TROUBLESHOOTING

CHECK VOLTAGE AT TERMINALS
WITH VOLTMETER.
MOTOR
WON'T
IF Ø VOLTS:
START:
IF LOW VOLTS:
IF PROPER VOLTAGE:
CHECK VOLTAGE
MOTOR
AT TERMINAL
HUMS
WITH VOLTMETER.
IF PROPER VOLTAGE:
WON'T
IF VOLTAGE IS NOT
START:
WITHIN 10% OF
NAMEPLATE, CALL
ELECTRICIAN.
CHECK TO SEE THAT
MOTOR
MOUNTING IS SECURE:
IS
BENT SHAFT:
NOISY:
DISASSEMBLE PUMP AND
RUN MOTOR SEPARATE
TO DETERMINE WHETHER
MOTOR NOISE IS ACCEPTABLE:
CHECK FOR MOTOR
OVERLOAD BY CHECKING
AMP DRAW AT MOTOR
MOTOR
TERMINAL WITH AMMETER,
RUNS,
AMP DRAW SHOULD BE WITHIN 10%
THEN
OF NAMEPLATE.
STOPS:
IF MOTOR IS NOT
OVERLOADED:
IF MOTOR IS
OVERLOADED:
CHECK SHUT OFF
PUMP
VALVES:
RUNS,
CHECK TO SEE THAT PUMP IS
NO
BELOW WATER LEVEL:
FLOW:
CHECK SHUT OFF VALVES:
VISIBLE AIR BUBBLES
PUMP
IN RETURN LINE:
RUNS,
CHECK TO SEE
NOT
THAT VALVES ARE
ENOUGH
COMPLETELY OPEN:
FLOW: CHECK FILTER
PRESSURE GAUGE:
©2017 Waterway Plastics
REPLACE FUSE/ RESET BREAKER.
FUSE/ BREAKER
TRIPPED GFI RESET GFI.
CHECK SWITCH SETTINGS
DEFECTIVE EXTERNAL SWITCH
AND CONNECTIONS.
CALL ELECTRICIAN
INCORRECT OR LOOSE
INSURE WIRING CIRCUIT AGREES
CONNECTIONS
WITH DIAGRAM AND LEADS ARE TIGHT.
THERMAL PROTECTOR TRIPPED ALLOW MOTOR TO COOL AND RESTART.
WINDING SWITCH OR
SEE AN AUTHORIZED MOTOR
CAPACITOR FAILURE
SERVICE CENTER.
TAKE APART PUMP,
TIGHT PUMP
LOOK FOR SIGNS OF RUBBING.
SEIZED OR TIGHT MOTOR
TAKE APART PUMP, TURN MOTOR
BY HAND. SEE AN AUTHORIZED
WINDING SWITCH OR
MOTOR SERVICE CENTER.
CAPACITOR FAILURE
SEE AN AUTHORIZED
MOTOR SERVICE CENTER.
LOOSE MOUNTING TIGHTEN MOUNTING.
SEE AN AUTHORIZED MOTOR
SERVICE CENTER.
BEARING NOISE OR
SEE AN AUTHORIZED
ROTOR RUB
MOTOR SERVICE CENTER.
RESET BREAKER.
TRIPPED BREAKER
INADEQUATE VENTILATION
INCREASE VENTILATION.
CHECK VOLTAGE, IF INCORRECT
INCORRECT LINE VOLTAGE
CALL AN ELECTRICIAN.
INCORRECT WIRING
INSURE THAT WIRING CIRCUIT AND
WIRING DIAGRAM ARE THE SAME.
CHECK VOLTAGE, IF INCORRECT,
CALL AN ELECTRICIAN.
INCORRECT VOLTAGE
INCORRECT WIRING
INSURE THAT WIRING CIRCUIT AND
WIRING DIAGRAM ARE THE SAME.
PUMP BINDING
MOTOR BINDING
TAKE APART PUMP, LOOK
FOR SIGNS OF RUBBING.
IF MOTOR WILL NOT TURN BY ITSELF
SEE AN AUTHORIZED MOTOR SERVICE CENTER.
VALVES CLOSED OPEN VALVES.
REPLUMB PUMP BELOW WATER LEVEL.
PUMP ABOVE WATER LEVEL
AIR LOCK
REMOVE DRAIN PLUG UNTIL WATER FLOWS
FROM PUMP. REPLACE DRAIN
PLUG AND START PUMP.
LEAK IN SUCTION PLUMBING
REPLUMB PUMP BELOW WATER LEVEL.
PARTIALLY CLOSED VALVES OPEN VALVES.
DIRTY IMPELLER OR FILTER CLEAN FILTER OR IMPELLER.
ASSEMBLY DRAWING
Power Defender
Executive Pump
48/56-Frame
EXPLODED VIEW
Impeller
Assembly
56-Frame
Faceplate
O-Ring
N o: 111
O-Ring
⁄ " Plug
N o: 261
Screw N 8-32 x ⁄ " PPH
o:
56-Frame Executive
Volute
Slinger
PS1100
Seal
PS1100
Ring
Motor
810-0061.0117
