Adcraft HCD-5 Operating Instructions Manual

5/10 liter hot chocolate dispenser
Hide thumbs

Advertisement

Table of Contents

Chocofairy

OPERATING INSTRUCTIONS

Read these operating instructions carefully before using the machine
MANUALE ISTRUZIONI
Leggere attentamente queste istruzioni d'uso prima di utilizzare la macchina
MANUAL DE EMPLEO
Leer atentamente estas instrucciones de uso antes de utilizar la máquina
BETRIEBSANLEITUNG
Diese Bedienungsanleitung ist vor dem ersten Gebrauch der Maschine
aufmerksam zu lesen
MODE D'EMPLOI
Lire attentivement ce mode d'emploi avant d'utiliser la machine
SL
04/2010

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the HCD-5 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Adcraft HCD-5

Summary of Contents for Adcraft HCD-5

  • Page 1: Operating Instructions

    Chocofairy OPERATING INSTRUCTIONS Read these operating instructions carefully before using the machine MANUALE ISTRUZIONI Leggere attentamente queste istruzioni d’uso prima di utilizzare la macchina MANUAL DE EMPLEO Leer atentamente estas instrucciones de uso antes de utilizar la máquina BETRIEBSANLEITUNG Diese Bedienungsanleitung ist vor dem ersten Gebrauch der Maschine aufmerksam zu lesen MODE D’EMPLOI Lire attentivement ce mode d’emploi avant d’utiliser la machine...
  • Page 2 English version ............Pag.2 - EN Versione Italiana ............Pag.2 - IT Lingua originaria di riferimento per traduzione Versión española ............Pag.2 - ES Deutsche version ............Pag.2 - DE Version française............Pag.2 - FR...
  • Page 3 7.14. Resetting the temperature sensor ......19 7.15. Periodic maintenance..........19 8. SCRAPPING..........19 9. TROUBLESHOOTING.......20 10. BASIC WIRING DIAGRAM......21 04/2010...
  • Page 4 04/2010...
  • Page 5 L=28 cm (11.02 inch) L=28 cm (11.02 inch) P=41 cm (16.14 inch) P=41 cm (16.14 inch) A=46,50 cm (18.31 inch) A=58 cm (22.83 inch) 6,8 Kg 7,5 Kg (14.96 Ib) (16.5 Ib) Boiler tank drainage cap Mod. 10 Liters 04/2010...

  • Page 6: General Safety Rules

    3. SAFETY Do not clean the machine with gasoline and/or solvents of any kind. Repair work may be performed only by a Service Center authorized by the Manufacturer and/or specialized, trained personnel. Do not site the machine near heating equipment (stoves or radiators). ln case of fire, use carbon dioxide (CO2) extinguishers.
  • Page 7 375 mm 375 mm 510 mm 8,8 kg (14.76 inch) (14.76 inch) (20.08 inch) (19.36 Ib) 375 mm 375 mm 600 mm 9,5 kg (14.76 inch) (14.76 inch) (23.62 inch) (20.9 Ib) 04/2010...
  • Page 8 Chocofairy 04/2010...
  • Page 9 remove the lid and pour the beverage prepared accor dlng to the manu- facturer’s lnstructlons lnto t he bowl; 04/2010...

  • Page 10: Dispensing The Product

    the machlnes wlth LCD offer the opportunlty to make a visual check to see 6.2 Dispensing the product hen the product has reached the required temperature inside the bowl. Warning: the product dispensed from the machine has a very arnlng: during bowl and/or boller switch off the machine us- high temperature;...
  • Page 11 04/2010...
  • Page 12 04/2010...
  • Page 13 unhook the bowl hook-on handles, as illustrated in the figure, to free the bowl slide the mixing auger upwards with one hand, taking care to grip it by the rotation pin; from the machine body; release the bowl from the machine body, using two fingers to prise it away place the bowl on a flat surface and using both hands, romove the gasket by from the fixed steel part of the mixer auger (A) and the others to grip the sliding it upwards in the direstion shown by the arrow.

  • Page 14: Cleaning The Pan

    press the button (A) securing the tap to the machine and then remove the clean the channel connecting the bowl and the tap, using a cleaning brush, tap (B) with both hands, as illustrated in the figure; as illustrated in the figure; refit the tap;...
  • Page 15 04/2010...
  • Page 16 04/2010...
  • Page 17 insert the mixer into its seating following the steps descrlbed in paragr Fig. 37 shows a bpwl which is not correctly assembled;here the bowl does NOT perfectly adhere to the machine edge. 7.3 in reverse order. Fix the bowl to the machine body using the relevant hook-on handles, as illustrated in the figure;...

  • Page 18: Fitting The Tap

    7.8.3 Fitting the tap 7.10. Cleaning the drip tray T he drip tray shou ld be empt i ed and cleaned dally. To fl t the tap correctly b ack in place proceed as follows; hold down the button , making sure that the rod is completely extract ed; introduce the tap into the seat provided and push until the pushbutton re- Note: t h e tray nee ds t o b e e mpti e d out a nd cleaned every t ime turns to its initial position.
  • Page 19 04/2010...

  • Page 20: Periodic Maintenance

    7.14. Resetting the temperature sensor 7. 15.Periodic maintenance The machine must be periodically checked (at least once a year) by a specialised technician. This periodic check serves to ensure that all the components installed and the machine itself are maintained at a high level of safety. Any worn components must be replaced by an original spare part.
  • Page 21 - 20_EN - 04/2010...
  • Page 22 - 21_EN - 04/2010...
  • Page 23 - 22_EN- 04/2010...
