- Page 1 DOOR CONTROLLER INSTALLATION GUIDE ADC-ACC1-17...
- Page 2 The ADC-ACC1-17 requires Power over Ethernet (PoE) or 12V DC for power. The ADC-ACC1-17 may be mounted in a 3-gang switch box; on the provided mounting plate, or in an enclosure. The supplied mounting plate has mounting holes that match the ADC-ACX1 mounting footprint.
- Page 3 ADC-ACC1-17 Hardware PoE/12V DC POWER SELECTOR JUMPER (J3) 5.40” [137.16 mm] .15” [3.81 mm] .20” [5.08 mm] 2.55” [64.77 mm] 2.55” [64.77 mm] TAMPER ETHERNET SWITCH CONNECTOR CONNECTION (J6) (J7) Ø .125” [Ø3.175 mm] RESET SWITCH DIP SWITCHES STATUS LEDs CHASSIS GND .20”...
- Page 4 J U M P E R S Jumpers Set At Description ADC-ACC1-17 powered from the Ethernet connection ADC-ACC1-17 powered from a local 12V DC power source connected to TB4-3 (VIN), TB4-4 (GND) Cabinet Tamper Switch Input: short = tamper secure ADC-ACC1-17 Installation Guide...
- Page 5 D I P S W I T C H E S The four DIP switches on configure the operating mode of the ADC-ACC1-17 processor. DIP switches are read on power-up except where noted. Pressing the reset button (S2) causes the ADC-ACC1-17 to reboot.
-
Page 6: Status Leds
If clearing the memory does not correct the initialization problem, contact technical support. R U N N I N G Description Connecting to Alarm.com = Connected to Alarm.com = Alarm.com Communication Activity Readers (combined): Clock/Data or D1/D0 Mode = Flashes when Data is Received, Either Input. - Page 7 Full memory erase takes up to 60 seconds. When complete, only LEDs 1 & 4 will flash for 8 seconds. The ADC-ACC1-17 board will reboot 8 seconds after LEDs 1 & 4 stop flashing (no LEDs are on during this time).
-
Page 8: Input Power
Input Power The ADC-ACC1-17 may be powered by one of two ways. Use jumper J3 to select the input power source: • Power over Ethernet (PoE) connection, fully compliant to IEEE 802.3af, or • Local 12V DC power supply wired to TB4-3 (VIN), TB4-4 (GND) Reader &... - Page 9 R E A D E R W I R I N G D I AG R A M S Reader Port 1: Typical Wiegand Reader OSDP PROTOCOL DEVICE ADDRESS 0 FIRST READER PORT CLK/D1 9600 BAUD (DEFAULT) DAT/D0 VO (12V DC) CLK/D1 DAT/D0 Reader Port 2: Typical Wiegand Reader...
- Page 10 SHIELD WIRES. 2,000 FT. (609 M) MAXIMUM TOTAL LENGTH. ADC-ACX1 ADC-ACX2 ADC-ACC1-17 For ease of install, daisy chain expansion modules together. Wire each expansion module to the next module instead of wiring directly back to the controller. ADC-ACC1-17 Installation Guide...
-
Page 11: Relay Wiring
MOV (metal oxide varistor) be used to protect the relay. From the Auxiliary output, the ADC-ACC1-17 can provide 12V DC power for external devices, provided 650 mA is not exceeded. See the specifications section for details. If a local power supply is used, it must be UL Listed Class 2 rated. -
Page 12: Input Wiring
The input circuit wiring configurations shown are supported but may not be typical: Standard Supervised Circuit, 1K,1% Normally Open Contact 1K,1% Standard Supervised Circuit, 1K,1% Normally Closed Contact 1K,1% Unsupervised Circuit, Normally Closed Contact Unsupervised Circuit, Normally Open Contact ADC-ACC1-17 Installation Guide... -
Page 13: Specifications
Specifications The interface is for use in low voltage, Class 2 circuits only. The installation of this device must comply with all local fire and electrical codes. I N P U T P O W E R PoE or 12V DC, 900 mA max. O U T P U T P O W E R 650 mA @ 12V DC I N P U T S... - Page 14 This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. ADC-ACC1-17 Installation Guide...
