Havis KK-K9-F18-K Installation Instructions Manual

K9 kit for 2013-2017 ford interceptor utility

Advertisement

Quick Links

KK-K9-F18-K INSTALLATION INSTRUCTIONS
K9 Kit for 2013-2017 FORD INTERCEPTOR
** For K9 applications, it is recommended to order the Interceptor Utility with the
OEM optional Aux Rear Air conditioning. (Ford option code 17A)
TOOLS Needed:
Phillips Screw Driver
Standard Socket set
Metric Socket set
PARTS & HARDWARE:
QTY
DESCRIPTION
1
Front bulkhead with sliding door
Lower "B" pillar bracket
2
Upper "B" pillar bracket
2
1
Rear bulkhead
1
Rear bulkhead reinforcement bracket
1
Floor
1
Front floor bracket
1
Rear floor bracket (lower)
1
Rear floor bracket (upper)
1
Ceiling
2
Ceiling air duct vents
1
Passenger side upper filler (large)
1
Passenger side upper filler (small)
1
Driver side upper filler (large)
1
Driver side upper filler (small)
1
Passenger side lower filler
1
Driver side lower filler
1
Rubber Mat
1
Driver side door panel
1
Passenger side door panel
1
Driver side hinged window guard
1
Passenger side hinged window guard
1
Dome Light Kit
1/4" serrated flange nut
30
1/4 x 3/4" Hex head bolt
4
4
1/4 Lock washer
1/4 x 3/4" Carriage bolt – SS
30
1/4 x 3/4" Phillips pan head screw - SS
22
26
1/4 Flat washer - SS
10
#10 x 1/2 Phillips flat head sheet metal screw - SS
#10 x 1/2 Phillips pan head sheet metal screw – SS
17
20
#10 x 3/4 Phillips pan head sheet metal screw- SS
1
Silicone caulk (sealant)
2
Rubber Bumper
2
6MM nut
UTILITY
Trim panel removal tool
Wire Cutters /Crimpers
T-20 Torx bit
Caulk Gun
Foam cutting tool
PART #
KNM005039
KNM004369
KNM004370
KNM005037
KNM005115
KNM005036
KNM004393
KNM005042
KNM005076
KNM005038
KNM004992
KNM005078
KNM005079
KNM005084
KNM005085
KNM005086
KNM005087
KNM005116
DP-F18-1A
DP-F18-6A
WGI-F18-1-K9
WGI-F18-6-K9
KK-K9-DOME-LED
GSM30170
GSM33001
GSM31026
GSM32024
GSM34102
GSM31048
GSM34150
GSM34169
GSM34170
PRM97343
GSM21105
KK-K9-F18-K_INST_2-13.docx
GSM30201
