307.6702...
- Page 6 3) Connect the wires as shown in the wiring diagram. It is recommended that the quick-connect tabs be soldered to the stranded wire for the best and most reliable connection to the compressor. Suggestion: Use the Marinco Direct Connect Multi Connection Battery Terminals (Part #12VTR) to connect the wiring to the battery.
- Page 7 Inspect the diaphragm for contamination. If there is dirt or oil on it, clean with a soft dry cloth and re- install. In the unlikely event that the diaphragm is torn, call Marinco customer service for replacement part #20147.
- Page 8 Warranty information: www.marinco.com/limited-warranty www.marinco.com 800.307.6702 12/2012 20140...
