XT-301 Operating Instructions
The XT-301 features a patented method of creating ozone by corona discharge, and a
patented air pump.
It can be used for disinfecting water in a 16-oz bottle up to a 5-gallon water tank.
It can also purify food and eliminate surface bacteria and pesticides from the food.
* PLEASE NOTE: Before you begin operating the XT-301 allow for a warm-up period.
You do this by turning on the machine without the silicone hose attached, and let the unit
blow ozone into the air for 10 minutes. Also, always be sure your check valve connector
piece is pointed in the direction of ozone flowing into your container. The check valve is
the plastic connector piece in the silicone hose. There is an engraved arrow on this valve
and it should be pointing in the direction of the ozone flow.
Placement of the Unit
The ozone generator can be used lying flat on a countertop, or it can be mounted on the
wall by the hook cradles found on the bottom of the unit.
Mounted on the wall the XT-301 has a very thin profile, and takes up very little room.
How to Purify Water
The ozone generator should be placed where the best possible ozone distribution can be
obtained. Purifying water with the XT-301 could not be simpler. Connect the air hose to
the output of the stainless steel ozone nipple just under the timer knob on the top of the
unit. Then connect the bubbling rock to the other end of the hose and place the air rock at
the bottom of a container of water. As the ozone bubbles through the water it will purify
the water. The automatic timer can be set for the 15, 30, 45 minutes or a continuous
setting. When the ozone time period is over the hose and the air rock can be removed, and
the unit turned off.
Here is a timer guide for different sized containers:
1 Quart of water can be purified in about 5 minutes
1 Gallon of water can be purified in about 15 minutes.
5 Gallons of water can be purified in 45 minute to an hour.
When a container needs less than the programmed time, simply power off the unit before
the programmed time has expired.
Automatic Hourly Burst Function:
Advertisement
Table of Contents
Related Manuals for Air-Zone Inc. XT-301
Summary of Contents for Air-Zone Inc. XT-301
- Page 1 The ozone generator can be used lying flat on a countertop, or it can be mounted on the wall by the hook cradles found on the bottom of the unit. Mounted on the wall the XT-301 has a very thin profile, and takes up very little room. How to Purify Water The ozone generator should be placed where the best possible ozone distribution can be obtained.
- Page 2 How to Make an Olive Oil Salve The Air-Zone XT-301 can also be used to make ozonated olive oil. When ozone is bubbled through pure olive oil for a long period of time it will thicken into a paste like salve.
-
Page 3: Warranty Information
Every Air-Zone ozone generator is checked to be in perfect working condition before it is shipped. The XT-301 ozone generator is under warranty from manufacturing defects for a period of five years. Air-Zone will repair or replace the unit at our cost if a defect is determined to be from the manufacturing process. - Page 4 XT-301 Specifications Electrical: 110 volts 60 Hz. 15 Watts Dimensions: 14.1"X 8.0"X 4.3" Weight: 4.85 lbs. Ozone Concentration: 100 PPM at air flow rate of 2.5 L/min, Ozone output: 210 mg/hr. Five-year manufacturer’s defects warranty NEVER OPEN THE UNIT. There are no user serviceable parts inside. Dangerous high voltages exist.
