Page 1
MIRA FLIGHT WALL Installation and User Guide These instructions are to be left with the user 1103014-W2-E...
Page 2
INTRODUCTION Thank you for purchasing a quality Mira product. To enjoy the full potential of your new product, please take time to read this guide thoroughly, having done so, keep it handy for future reference. Mira Modular Wall Panels Mira Modular wall panels provide a fast, easy to install, low maintenance, durable and leak free wall panel system.
IMPORTANT SAFETY INFORMATION Warning! Products manufactured by Mira are safe and without risk provided they are installed, used and maintained in good working order in accordance with our instructions and recommendations. When handling or cutting the wall panels, protective equipment should be worn, P2 Rated Dust Mask, Safety Spectacles Approved to EN 166 and Ear Protection required when noise levels exceeds 85dBA.
INSTALLATION Read the section: Installation Requirements before proceeding with the installation. Installing a Single Corner Extrusion (Shower Tray Installation) Silicone Sealant No.6 x 25 Countersunk Head Self Tapping Screw NO UPSTAND UPSTAND Silicone Silicone Sealant Sealant 1103014-W2-E...
Page 5
Apply the silicone sealant around the edge of the wall panel. Adhesive Note! The circular pattern of adhesive creates a suction effect when the flight wall is pushed flat onto the wall. Silicone Sealant 3 mm NO UPSTAND 3 mm...
Page 6
Installing a Two Corner Extrusion (Shower Tray Installation) Measure the size of the alcove. Cut the flight wall panels to size, cut any holes required for pipework and seal the edges around the holes with silicone sealant. Warning! When handling...
Page 7
Apply the silicone sealant to the corner extrusion and around the edge of the wall panel. Corner Extrusion Silicone Sealant Adhesive Silicone Sealant Silicone Sealant Corner Extrusion Corner Extrusion Drill 3 holes in each of the corner extrusions for the No.6 x 25 countersunk head self tapping screws.
Page 8
Silicone Sealant NO UPSTAND Silicone Sealant UPSTAND 3 mm NO UPSTAND 3 mm 3 mm Spacers UPSTAND 1103014-W2-E...
Page 9
Silicone Sealant Adhesive Silicone Sealant 3 mm NO UPSTAND 3 mm UPSTAND Remove the 3 mm spacers once adhesive has cured and seal around the edge with silicone sealant. 1103014-W2-E...
Page 10
Installing The Bath Panel Cut the bath panels and joining strip to size. Warning! When handling and cutting the wall panels Safety Equipment should be worn. Equipment Required P2 Rated Dust Mask. Safety Spectacles Approved to EN 166. Ear Protection required when noise levels exceeds 85dBA.
Install the wall panels as Silicone previous installations. Sealant Apply silicone sealant to the joining strip and install the bath panel. Installing Sink Splashback Panel Prepare the sink splashback as panels and install as previous installations. Silicone Sealant MAINTENANCE Cleaning Many household cleaners contain abrasives and chemical substances, and should not be used for cleaning the wall panels.
Page 12
The product must be installed and maintained in Spares and Accessories - We hold the largest accordance with the instructions given in this user stocks of genuine Mira spares and accessories. guide. Contact us for a price or visit our website to...
