Kohler Odeon K-8752IN Installation Instructions Manual

Please read these instructions carefully to familiarize yourself with the required tools, materials, and installation sequences.
Follow the sections that pertain to your particular installation. This will help you avoid costly mistakes. In addition to proper
installation, read all operating and safety instructions.
All information in these instructions is based upon the latest product information available at the time of publication. Kohler India
reserves the right to make changes in product characteristics, packaging, or availability at any time without notice.
These instructions contain important care, cleaning, and warranty information.
Observe all local plumbing and building codes. Shut off the water supply. Seat post holes are on 155mm centers. Passageways is
60mm. Water depth from rim is 210mm.
Ensure that the new drain and shut-off valve have the correct roughing-in dimensions. See Fig.#1.
Be very careful while working with vitreous china products. Vitreous china can break or chip if the bolts or nuts are overtightened, or
if carelessly handed. Carefully inspect the new bowl for any sign of damage.
Fixture dimensions are nominal and conform to tolerances established by ASME Standards (A112. 19.2M).
1037407-IN01-B
K-8752IN
K-8750IN
K-8741T
TM
K-8752IN
