English-4
32
Loosen the anti-theft bracket screw three
turns.
•
Take care not to loosen the anti-theft bracket screw too
much (to the point that the bracket detaches).
Anti-theft bracket
Screw
42
After loosening the screw, rotate the anti-theft
bracket out of the way.
52
Load an SD card into the SD card slot that
appears after the anti-theft bracket is rotated.
62
Return the bracket to its original position and
then tighten the screw.
72
Close the cover.
Normal Operation
n
To turn on the Signage Unit
Perform either of the operations below.
•
If the Signage Unit is already connected to a power supply,
press the power button on the front of the Signage Unit.
•
If the Signage Unit is not connected to a power supply, plug its
AC adapter into a power outlet.
Turning on the Signage Unit will display a startup screen on the
touch panel. The startup screen indicates that the Signage Unit is
performing internal processes required to start content play.
The "Play Mode" screen will appear on the touch panel and
content play will start automatically after the internal processes
are complete.
To turn off the Signage Unit
n
12
Hold down the power button until a menu
appears on the touch panel.
22
On the menu, tap [Power off].
32
On the confirmation dialog box that appears,
tap [OK].
D
MG-30MBPACK_e.indd
4
n
Removing and Attaching the Ad Panel
You can remove the transparent ad panel on the front of the
Signage Unit to insert a printed ad sheet* underneath it.
*
You can use the sample ad sheet that comes with the Signage
Unit as a trial. For more information, visit the CASIO website.
Ad panel
Cleaning
The intake and exhaust vents of the Signage Unit are prone to
dust buildup. Use a vacuum cleaner to periodically clean the vents
and keep them clear of dust. Continued use of the Signage Unit
after dust has accumulated around the intake and/or exhaust
vents can cause excessive heat build up inside the case and lead
to malfunction.
n
To clean the Signage Unit
12
Turn off the Signage Unit and unplug its AC
adapter from the power outlet.
22
Remove the screws that secure the screen, ad
panel, and top plate, and then remove each of
the items from the Signage Unit.
32
Use a vacuum cleaner to clean dirt and dust
from inside the Signage Unit case.
42
Use a vacuum cleaner to clean dirt and dust
from intake and exhaust vents.
52
Replace the top plate, ad panel, and screen to
their original positions, and then secure them
with their screws.
Main Specifications
Environment
Operating Temperature: 5 to 35°C (41 to 95°F)
Operating Humidity: 20 to 80% (non-condensation)
Operating Altitude: 0 to 2,000 meters (0 to 6,500 feet) above sea level
Power
Requirements AC 100V-230V 50/60Hz (AC adapter : DC 19V 4.74A)
Approximate
286 (W) × 350 (D) × 110 (H) mm (11.3" × 13.8" × 4.3")
Dimensions
except screen and projection
Weight
8.5 kg (18.7 lbs) or less
GUIDELINES LAID DOWN BY FCC RULES FOR USE OF THIS UNIT IN THE U.S.A. (not applicable to other areas).
MG-30MBPACK: NOTICE
This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to Part 15 of the FCC Rules.
These limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a commercial
environment. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with
the instruction manual, may cause harmful interference to radio communications. Operation of this equipment in a residential area is
likely to cause harmful interference in which case the user will be required to correct the interference at his own expense.
FCC CAUTION
Changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the
equipment.
Proper connectors must be used for connection to host computer and/or peripherals in order to meet FCC emission limits.
Model Number: MG-30MBPACK
Trade Name: CASIO COMPUTER CO., LTD.
Responsible party: CASIO AMERICA, INC.
Address: 570 MT. PLEASANT AVENUE, DOVER, NEW JERSEY 07801
Telephone number: 973-361-5400
This device complies with Part 15 of the FCC Rules, Operation is subject to the following two conditions:
(1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that
may cause undesired operation.
FOR CALIFORNIA USA ONLY
Perchlorate Material - special handling may apply.
See www.dtsc.ca.gov/hazardouswaste/perchlorate.
The projector built into the Signage Unit is Risk Group 2 based on IEC62471.
MG-30MBPACK:
This Class A digital apparatus complies with Canadian ICES-003.
Cet appareil numérique de la classe A est conforme à la norme NMB-003 du Canada.
GPL and LGPL
(1) This product uses software (This Software) that comes under the GNU General Public License (GPL) and GNU Lesser General
Public License (LGPL). In accordance with the GPL and LGPL, the source code of This Software is open source code. Anyone who
wishes to view the open source code can do so by downloading it from the CASIO download site. Whenever copying, modifying, or
distributing This Software, be sure to do so in accordance with the terms and conditions of the GPL and LGPL.
(2) This Software is provided "as is" without expressed or implied warranty of any kind. However, this disclaimer does not affect the
terms and conditions of the warranty of the product itself (including malfunctions due to This Software).
(3) The full text of the GPL and LGPL that covers this software can be found at the back of the "CASIO Signage User's Guide".
"CASIO Signage User's Guide" is available as a file that you can download from the CASIO website.
2014/08/25
15:09:26
