ENGLISH
ATTENTION
This manual explains how to safely operate the Camera Goggle.
Please read these instructions carefully before using the camera.
Keep this manual in a safe place for later reference
Disclaimer
While every effort has been made to ensure that the information contained in the
guide is accurate and complete, no liability can be accepted for any errors or
omissions. Liquid Image Co reserves the right to change the specifications of the
hardware and software described herein at any time without prior notice.
Liquid Image Co declines all responsibility for damages due to improper use of
this product, failure to adhere to the instructions given in this manual, or
modifications to the CAMERA GOGGLE.
Cautions concerning data storage: Stored data may be lost or corrupted. It is
recommended that any important data be copied onto a separate media (such as
a hard disk, DVD-R or CD-R disk). Liquid Image Co makes no warranties and shall
not be held responsible for damages resulting from corrupted or lost data due to a
malfunction of the camera, the software, the memory cards, personal computer,
peripheral devices, or for any losses that result from images that could not be
recorded, are erased, destroyed, or damaged in any way due to a problem or a
mistake while utilizing the camera or any of its accessories.
The Camera Goggle is a sophisticated electronic device and should
be supervised by an adult at all times. This product should not be
used by children under 13 years. This product is not a toy. The inserting
of memory cards, USB cable, and battery must be performed by an
adult 18 years or older who has read and understands this manual. An
adult must always check all water resistant compartments prior to each use.
Products mentioned above or throughout the manual may be trademarks or registered trademarks of their respective
companies.
1.0 GET TO KNOW YOUR CAMERA GOGGLE
1.1 Features
Video Clips, Still Images, Micro SD/SDHC Card support
Driver free for Windows XP/Vista/7 and Mac 9.x or above
1.2 Specifications -
Subject to change without notice
Sensor
1/2.5" 5.0MP CMOS Sensor
Image Resolution
12.0 Megapixels (4000x3000)
*
Lens
F/3.2 f=2.75mm (135 Degree FOV)
Focus range
.4m to infinity
Internal Memory
256MB NAND Flash Memory for CPU only
External Memory Card
Micro SD/SDHC Card supports up to 32GB
Must be Class 6 and above
Video Mode
30FPS@HD 1080P
**
60FPS@HD 720P (1280x720) with Audio
File Format
Picture: JPEG, Video: H.264 MOV with Audio
Status Display
LCD Display
PC Interface
USB
TV Output
PAL and NTSC
Power
3.7V Lithium Rechargeable Battery 1150mAh
Auto Of
f System time
180 seconds
WiFi - Wireless
Apps for Android and iOS systems
*
Quantity of pixels is only an approximate number
1.2 System Requirements
***
Operating System
Windows® XP (SP2 or higher) ,Vista™,
Windows® 7 or Mac 9.x
CPU
Intel® Core™ 2 Duo CPU E6300 processor
(or above), AMD Athlon 64 X2 3800+ (or above)
RAM
1GB RAM (2GB recommended for editing HD videos)
Memory
300 MB available hard disk space
Graphics Card
256 MB Graphics Card or above is recommendeded
***
No Software required to download files
(1920X1080) with Audio
**
Approximate frames per second
