RNA SLK 05 Operating Instructions Manual

Linear feeder
Hide thumbs Also See for SLK 05:

Advertisement

Rhein - Nadel Automation GmbH
VT-BA-SLK-GB
Operating instructions
Linear feeder
SLK 05
SLK 1
SLK - N 6
SLK - N 6G
SLK 12
1
BA
Rhein-Nadel Automation GmbH
Stand 14.04.2014

Advertisement

loading
Need help?

Need help?

Do you have a question about the SLK 05 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for RNA SLK 05

  • Page 1 Operating instructions Linear feeder SLK 05 SLK 1 SLK - N 6 SLK - N 6G SLK 12 Rhein-Nadel Automation GmbH Rhein - Nadel Automation GmbH Stand 14.04.2014 VT-BA-SLK-GB...
  • Page 2: Table Of Contents

    Contents Technical data Page 3 Safety instructions Page 4 Construction and function of the linear feeder Page 5 Transport and mounting Page 6 Starting/Adjustment Page 6 Specifications for the design of the track Page 9 Maintenance Page 9 Stockkeeping of spare parts and after-sales service Page 9 What is to do, if..? Page 10...
  • Page 3: Technical Data

    Notice All linear feeders listed in the table may only be operated in connection with a RNA control unit at a mains voltage of 230V/50Hz.. Special voltages and frequencies see separate data sheet. Technical data Linear feeder type SLK 05...
  • Page 4: Safety Instructions

    Pin assignment The bridge has to be installed in connection 3+4 Safety instructions The conception and production of our linear feeders has been carried out very carefully, in order to guarantee trouble-free and save operation. You too can make an important contribution to job safety. Therefore, please read this short operating instructions completely, before starting the machine.
  • Page 5 Notice The linear feeder may only be operated in perfect condition! The linear feeder may not be operated in the explosive or wet area. The linear feeder may only be operated in the configuration drive unit, control unit and oscillating unit, as specified by the manufacturer.
  • Page 6: Construction And Function Of The Linear Feeder

    Construction and function of the linear feeder Linear feeders are used for the actuation of conveying equipments. The actuation takes place by an electromagnet. The following schematic diagram shows the function of a linear feeder: A Conveying track and oscillating weight B Material to be conveyed C Spring assembly D Drive magnet...
  • Page 7 3). The following table will give you a summary of the bore data of the various types: Linear feeder type Length in mm Width in mm Shock absorber thread SLK 05 SLK-N6 SLK-N 6 G SLK 12 Table bore data Make sure that the linear feeder cannot come into contact with other devices during operation.
  • Page 8 SLK12 2x50 The size of the weight must be determined in a test. The linear feeders type SLK 05 and SLK-N6G are already equipped with a counterweight in the factory. During the adjustment of the conveying track to a steady running speed the following must be carried out: ...
  • Page 9 Adjustment of the natural frequency In case the linear feeders are delivered without track, they have been adjusted in the factory to average weights of the oscillating elements. In order to guarantee an optimal conveying behaviour, the linear feeder must be adjusted to the definite operating conditions. The adjustment is made by adding or removing leaf springs and washers.
  • Page 10: Specifications For The Design Of The Track

    The conveying speed decreases? Mount additional springs (with distance plates). Start with one additional spring (with washer) at one spring assembly. Start with one additional spring at one spring assembly. In case the conveying speed still decreases, although an additional fastening screw is loosened, install one additional spring with washer at the second spring assembly (one after the other).
  • Page 11: Maintenance

    (see type plate and "technical data" (chap. 1) Attention: in case a linear feeders SLK 05 and SLK1 are operated without a bridge in a 7-pole plug, the control unit and the magnet is in danger!
  • Page 12 Rhein-Nadel Automation GmbH Reichsweg 19/23  D - 52068 Aachen Tel (+49) 0241/5109-159  Fax +(49) 0241/5109-219 Internet www.rna.de  Email vertrieb@rna.de Rhein-Nadel Automation GmbH Zweigbetrieb Lüdenscheid Nottebohmstraße 57  D - 58511 Lüdenscheid Tel (+49) 02351/41744  Fax (+49) 02351/45582 Email werk.luedenscheid@rna.de...

This manual is also suitable for:

Slk-n 6Slk 1Slk-n 6gSlk 12
