558J***D
SINGLE PACKAGE ROOFTOP, COOLING ONLY
R
WITH PURON
(R- - 410A) REFRIGERANT:
SIZES 08, 12, & 14 WITH NOVATIONt COIL
SIZES 08 - - 14 WITH ROUND TUBE/PLATE FIN COIL
NOTE: Read the entire instruction manual before starting
the installation.

TABLE OF CONTENTS

. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
. . . . . . . . . . . . . . . . . . . . . . . . . . .
Installation Instructions
. . . . . . . . . . . . . . . . . . . .
1
6
. . . . . . . . . . . . . . . . . .
6
. . . . . .
7
7
. . . . . . . . . . . . . . . . . . .
7
. . . . . . . . . . . . . . . .
9
. . . . . . . . . . . . . . . . . . . . .
9
. . . . . . . . . . . . . . .
10
.
12
. . . . . . . . . . .
13
. . . . . . . . . . . . . .
30
. . . . . . . .
40
. . . . . . . . . . . . . . . . . . .
40

SAFETY CONSIDERATIONS

Improper installation, adjustment, alteration, service,
maintenance, or use can cause explosion, fire, electrical
shock or other conditions which may cause personal
injury or property damage. Consult a qualified installer,
service agency, or your distributor or branch for
information or assistance. The qualified installer or
agency must use factory- - authorized kits or accessories
when modifying this product. Refer to the individual
instructions packaged with the kits or accessories when
installing.
Follow all safety codes. Wear safety glasses and work
gloves. Use quenching cloths for brazing operations and
have a fire extinguisher available. Read these instructions
thoroughly and follow all warnings or cautions attached to
the unit. Consult local building codes and appropriate
national electrical codes (in USA, ANSI/NFPA70,
National Electrical Code (NEC); in Canada, CSA C22.1)
for special requirements.
It is important to recognize safety information. This is the
safety- - alert symbol
. When you see this symbol on the
unit and in instructions or manuals, be alert to the
potential for personal injury.
Understand the signal words DANGER, WARNING,
CAUTION, and NOTE. These words are used with the
safety- - alert symbol. DANGER identifies the most serious
hazards which will result in severe personal injury or
death. WARNING signifies hazards which could result in
personal injury or death. CAUTION is used to identify
unsafe practices, which may result in minor personal
injury or product and property damage. NOTE is used to
highlight suggestions which will result in enhanced
installation, reliability, or operation.
