Total Control MRX-8 Owner's Manual

System controller
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
Owner's Manual
MRX-8
System Controller

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the MRX-8 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Total Control MRX-8

Summary of Contents for Total Control MRX-8

  • Page 1 Owner’s Manual MRX-8 System Controller...
  • Page 2 Total Control MRX-8 Owner’s Manual ©2015 Universal Remote Control, Inc. The information in this owner’s manual is copyright protected. No part of this manual may be copied or reproduced in any form without prior written consent from Universal Remote Control, Inc.

  • Page 3: Table Of Contents

    ABLE ONTENTS Introduction Features and Benefits Parts Guide Front Panel Descriptions Rear Panel Descriptions Installing the MRX-8 Specifications Limited Warranty Statement End User Agreement Federal Communication Commission Interference Statement Declaration of Conformity...

  • Page 4: Introduction

    The MRX-8 makes it easy to turn on multiple devices at once such as a TV and Blu-Ray, even lights with one button press. Enjoy...

  • Page 5: Front Panel Descriptions

    The front panel consists of two indicator lights which illuminate when in use. Power LED Ethernet LED Power LED: Indicates that the MRX-8 is powered on when lit. Ethernet LED: Indicates the network connectivity status: ● On = Connected ● Off = Not connected ●...

  • Page 6: Rear Panel Descriptions

    MRX-8 S OTAL ONTROL YSTEM ONTROLLER Rear Panel Descriptions The rear panel ports are: IR Outputs: #1-6 Reset RS-232 Ports RFTX-1 DC 12V Relay: NO, Sensors Power NC, COM DC 12V Power: Attach the included 12V power supply here. LAN Connection: RJ45 standard Ethernet connection to the local network.

  • Page 7: Installing The Mrx-8

    1. Connect an Ethernet cable (RJ45) to the rear of the MRX-8 and onto the network. 2. Plug flashers into any of the six IR outputs on the rear of the MRX-8. (Make sure the 3.5mm pink connector cable is reserved for port #6.)
  • Page 8 The MRX-8 can operate equipment via RS-232 communication. This allows discrete serial commands to be triggered from a Total Control remote to a MRX-8. The signal is then sent to the device over proprietary URC RS-232 cables. These use either male or female DB-9 connections with standard pin-outs.
  • Page 9 For example, using a video sensor cable with the MRX-8 can detect a video signal from a composite or component video output.
  • Page 10 ONTROLLER Wiring to the Relay on the MRX-8 The MRX-8 has a Relay with three contacts, NO, NC, and COM. These can be used as dry contacts or to an electrical switch or motor for use with screens, blinds, curtains, etc. The Relay can be programmed as either a latching or a momentary contact.

  • Page 11: Specifications

    MRX-8 S OTAL ONTROL YSTEM ONTROLLER Specifications Network: One 10/100 Ethernet port Relay: One relay configurable to be NO, NC or Momentary Sensor: Two Sensors support Video (SEN-VID), Voltage (SEN-VOLT), Audio (SEN-AUD), Current (SEN-CMF), Light (SEN-LITE), and Contact Closure (SEN-CCLS) sensors.

  • Page 12: Limited Warranty Statement

    (36) months from the date of shipment of the URC equipment by URC to an authorized URC dealer or distributor, except that with respect to Total Control® whole-house products, the warranty extends for two (2) years from the date of purchase by...
  • Page 13 MRX-8 S OTAL ONTROL YSTEM ONTROLLER EXCEPT AS EXPRESSLY PROVIDED FOR HEREIN, TECHNICAL SERVICES ARE SUPPLIED "AS IS", WITHOUT ANY WARRANTY, EXPRESS, STATUTORY OR IMPLIED, OF ANY KIND. TO THE MAXIMUM EXTENT PERMITTED BY APPLICABLE LAW, URC EXPRESSLY DISCLAIMS ALL WARRANTIES RELATING TO...

  • Page 14: End User Agreement

    With the exception of URC's IR-only, broad-based consumer remotes, none of URC's PC programmable remotes or any of our Total Control® whole-house equipment are authorized for online internet sales. Buying URC's PC programmable remotes or any of our Total Control® whole-house equipment online means buying equipment that does not have URC's limited warranty.

  • Page 15: Federal Communication Commission Interference Statement

    MRX-8 S OTAL ONTROL YSTEM ONTROLLER Federal Communication Commission Interference Statement This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation.

  • Page 16: Declaration Of Conformity

    MRX-8 S OTAL ONTROL YSTEM ONTROLLER Declaration of Conformity Company Name OH SUNG ELECTRONICS CO., LTD. Company Address #181 GONG DAN-DONG, GUMI, GYEONG BUK, REPUBLIC OF KOREA Contact Information Phone: +82-54-468-7281, Fax: +82-54-461-8368 Brand Name UNIVERSAL remote control Product Name...
  • Page 17 Page 14...
  • Page 18 Page 15...
  • Page 19 500 Mamaroneck Avenue, Harrison, NY 10528 Phone: (914) 835-4484 Fax: (914) 835-4532 www.universalremote.com OCE-0073k Rev 02_RH...
