- Page 1 Tecal 650H Calibrator Operator's Manual Issue 10 Date of issue: 3rd May 2005 Techne is a trademark © Techne, 2003...
-
Page 3: Table Of Contents
T E C A L 6 5 0 H O P E R A T O R ’ S M A N U A L CONTENTS Hi-Spec Dri-Block Calibrator Operator’s Manual ® page SAFETY AND INSTALLATION English Français Deutsch Español THE CALIBRATOR Applications Warning... - Page 4 T E C A L 6 5 0 H O P E R A T O R ’ S M A N U A L PAGE 2...
- Page 5 T E C A L 6 5 0 H O P E R A T O R ’ S M A N U A L PAGE 3...
-
Page 6: English
Servicing under this Techne have taken great care in the design of these units guarantee should be obtained from the supplier. to protect operators from hazards, but users should pay... -
Page 7: Français
6. Les symboles situés sur ou à côté de l’interrupteur de Techne a apporté un soin tout particulier à la conception l’appareil ont la signification suivante : de ces appareils de façon à assurer une protection : arrêt... -
Page 8: Deutsch
Bringen sie KEINE Flüssigkeiten direkt in Ihr Gerät. enthaltenen Beschreibungen und Spezifikationen, behält · Benutzen Sie immer den normalen Menschenverstand sich Techne hiermit das Recht vor, Änderungen an den Geräten bzw. an einzelnen Geräteteilen durchzuführen. Sicherheit des Anwenders Diese Gebrauchsanleitung wurde ausschließlich dazu Alle Benutzer von Techne Geräten müssen Zugang zu der... -
Page 9: Español
: Indicador de sobretemperatura Techne ha puesto gran cuidado en el diseño de estos 6. Los símbolos que se encuentran en o cerca del aparatos para proteger al usuario de cualquier peligro;... -
Page 10: The Calibrator
A NAMAS certificate can be provided, contact your dealer for details. Temperature cycling You can connect a PC to the Tecal unit using Techne's Data Logging software, CALSOFT, to gather data. You may also print out profiles using the printer connected to the PC. -
Page 11: Warning
HIGH TEMPERATURES ARE DANGEROUS: they can cause serious burns to operators and ignite combustible material. Techne have taken great care in the design of these units to protect operators from hazards, but operators should pay attention to the following points: •... -
Page 12: Specification
T E C A L 6 5 0 H O P E R A T O R ’ S M A N U A L Specification The figures stated in the specification are as measured 0-50 mm from the base of the well of the insert, using an SPRT, at the time of calibration. Tecal650 Measuring zone 0 to 50 mm... -
Page 13: The Front Panel
T E C A L 6 5 0 H O P E R A T O R ’ S M A N U A L THE FRONT PANEL The control panel of the Tecal units consists of a membrane keypad, an alphanumeric LCD panel, an LED display and three LEDs. -
Page 14: Front Panel Controls
T E C A L 6 5 0 H O P E R A T O R ’ S M A N U A L The Front Panel Controls The ESC key " ENTER ABCD EFGH IJKL ON/OFF PAUSE MNOP QRSTU VWXYZ (0-9) - Page 15 T E C A L 6 5 0 H O P E R A T O R ’ S M A N U A L The ON/OFF key " ENTER ABCD EFGH IJKL ON/OFF PAUSE MNOP QRSTU VWXYZ (0-9) The ON/OFF key allows the operator to start or stop the unit in Manual Mode or stop a program in Program Mode.
- Page 16 T E C A L 6 5 0 H O P E R A T O R ’ S M A N U A L Power Indicator The top indicator shows that there is power to the unit Power to the Block Indicator The next indicator shows when there is power to the block.
-
Page 17: When You Switch On
T E C A L 6 5 0 H O P E R A T O R ’ S M A N U A L When you Switch On When you first switch on, the display will show a choice of options. MAIN MENU manual mode program mode... -
Page 18: Manual Mode
T E C A L 6 5 0 H O P E R A T O R ’ S M A N U A L MANUAL MODE To go into the Manual Mode, use the # # # # # key to put the cursor on manual mode then press the ENTER key. -
Page 19: Program Mode
T E C A L 6 5 0 H O P E R A T O R ’ S M A N U A L PROGRAM MODE To go into the Program Mode, use the # # # # # key to put the cursor on program mode then press the ENTER key. -
Page 20: New Program
T E C A L 6 5 0 H O P E R A T O R ’ S M A N U A L New Program If you have chosen New Program the following screen will appear NEW PROGRAM name: _ _ _ _ _ _ _ _ Use the keys with letters beneath them to enter the name of the program you... -
Page 21: Program Running Display
T E C A L 6 5 0 H O P E R A T O R ’ S M A N U A L Program Running Display The Display will automatically go into the the program running display as described earlier. -
Page 22: Switch Test
T E C A L 6 5 0 H O P E R A T O R ’ S M A N U A L Switch Test The switch test indicates the switch point temperature of a thermostat by detecting the making or breaking of the circuit made by the contacts of the thermostat. -
Page 23: Program Delete
T E C A L 6 5 0 H O P E R A T O R ’ S M A N U A L Program Delete PROGRAM MODE run program new program delete program To go into the Program Delete Mode from the Program Mode screen, use the # # # # # key to put the cursor on delete program then press the ENTER key. -
Page 24: Cooling Probe
T E C A L 6 5 0 H O P E R A T O R ’ S M A N U A L Cooling Probe Operating temperatures below ambient can be achieved by using the cooling probe with a chilled water circulator. The cooling probe is supplied as an accessory and can be used in an insert with a 3/8"... -
Page 25: Rs232 Serial Interface
T E C A L 6 5 0 H O P E R A T O R ’ S M A N U A L RS232 SERIAL INTERFACE The calibrator may send data logging information to an IBM PC or compatible computer by connecting the unit and the PC via an RS232 cable, and installing the "Calsoft"... -
Page 26: Technical Information
The insert must be removed from the unit and packed separately within the case. Techne accept no responsibility for damage to units which are not properly packed for shipping: if in doubt, contact your supplier. -
Page 27: Replacement Parts
T E C A L 6 5 0 H O P E R A T O R ’ S M A N U A L Fuses should only be changed by suitably qualified personnel. If the fuses blow persistently, a serious fault is indicated and you should return the calibrator to your supplier for repair. -
Page 28: Inserts
T E C A L 6 5 0 H O P E R A T O R ’ S M A N U A L Inserts Inserts are made from aluminium or aluminium-bronze and must be ordered separately from the calibrator. Each insert is stamped for identification. A blank insert is available which may be drilled to suit your application. -
Page 29: Glossary
T E C A L 6 5 0 H O P E R A T O R ’ S M A N U A L GLOSSARY Block temp. The current temperature of the heat transfer block. Cursor The flashing bar on the LCD screen which indicates where the next character is entered. - Page 30 T E C A L 6 5 0 H O P E R A T O R ’ S M A N U A L PAGE 28...
