Hot Wheels Battleslam Assembly & Instruction Manual

electricracing.com
BATTLESLAM
I. GENERAL INFO
READ THIS FIRST
• First, unfold these instructions, so you can see all four
pages at the same time. These four pages tell you the
"basics" of track assembly, power connection and
maintenance.
• Second, turn these instructions over for detailed, step-
by-step assembly instructions.
A. ASSEMBLE YOUR TRACK
1
Start out on a clean, hard, flat racing surface – not carpet-
ing. Spread out all the track pieces (and other parts) and
check them against the contents list inside.
2
Follow the letters molded into each track piece – it's easy!
Following the Track Layout inside, first lay out your track –
without connecting any track pieces. That way you'll be able
to see how the track layout goes together.
3
To connect track pieces:
working on the flat surface,
push the ends of the track
pieces together. Make sure
they snap together securely
– you'll hear a click when
they're properly connected.
Remember: if the track con-
nections aren't right, electric
power won't flow from one track section to the next.
SEE THE OTHER SIDE FOR DETAILED, STEP-BY-STEP
ASSEMBLY INSTRUCTIONS.
NOT RECOMMENDED FOR CHILDREN UNDER 8 YEARS OF
AGE. AS WITH ALL ELECTRIC PRODUCTS, PRECAUTIONS
®
SHOULD BE OBSERVED DURING HANDLING AND USE TO
PREVENT ELECTRIC SHOCK. MODEL B615RG:
INPUT: 120VAC, 60Hz, OUTPUT: 15.0VDC, 500mA.
for future reference, as they contain important information.
™
4
To disconnect track pieces, sim-
ply reach underneath where the
track pieces meet and press the
locking tabs together with thumb
and forefinger as shown.
5
Guardrails help keep your
car from spinning off on
curves. They also add sup-
port for long "overpasses."
Refer to the Track Layout for
location of guardrails. To
attach guardrails, carefully
attach the bottom of the
guardrail first. Then pull up
and snap into place. Don't
force guardrails into place.
6
Your track layout includes
several specially designed
track supports. Refer to the
Track Layout for location of
track supports. To assemble
the track supports, separate
pieces as shown and remove
connectors. Next, fit the two
pieces together as shown.
1
CAUTI O N - ELECTRI C TOY:
Keep these instructions
91547-0920
