MasterCool 71400 User Manual And Parts List

Gm fuel line tube flaring tool set

Advertisement

Quick Links

"World Class Quality"
Part# 71400
GM Fuel Line Tube
Flaring Tool Set
User Guide and Parts List
Pre-operation set-up
•O pen the relief valve to fully recess
the piston, then close tightly.
•R otate the yoke fully counter clock-wise
to bottom out the adapter seat.
• READY TO GO!
Warning!
Wear safety goggles when using this tool.
NEWS...
R
OTHER AVAILABLE ADAPTERS & DIE SETS
Part#
71205
71215
71206
71216
71204
71214
Part#
71097-01
71097-03
71097-13
71097-04
71097-14
71097-05
71097-15
71097-06
71097-16
71097-08
71097-18
www.mastercool.com
Push Connect Adapters and Die Sets:
Description
5/16" Push Connect adapter
5/16" Push Connect die set
3/8"
Push Connect adapter
3/8"
Push Connect die set
1/4"
Push Connect adapter
1/4"
Push Connect die set
45º Double Flaring Adapters and Die Sets:
Description
45º
Flaring Cone
3/16" Double Flare adapter
3/16" Double Flare die set
1/4"
Double Flare adapter
1/4"
Double Flare die set
5/16" Double Flare adapter
5/16" Double Flare die set
3/8"
Double Flare adapter
3/8"
Double Flare die set
1/2"
Double Flare adapter
1/2"
Double Flare die set
"World Class Quality"
R
71400-INST
