Orion CS12 Installation And Operating Instructions

Fed up with your Compressor Pressure Switch?
The CS12 from Orion offers you Peace of Mind and Unbeatable Features!
Ready to Use, Easy to Fit,
No Special Mounting
2 Ground Screws enable you to
"Just Fit it, Set it and Forget it!"
Corrosion Resistant
Non Metallic Cover
Protects and Lasts...
Non Additional Relays,
No Extra Circuitry
You can use just a three-phase switch.
Manual Cut-Off
Separate Auto Cut-Off
Disconnect Lever.

Salient Features

Separate an auto-off disconnect lever for
manual cut off of the compressor.
Three Phase Pressure Switches can be used
instead of a motor starter pressure switch
combination. No need for additional relay or
any other circuitry.
2 Ground Screws
Available in ready to use condition.
Special Unloader valve is provided which
prevents compressor from starting under
load.
No Special Mounting required.
Corrosion Resistant and Non Metallic cover.
PRESSURE SWITCHES
PRESSURE DIFFERENCE SWITCHES
VACUUM SWITCHES
Switch to CS12

Technical Specifications

Sensing Element - Nitrile Rubber.
Pressure Range 2 ~ 12 bar.
Factory setting 6~ 8 bar.
Input Pressure Port 1/2" BSP Female
Differential between 1.5 bar ~ 4 bar 4 bar (Maximum)
Relief valve 6 mm dia.
Cable Leading 11.5 & 14.5 mm diameter.
Electrical Rating 16 A, 500 V AC
Protection - IP 44.
The 'Fit it, Set it, Forget it'
Compressor Pressure Switch
only from
