Imagenation PXD1000 Frame Grabber
CyberOptics Semiconductor
Quick Start Guide
Contents
by
Copyright © 2003
922-0081-00
Advertisement
Table of Contents
Related Manuals for Imagenation PXD1000
Summary of Contents for Imagenation PXD1000
- Page 1 WDM and Legacy Driver Issues ....6 Cleanup of Previous Installations ....7 Imagenation PXD1000 Frame Grabber CyberOptics Semiconductor Copyright ©...
-
Page 2: Hardware Installation
Using anti-static precautions, remove the PXD1000 from its anti-static bag. Note: (See Chapter 2, PXD1000 User’s Guide, for anti-static precautions.) Optional: If you plan to use the PXD1000 for setting triggers, switches, etc., attach the I/O ribbon cable to the JP5 connector on the PXD1000 card (Figure 1). -
Page 3: Software Installation
DOS window entitled InfClean. InfClean is an auxiliary program we created to erase INF files left by previous installations of the PXD1000. It ensures a clean installation of this latest version of software. See “Cleanup of Previous Installations” on Page 7 for a more detailed explanation of InfClean. -
Page 4: Installation For Windows Nt 4.0
After installing the PXD1000, turn on your computer, and let the operating system boot. Run the SETUP.EXE program from the PXD1000 CD or from the file that you downloaded from the Imagenation website. The SETUP program installs all of the software: drivers, DLLs, camera configuration files, and samples. -
Page 5: Viewing Live Video (Viewpxd)
Viewing Live Video (ViewPXD) ViewPXD is a utility that comes with the PXD1000. It lets you test your camera by viewing live video, grabbing and saving frames, and zooming in and out on live or still video. You can run ViewPXD from the Start menu as follows: Start ! Programs ! PXD ! ViewPXD Once ViewPXD has started, from the File menu, select PXD, then PXD1. -
Page 6: Drivers And Device Management
Windows Driver Model (WDM) drivers. The PXD1000 uses a legacy driver. Hence, the process does not work perfectly. If you view the properties of the PXD1000 with the Device Manager, you will see a screen similar (depending on your version of Windows) to the one shown in Figure 3. -
Page 7: Cleanup Of Previous Installations
INF file specifies the device as null, hence, the Device Manager does not try to load a WDM driver. The PXD1000 will work just fine. The screen in Figure 3 is NOT a warning, it is just information. -
Page 8: Copyright
